REVISION AB
DO NOT
SCALE FROM
THIS PRINT
PATENT NUMBER
6159045
2 MAX
SWAY
((No OF POS + 2) x .03937) + .100 REF
[1.0000] [2.54]
C
MEC1-1XX-XX-XX-D-RAX-XX-SL-XX
No OF POSITIONS
-05, -08, -20, -30,
-40, -50, -60 & -70
(PER ROW - SEE TABLE 2)
CARD THICKNESS
-01: .031 THICK CARD
(USE MEC1-XX-T-D-RAX-X-SL)
-02: .062 THICK CARD
(USE MEC1-XX-S-D-RAX-X-SL)
(SEE TABLES 1 AND 4)
(SUBSTITUTE -T: FOR -TR: DESIGNATION
WHEN USING -XM PLATING DESIGNATION
WITH BOTH -NP AND -SL OPTIONS)
(-T OR -TR OPTION NOT AVAILABLE FOR
70 POS)
OPTION
-TR: TAPE & REEL
.1096 2.783
REF
(No OF POS -1) x .03937
[1.0000]
"A"
02
DETAIL 'D'
SCALE 6 : 1
SOLDER LOCKS
.268 6.81
REF
01
"A" REF
'D'
"A"
(No OF POS + 2) x .03937 REF
[1.0000]
MEC1-XX-X-D-RA1-X-SL
(No OF POS + 2) x .03937 REF
[1.0000]
PLATING
-F: GOLD FLASH (USE C-150-XX-F-P)
-L: LIGHT SELECTIVE GOLD (USE C-150-XX-L-P)
-S: SELECTIVE GOLD (USE C-150-XX-S-P)
-FM: FLASH GOLD SELECTIVE, MATTE TIN TAIL
(USE C-150-XX-F-P)
-LM: LIGHT SELECTIVE GOLD, MATTE TIN TAIL
(USE C-150-XX-L-P)
-SM: SELECTIVE GOLD, MATTE TIN TAIL
(USE C-150-XX-S-P)
C
NON-POLARIZED OPTION
-NP: NO POLARIZED POSITION
(ONLY AVAILABLE ON -05,
-08, -20, & -30 POSITIONS)
-BLANK: BODY IS POLARIZED
TAIL OPTION
-RA1: STANDARD
-RA2: ELEVATED
ROW SPECIFICATION
-D: DOUBLE (USE MEC1-XX-X-D-RAX-X-SL)
"C" .005
"B" .002 (TYP) (SEE NOTE 8)
.134 3.40 REF
.169 4.29
.320 8.13
REF
C-150-01-X-P
.013 0.32 REF (TYP)
.025 0.64 REF (TYP)
SEE TABLE 3
.460 11.68
REF
.225 5.72
REF
'F'
.470 11.94
.03 0.8
.0394 1.000
C
(No OF POS -1)
x .03937[1.0000]
.0394 1.000
.059 1.50
C
C-150-04-X-P
.070 1.78 REF
.049 1.23
REF
"E"
.01 0.2 REF (TYP)
1.5 MAX SWAY
MEC1-120-02-XX-D-RA1-SL SHOWN
(IN-PROCESSES ON SHEET 2)
NOTES:
1. C REPRESENTS A CRITICAL DIMENSION.
C 2. COPLANARITY: SEE TABLE 3.
3. BURR ALLOWANCE: .004[0.10] MAX.
4. NOTE DELETED.
5. MINIMUM PUSHOUT FORCE: .5 LB.
6. NOTE DELETED.
7. TAIL OPTION -RA1 TO HAVE C-150-01-XX-X CONTACT FULLY PRE-FORMED.
8. TO BE MEASURED ON OPPOSING CONTACTS.
9. BODIES TO BE LAYER PACKAGED FOR TRANSIT BETWEEN INVENTORY AND PRODUCTION.
10. TO BE MEASURED AT 2 MAIN 90 BENDS.
11. HOT BAR FORM AFTER ASSEMBLY (WILL PRODUCE RETENTION FLANGE AS SHOWN).
12. -F PLATING OPTION CAN BE SUBBED FOR -FM, -L FOR -LM, & -S FOR -SM
SECTION "A"-"A"
SEE NOTE 11
DETAIL 'E'
SCALE 4 : 1
.022 0.56 REF
.350 8.89
REF
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
FLAMMABILITY RATING: UL 94V-0
SHEET SCALE: 2:1
DETAIL 'F'
SCALE 4 : 1
INSULATOR: LCP
-01: COLOR: NATURAL
-02: COLOR: BLACK
CONTACT: PHOS BRONZE
F:\DWG\MISC\MKTG\MEC1-1XX-XX-XX-D-RAX-XX-SL-XX-MKT.SLDDRW
1mm MEC1 -RA ASSEMBLY
01/25/00
SHEET
1
OF
3
MEC1-1XX-XX-XX-D-RAX-XX-SL-XX
BY:
MARKS
REVISION AB
(C-150-04-X-P SHOWN)
(-RA1 SECOND ROW)
IN PROCESS
C
.2225 5.652
(SEE NOTE 10)
PACKAGING VIEW
STANDARD TAIL OPTION
ELEVATED TAIL OPTION
.4082 10.367
90°
.1430 3.632
.092 2.34
C
.2045 5.194
90°
* DIMENSIONS ALSO APPLY TO C-150-14-X-P
C
TUBE: PT-1-24-01-106
PLUG: TP-07
TUBE: PT-1-24-02-106
PLUG: TP-13
C-150-X1-X-P
C-150-X4-X-P
.017 0.43
.511 12.98 REF
.089 2.26
.325 8.24 REF
(-RA1 FIRST ROW)
IN-PROCESS 1
(-RA1 SECOND ROW)
IN-PROCESS 2
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 4:1
1mm MEC1 -RA ASSEMBLY
MEC1-1XX-XX-XX-D-RAX-XX-SL-XX
01/25/00
SHEET
2
OF
3
F:\DWG\MISC\MKTG\MEC1-1XX-XX-XX-D-RAX-XX-SL-XX-MKT.SLDDRW
BY:
MARKS
REVISION AB
.1230 3.124
(SEE NOTE 10)
C
C
(-RA2 FIRST ROW)
IN-PROCESS 2
.3070 7.798
(SEE NOTE 10)
C-150-X5-X-P
C
90°
.4112 10.443
.017 0.43
.436 11.07
.3058 7.767
.0170 0.432
90°
.0378 0.959
90°
- 5°
C
+2°
C
.350 8.88
.1160 2.946
90°
C
(-RA2 SECOND ROW)
IN-PROCESS 2
.1430 3.632
.0960 2.438
C-150-X6-X-P
IN-PROCESS 1
(-RA2 FIRST ROW)
(C-150-05-X-P SHOWN)
* DIMENSIONS ALSO APPLY TO C-150-15-X-P
(-RA2 SECOND ROW)
(C-150-06-X-P SHOWN)
* DIMENSIONS ALSO APPLY TO C-150-16-X-P
C-150-06-X-P
"B"
'G'
.092 2.34
.239 6.07 REF
IN-PROCESS 1
MEC1-120-02-XX-D-RA2-SL SHOWN
TAIL OPTION -RA2 [ELEVATED] SHOWN
[DIFFERENT AS SHOWN, OTHERWISE SAME AS TAIL OPTION -RA1]
.010 0.25
.354 8.98
REF
.035 0.89
C
.356 9.04
.219[5.55]
REF
"B"
.002±.003 0.06±0.08
SEE TABLE 3, SHT 1
.024 0.62 REF
'B'
'C'
MEC1-XX-X-D-RA2-SL-X
.052 1.32
C
F:\DWG\MISC\MKTG\MEC1-1XX-XX-XX-D-RAX-XX-SL-XX-MKT.SLDDRW
SECTION "B"-"B"
SCALE 3 : 1
C-150-05-X-P
C
.025 0.64
(TYP)
.022 0.56 REF
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.123 3.12
C
5 MAX
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DETAIL 'B'
SCALE 8 : 1
(DIMENSIONS APPLY TO -RA1 & -RA2 OPTIONS) (APPLIES TO BOTH ROWS)
(SEE NOTE 11 & DETAIL "E", SHT 1)
DETAIL 'C'
SCALE 10 : 1
DO NOT SCALE DRAWING
DETAIL 'G'
SCALE 4 : 1
1mm MEC1 -RA ASSEMBLY
SHEET SCALE: 2:1
MEC1-1XX-XX-XX-D-RAX-XX-SL-XX
01/25/00
SHEET
3
OF
3
BY:
MARKS
