DL5519-TP

Description
Zener Diode, 3.6V V(Z), 20%, 0.5W, Silicon, Unidirectional, ROHS COMPLIANT, HERMETIC SEALED, GLASS, MINIMELF-2
CategoryDiscrete semiconductor    diode
File Size482KB,4 Pages
ManufacturerMicro Commercial Components (MCC)
Environmental Compliance
Download Datasheet Parametric View All

DL5519-TP Overview

Zener Diode, 3.6V V(Z), 20%, 0.5W, Silicon, Unidirectional, ROHS COMPLIANT, HERMETIC SEALED, GLASS, MINIMELF-2

DL5519-TP Parametric

Parameter NameAttribute value
Is it lead-free?Lead free
Is it Rohs certified?conform to
MakerMicro Commercial Components (MCC)
Parts packaging codeMELF
package instructionROHS COMPLIANT, HERMETIC SEALED, GLASS, MINIMELF-2
Contacts2
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresHIGH RELIABILITY
Shell connectionISOLATED
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeZENER DIODE
JESD-30 codeO-LELF-R2
JESD-609 codee3
Number of components1
Number of terminals2
Maximum operating temperature125 °C
Minimum operating temperature-65 °C
Package body materialGLASS
Package shapeROUND
Package formLONG FORM
Peak Reflow Temperature (Celsius)260
polarityUNIDIRECTIONAL
Maximum power dissipation0.5 W
Certification statusNot Qualified
Nominal reference voltage3.6 V
surface mountYES
technologyZENER
Terminal surfaceMatte Tin (Sn)
Terminal formWRAP AROUND
Terminal locationEND
Maximum time at peak reflow temperature10
Maximum voltage tolerance20%
Working test current20 mA
MCC
TM
Micro Commercial Components
  omponents
20736 Marilla Street Chatsworth

  !"#
$ %    !"#
DL5518B
THRU
DL5546B
500mW Silicon
Zener Diodes
Features
Zener Voltage 3.3V-33V
Low Reverse Leakage Characteristic
Metallurgically Bonded
High Reliability
Lead Free Finish/RoHS Compliant(Note 1) ("P" Suffix designates
Compliant. See ordering information)
Surface Mount Application
Mechanical Data
Case: Double slug type, hermetically sealed glass
Polarity: Cathode indicated by polarity band
MINIMELF
Maximum Ratings
Symbol
DC Power Dissipation
@T
EC=
125
O
C
Junction Temperature
Storage Temperature Range
Power Dissipation
aboveT
EC=
125
O
C
P
D
T
J
T
STG
P
D
Value
500
-65 to125
-65 to125
10
mW/
DIM
A
Cathode Mark
Units
mW
B
C
DIMENSION
INCHES
MIN
MAX
MM
MIN
MAX
NOTE
A
B
C
.130
.008
.055
.146
.016
.059
3.30
0.20
1.40
3.70
0.40
1.50
Electrical Characteristics @ 25 C Unless Otherwise Specified
Symbol
Max. Forward Voltage
@ I
F
=200mA
V
F
Maximum
1.1
Unit
V
SUGGESTED SOLDER
PAD LAYOUT
0.105
Note:1.Lead in Glass Exemption Applied, see EU Directive Annex 5.
0.075”
0.030”
Revision:
4
www.mccsemi.com
1 of 4
2009/09/01
