SYS-4W5120-4U01E
Features
Intel 945G Platform
Ideal for Embedded Applications
Intel
®
Core™ 2 Duo
MicroATX System with
Front-Accessible I/O
- Supports Intel Core 2 Duo processor up to 2.66 GHz
- Supports dual channel DDR2 533/667 SDRAM up to 4 GB
- One integrated GbE delivers excellent network performance
- Ultra compact chassis with all-in-one feature
- All I/O interfaces are located in the front to facilitate cable routing
- Accepts standard optical drive, FDD and 3.5" HDD for better cost
structure
- Supports up to four add-on cards
Specifications
Form Factor
Chipset
CPU
Processor System
L2 Cache
Front Side Bus
Memory
Controller
VRAM
PCIe x16
PCIe x1
PCI
Optical Drive (supported)
Floppy Disk (supported)
HDD (supported)
5.25" (front-accessible)
3.5" (front-accessible)
3.5" (internal)
Interface
Controller
USB
PS/2
COM
VGA
Parallel
RJ-45
Audio
Output
Interval
Power Output Wattage
Input Range
Chassis Fan
Air Filter
LED Indicators
Temperature
Humidity
Dimensions (W x H x D)
Weight
Wallmount / Desktop
Intel 945G + ICH7
Intel Core 2 Duo
Pentium D
Pentium 4
Pentium Dual Core
2.66 GHz
3.2 GHz
3.8 GHz
2.2 GHz
4 MB
4 MB
2 MB / 1 MB
1 MB
533 / 800 / 1066 MHz
Dual channel DDR2 533/667 SDRAM up to 4 GB
Intel 945G integrated
Dynamically shared system memory up to 224 MB
1
1
2 x 32-bit
CD-ROM / DVD-ROM / CD-RW
3.5" 1.44 MB FDD
SATA
1
1
1
10/100/1000 Mbps Gigabit Ethernet
Intel 82573L
4
2
1
1
1
1
6 (Mic-in, Line-in, Line-out, CD-Audio)
Microsoft Windows 2000/ XP/ Vista
Window XP Embedded
System Reset
Programmable 1 ~ 255 seconds
250 W
AC 100 ~ 240V
2 (12 cm / 85 CFM + 6 cm / 10 CFM)
Yes
Power status and HDD activity
Operating
Non-Operating
0 ~ 40° C (32 ~ 104° F)
-20 ~ 60° C (-4 ~ 140° F)
10 ~ 85% @ 40° C non-condensing
10 ~ 95% @ 40° C non-condensing
320 x 164 x 317 mm (12.6" x 6.5" x 12.5")
10 kg (22 lb)
Celeron D
3.06 GHz
512 KB / 256 KB
Graphics
Expansion Slot
Storage
Drive Bay
Ethernet
Front I/O Interface
Operating System
Watchdog Timer
Power Supply
Cooling
Miscellaneous
Environment
Physical Characteristics
Pre-Configured Systems
All product specifications are subject to change without notice
Last updated : 24-Mar-2009
SYS-4W5120-4U01E
Dimensions
Unit: mm (inch)
Installation
Unit: mm (inch)
320 [12.6"]
6-ø5.2
24 [0.9˝] 176.2 [6.9˝]
164 [6.5"]
316.5 [12.5"]
8-ø10
8-ø5.2
334.6 [13.2˝]
349.4 [13.8˝]
178.6 [7.0˝]
193.4 [7.6˝]
Ordering Information
Part Number
SYS-4W5120-4U01E
Chassis
IPC-5120-25ZBE
Desktop/wallmount chassis
with 250W power supply (ATX)
Motherboard
AIMB-562VG-00A1E
LGA775 Core 2 Duo/Pentium 4
MicroATX motherboard
Regulation
UL, CB
Front View
HDD LED
3.25" drive bay
Power switch 5.25" drive bay
Inside View
Easy-to-maintain air filter
Shockproof
drive bay
for holding
an internal
3.5" HDD
Power LED
Reset switch
Supports up to
four half-size
add-on cards
12 cm /
85 CFM
cooling fan
6 cm /
10 CFM
cooling fan
1U 300 W ATX
power supply
MicroATX
motherboard
Download
www.advantech.com/products
99.5 [3.9˝]
99.5 [3.9˝]
24 [0.9˝]
