IMC-1008
Vishay Dale
High Frequency, Surface Mount Inductors
FEATURES
•
•
•
•
High self-resonant frequency values
High Q values at higher frequencies
Wirewound construction
Compatible with vapor phase and infrared reflow
soldering
• Tape and reel packaging for automatic handling, 2000/reel
• Compliant to RoHS directive 2002/95/EC
STANDARD ELECTRICAL SPECIFICATIONS
IND.
(nH)
3.3
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
750
820
910
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10 000
12 000
15 000
18 000
22 000
27 000
33 000
39 000
47 000
TEST
RATED
FREQ.
DC
SRF DCR
(MHz)
MIN. MAX. CURRENT
Q
L
Q
(mA)
MIN. (MHz) (Ω)
100 1000 50
6000 0.06
1000
100 1000 50
5500 0.06
1000
100 1000 50
5500 0.06
1000
100 1000 50
4300 0.08
1000
100 500
60
3600 0.08
1000
100 500
60
2700 0.08
1000
100 350
60
2700 0.10
1000
100 350
60
2500 0.10
1000
100 350
60
1800 0.10
1000
100 350
60
1700 0.10
1000
100 350
60
1500 0.10
1000
100 350
60
1500 0.10
1000
100 350
60
1350 0.12
1000
100 350
60
1300 0.15
1000
100 350
60
1100 0.18
1000
100 350
60
1100 0.18
1000
25
100
45
950
0.20
800
25
100
45
880
0.22
800
25
100
45
800
0.33
800
25
100
45
730
0.45
800
25
100
45
650
0.75
600
25
100
45
570
0.90
500
25
100
45
530
1.06
470
25
100
45
480
1.17
420
25
100
45
430
1.50
310
25
100
45
380
2.06
230
25
100
45
360
2.20
200
25
100
45
350
2.30
180
25
100
45
330
3.18
150
25
50
35
310
3.30
120
7.96 7.96
20
280
1.30
230
7.96 7.96
20
250
1.65
220
7.96 7.96
20
200
2.20
210
7.96 7.96
20
160
2.35
200
7.96 7.96
20
130
2.60
195
7.96 7.96
20
80
2.85
185
7.96 7.96
20
50
4.00
180
7.96 7.96
20
45
4.30
175
7.96 7.96
20
42
2.60
170
7.96 7.96
20
39
2.80
165
7.96 7.96
20
36
3.05
160
2.52 2.52
15
33
3.50
150
2.52 2.52
15
30
3.60
140
2.52 2.52
15
26
4.00
130
2.52 2.52
15
24
4.50
120
2.52 2.52
15
22
4.80
110
2.52 2.52
15
21
5.30
95
2.52 2.52
15
20
6.10
85
2.52 2.52
15
18
8.30
60
2.52 2.52
15
17
12.00
45
ELECTRICAL SPECIFICATIONS
Inductance Range:
3.3 nH to 47 000 nH
Inductance and Tolerance:
0.3 nH for 3.3 nH
± 5 % for 6.8 nH to 47 000 nH
Operating Temperature:
- 40 °C to + 125 °C
Core Material:
Ceramic from 3.3 nH to 1000 nH
Ferrite from 1200 nH to 47 000 nH
TOL.
0.3 nH
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
5%
TEST EQUIPMENT
• Inductance and Q measured on HP4286A
• SRF measured on HP8753D
DIMENSIONS
in inches [millimeters]
0.098 ± 0.012
[2.50 ± 0.3]
0.079 ± 0.012
[2.00 ± 0.3]
0.020 ± 0.008
[0.50 ± 0.2]
0.02
[0.5]
0.063 ± 0.012
[1.60 ± 0.3]
DESCRIPTION
IMC-1008
MODEL
10 nH
INDUCTANCE VALUE
±5%
INDUCTANCE TOLERANCE
ER
PACKAGE CODE
e4
JEDEC LEAD (Pb)-FREE STANDARD
Note
For parts within 3.3 nH to 910 nH please use e4 for JEDEC lead (Pb)-free standard. For parts within 1000 nH to 47 000 nH please use e3 for JEDEC lead (Pb)-free standard.
GLOBAL PART NUMBER
I
M
PRODUCT
FAMILY
Document Number: 34041
Revision: 10-Aug-06
C
1
0
SIZE
0
8
E
R
1
0
INDUCTANCE
VALUE
N
J
TOL.
PACKAGE
CODE
For technical questions, contact:
magnetics@vishay.com
www.vishay.com
