The safety of the device is not guaranteed when it is operated above the “Absolute Maximum Ratings”. The device
should not be operated at these “absolute” limits. Adhere to the “Recommended Operating Conditions” for proper de-
vice function. The information contained in the Electrical Characteristics tables and Typical Performance plots reflect the
operating conditions noted on the tables and plots.
C
omlinear
CLC2550, CLC4550
Low Power, Low Offset, 2V to 36V Comparators
Parameter
Supply Voltage
Differential Input Voltage
Input Voltage
Input Current (V
IN
< -0.3V)
(1)
Output Short Circuit Current to Ground
Power Dissipation (T
A
= 25°C) - SOIC-8
Power Dissipation (T
A
= 25°C) - SOIC-14
Min
0
-0.3
Continuous
Max
40
40
40
50
660
890
Unit
V
V
V
mA
mW
mW
Notes:
1. This input current will only exist when the voltage at any of the input leads is driven negative. It is due to the collector-base junction of the input PNP transistors be-
coming forward biased and thereby acting as input diode clamps. In addition to this diode action, there is also lateral NPN parasitic transistor action on the IC chip. This
transistor action can cause the output voltages of the comparators to go to the V+ voltage level (or to ground for a large overdrive) for the time duration that an input is
driven negative. This is not destructive and normal output states will re-establish when the input voltage, which was negative, again returns to a value greater than -0.3
V
DC
(at 25°C).
Reliability Information
Parameter
Junction Temperature
Storage Temperature Range
Lead Temperature (Soldering, 10s)
Package Thermal Resistance
SOIC-8
SOIC-14
Notes:
Package thermal resistance (q
JA
), JDEC standard, multi-layer test boards, still air.
