MOSPEC
SINGLE-PHASE BRIDGE RECTIFIER
VOLTAGE RANGE 50 to 1000 Volts
CURRENT
8.0 Ampere
FEATURES
＊Low
cost
＊High
forward surge current capability
＊Ideal
for printed circuit board
＊High
temperature soldering guaranteed:
260
o
c/10 second,0.375”(9.5mm)lead length
at 5 lbs. (2.3kg) tension.
MECHANICAL DATA
＊Case:
Transfer molded plastic
＊Epoxy:
UL94V-O rate flame retardant
＊Terminals：Lead
Solderable Per MIL-STD-202
E
method 208C
＊Polarity：Polarity
symbols marked on case
＊Mounting
:Thru hole for #6 screw, 5 in,-lbs.Torqute Max.
＊Weight：
0.27 ounce, 7.59 gram
RS801 THRU RS807
MAXIMUM RATINGS AND ELECTRICAL CHARATERISTICS
* Rating at 25℃ ambient temperature unless otherwise specified
* Single phase,half wave. 60Hz, resistive or inductive load.
* For capacitive load derate current by 20 %
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
T
C
=100℃
Average Rectifier Forward
T
A
=45℃(Note 3)
Current at
Non-Repetitive Peak Surge Current
8.3 ms Single half sine-wave superimposed on
rated load
Forward Voltage (per element) ( I
F
=8.0 Amp)
Peak Reverse Current at rated
DC blocking voltage per element
I
2
t Rating for Fusing( t<8.3ms)
Typical Junction Capacitance per element
(Note1)
Typical Thermal Resistance (per leg)(note 2)
Operating and Storage Temperature Range
T
A
= 25℃
T
A
= 100℃
Symbol RS801 RS802 RS803 RS804 RS805 RS806 RS807
V
RRM
V
RWM
V
DC
V
R(RMS)
I
O(AV)
50
35
100
70
200
140
400
280
8.0
6.0
I
FSM
V
FM
I
R
I
2
t
C
J
R
θ
jc
T
J
, T
stg
150
1.0
10
1.0
93
105
5.0
-65 to +150
600
420
800
560
1000
700
Unit
V
V
A
A
V
uA
mA
A
2
s
pF
o
C/W
℃
Note: 1. Measured at 1.0 MHz and applied reverse voltage of 4.0V D.C.
2. Unit mounted on 3.0”×3.0”×0.11” thick (7.5×7.5×0.3 cm ) Al. plate.
3. Unit mounted in free air, no heatsink, P.C.B. at 375”(9.5mm) lead length with. 5”×5”(12×12 mm) copper pads..
RS801 THRU RS807
FIG-1 FORWARD CURRENT DERATING CURVE
AVERAGE FORWARD RECTIFIED CURRENT (Amp.)
NSTANTANEOUS FORWARD CURRENT (Amp.)
60 Hz Resistive or
Inducttive Load
T
C
Case temperature
Ambient
T
A
Temperature
P.C.B Mounting
0.47”×0.47” (12×12 mm)
Copper Pads
0.375”(9.5mm) Lead Length
FIG-2 TYPICAL FORWARD CHARACTERISITICS
Heat Sink
Mounting
3.0”×3.0”×0.11”
(7.5×7.5×0.3 cm
AL Plate
T
J
=25 C
Pulse Width=300us
1% Duty Cycle
O
CASE TEMPERATURE (℃)
FORWARD VOLTAGE (Volts)
FIG-3 PEAK FORWARD SURGE CURRENT
FIG-4 TYPICAL JUNCTION CAPACITANCE
T
J
=25 C
f=1MHz
O
FWD SURGE CURRENT (A)
II
FSM
, PEAK
NUMBER OF CYCLES AT 60 Hz
JUNCTION CAPACITANCE (
P
F)
T
J
=25 C
Single Half
Sine Wave
(JEDEC Method)
O
REVERSE VOLTAGE (Volts)
FIG-5 TYPICAL REVERSE CHARACTERISTICS
I
R
, INSTANTANEOUS REVERSE CURRENT (uA)
T
J
=125 C
O
T
J
=25 C
O
PERCENT OF RATED REVERSE VOLTAGE (﹪)
