MURB820-1PBF

Description
Rectifier Diode, 1 Phase, 1 Element, 8A, 200V V(RRM), Silicon, TO-262AA, TO-262, 3 PIN
CategoryDiscrete semiconductor    diode
File Size196KB,8 Pages
ManufacturerInternational Rectifier ( Infineon )
Websitehttp://www.irf.com/
Environmental Compliance
Download Datasheet Parametric Compare View All

MURB820-1PBF Overview

Rectifier Diode, 1 Phase, 1 Element, 8A, 200V V(RRM), Silicon, TO-262AA, TO-262, 3 PIN

MURB820-1PBF Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerInternational Rectifier ( Infineon )
Parts packaging codeTO-262AA
package instructionTO-262, 3 PIN
Contacts3
Reach Compliance Codecompliant
Other featuresFREE WHEELING DIODE
applicationULTRA FAST RECOVERY
Shell connectionCATHODE
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)0.895 V
JEDEC-95 codeTO-262AA
JESD-30 codeR-PSIP-T3
JESD-609 codee3
Humidity sensitivity level1
Maximum non-repetitive peak forward current100 A
Number of components1
Phase1
Number of terminals3
Maximum operating temperature175 °C
Maximum output current8 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formIN-LINE
Peak Reflow Temperature (Celsius)260
Certification statusNot Qualified
Maximum repetitive peak reverse voltage200 V
Maximum reverse recovery time0.035 µs
surface mountNO
Terminal surfaceMATTE TIN OVER NICKEL
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperature40
Bulletin PD-20731 rev.
C
12/03
MUR820
MURB820
MURB820-1
Ultrafast Rectifier
Features
Ultrafast Recovery Time
Low Forward Voltage Drop
Low Leakage Current
175°C Operating Junction Temperature
t
rr
= 25ns
I
F(AV)
= 8Amp
V
R
= 200V
Description/ Applications
International Rectifier's MUR.. series are the state of the art Ultra fast recovery rectifiers specifically designed with
optimized performance of forward voltage drop and ultra fast recovery time.
The planar structure and the platinum doped life time control, guarantee the best overall performance, ruggedness and
reliability characteristics.
These devices are intended for use in the output rectification stage of SMPS, UPS, DC-DC converters as well as free-
wheeling diode in low voltage inverters and chopper motor drives.
Their extremely optimized stored charge and low recovery current minimize the switching losses and reduce over
dissipation in the switching element and snubbers.
Absolute Maximum Ratings
Parameters
V
RRM
I
F(AV)
I
FSM
I
FM
T
J
, T
STG
Peak Repetitive Peak Reverse Voltage
Average Rectified Forward Current
Total Device, (Rated V
R
), T
C
= 150°C
Non Repetitive Peak Surge Current
Peak Repetitive Forward Current
(Rated V
R
, Square wave, 20 KHz), T
C
= 150°C
Operating Junction and Storage Temperatures
-65 to 175
°C
100
16
Max
200
8
Units
V
A
Case Styles
MUR820
MURB820
MURB820-1
TO-220AC
www.irf.com
D
2
PAK
TO-262
1

MURB820-1PBF Related Products

MURB820-1PBF MURB820PBF MURB820TRPBF MURB820TR
Description Rectifier Diode, 1 Phase, 1 Element, 8A, 200V V(RRM), Silicon, TO-262AA, TO-262, 3 PIN Rectifier Diode, 1 Phase, 1 Element, 8A, 200V V(RRM), Silicon, D2PAK-3 Rectifier Diode, 1 Phase, 1 Element, 8A, 200V V(RRM), Silicon, D2PAK-3 Rectifier Diode, 1 Phase, 1 Element, 8A, 200V V(RRM), Silicon, D2PAK-3
Is it Rohs certified? conform to conform to conform to incompatible
Maker International Rectifier ( Infineon ) International Rectifier ( Infineon ) International Rectifier ( Infineon ) International Rectifier ( Infineon )
Parts packaging code TO-262AA TO-263 TO-263 TO-263
package instruction TO-262, 3 PIN R-PSSO-G2 R-PSSO-G2 R-PSSO-G2
Contacts 3 3 3 3
Reach Compliance Code compliant compliant compliant compli
Other features FREE WHEELING DIODE FREE WHEELING DIODE FREE WHEELING DIODE FREE WHEELING DIODE
application ULTRA FAST RECOVERY ULTRA FAST RECOVERY ULTRA FAST RECOVERY ULTRA FAST RECOVERY
Shell connection CATHODE CATHODE CATHODE CATHODE
Configuration SINGLE SINGLE SINGLE SINGLE
Diode component materials SILICON SILICON SILICON SILICON
Diode type RECTIFIER DIODE RECTIFIER DIODE RECTIFIER DIODE RECTIFIER DIODE
JESD-30 code R-PSIP-T3 R-PSSO-G2 R-PSSO-G2 R-PSSO-G2
JESD-609 code e3 e3 e3 e0
Humidity sensitivity level 1 1 1 1
Maximum non-repetitive peak forward current 100 A 100 A 100 A 100 A
Number of components 1 1 1 1
Phase 1 1 1 1
Number of terminals 3 2 2 2
Maximum operating temperature 175 °C 175 °C 175 °C 175 °C
Maximum output current 8 A 8 A 8 A 8 A
Package body material PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY
Package shape RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR
Package form IN-LINE SMALL OUTLINE SMALL OUTLINE SMALL OUTLINE
Peak Reflow Temperature (Celsius) 260 260 260 260
Certification status Not Qualified Not Qualified Not Qualified Not Qualified
Maximum repetitive peak reverse voltage 200 V 200 V 200 V 200 V
Maximum reverse recovery time 0.035 µs 0.035 µs 0.035 µs 0.035 µs
surface mount NO YES YES YES
Terminal surface MATTE TIN OVER NICKEL MATTE TIN OVER NICKEL MATTE TIN OVER NICKEL TIN LEAD
Terminal form THROUGH-HOLE GULL WING GULL WING GULL WING
Terminal location SINGLE SINGLE SINGLE SINGLE
Maximum time at peak reflow temperature 40 30 30 NOT SPECIFIED
