MURF1620CT
Technical Data
Data Sheet N0352, Rev. A
MURF1620CT ULTRAFAST RECTIFIER
Features
Ultra-Fast Switching
High Current Capability
Low Reverse Leakage Current
High Surge Current Capability
Plastic Material has UL Flammability Classification 94V-O
This is a Pb − Free Device
All SMC parts are traceable to the wafer lot
Additional testing can be offered upon request
ITO-220AB
Circuit Diagram
Applications
Switching Power Supply
Power Switching Circuits
General Purpose
Maximum Ratings:
Characteristics
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Average Rectified Forward Current
Peak One Cycle Non-Repetitive Surge
Current(Per Leg)
Symbol
V
RRM
V
RWM
V
R
I
F (AV)
I
FSM
Condition
-
50% duty cycle @T
A
=55°C,
rectangular wave form
8.3ms, Half Sine pulse
Max.
200
8(Per Leg)
16(Per Device)
125
Units
V
A
A
Electrical Characteristics:
Characteristics
Forward Voltage Drop(Per Leg)*
Reverse Current(Per Leg)*
Reverse Recovery Time(Per Leg)
Typical Junction Capacitance(Per Leg)
RSM Isolation Voltage
(t=1.0 second,R.H.<
=30%,
T
A
=25C)
Symbol
V
F1
I
R1
I
R2
t
rr
C
J
Condition
@ 8A, Pulse, T
J
= 25C
@V
R
= rated V
R,
T
J
= 25C
@V
R
= rated V
R,
T
J
= 125C
@I
F
=500mA, I
R
=1A,and I
rm
=250mA
@V
R
= 5V, T
C
= 25℃, f
SIG
= 1MHz
Clip mouting, the epoxy body away
from the heatsink edge by more
than 0.110”along the lead direction.
Clip mouting, the epoxy body is
inside the heatsink
Screw mounting, the epoxy body is
inside the heatsink
Typ.
-
-
-
-
-
-
-
-
Max.
1.5
10
500
35
80
4500
3500
1500
Units
V
μA
μA
ns
pF
V
iso
V
* Pulse width < 300 µs, duty cycle < 2%
China - Germany - Korea - Singapore - United States
http://www.smc-diodes.com - sales@ smc-diodes.com
MURF1620CT
Technical Data
Data Sheet N0352, Rev. A
Ordering Information
Device
MURF1620CT
ITO-220AB
(Pb-Free)
Package
Shipping
50 pcs/ tube
For information on tape and reel specifications, including part orientation and tape sizes, please refer to our tape and reel packaging
specification.
DISCLAIMER:
1- The information given herein, including the specifications and dimensions, is subject to change without prior notice to improve product
characteristics. Before ordering, purchasers are advised to contact the SMC - Sangdest Microelectronics (Nanjing) Co., Ltd sales department
for the latest version of the datasheet(s).
2- In cases where extremely high reliability is required (such as use in nuclear power control, aerospace and aviation, traffic equipment, medical
equipment , and safety equipment) , safety should be ensured by using semiconductor devices that feature assured safety or by means of
users’ fail-safe precautions or other arrangement .
3- In no event shall SMC - Sangdest Microelectronics (Nanjing) Co., Ltd be liable for any damages that may result from an accident or any other
cause during operation of the user’s units according to the datasheet(s). SMC - Sangdest Microelectronics (Nanjing) Co., Ltd assumes no
responsibility for any intellectual property claims or any other problems that may result from applications of information, products or circuits
described in the datasheets.
4- In no event shall SMC - Sangdest Microelectronics (Nanjing) Co., Ltd be liable for any failure in a semiconductor device or any secondary
damage resulting from use at a value exceeding the absolute maximum rating.
5- No license is granted by the datasheet(s) under any patents or other rights of any third party or SMC - Sangdest Microelectronics (Nanjing)
Co., Ltd.
6- The datasheet(s) may not be reproduced or duplicated, in any form, in whole or part, without the expressed written permission of SMC -
Sangdest Microelectronics (Nanjing) Co., Ltd.
7- The products (technologies) described in the datasheet(s) are not to be provided to any party whose purpose in their application will hinder
maintenance of international peace and safety nor are they to be applied to that purpose by their direct purchasers or any third party. When
exporting these products (technologies), the necessary procedures are to be taken in accordance with related laws and regulations..
China - Germany - Korea - Singapore - United States
http://www.smc-diodes.com - sales@ smc-diodes.com
