BF909T/R

Description
TRANSISTOR 2 CHANNEL, UHF BAND, Si, N-CHANNEL, RF SMALL SIGNAL, MOSFET, MICRO MINIATURE, PLASTIC PACKAGE-4, FET RF Small Signal
CategoryDiscrete semiconductor    The transistor
File Size316KB,12 Pages
ManufacturerNXP
Websitehttps://www.nxp.com
Environmental Compliance
Download Datasheet Parametric View All

BF909T/R Overview

TRANSISTOR 2 CHANNEL, UHF BAND, Si, N-CHANNEL, RF SMALL SIGNAL, MOSFET, MICRO MINIATURE, PLASTIC PACKAGE-4, FET RF Small Signal

BF909T/R Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerNXP
package instructionMICRO MINIATURE, PLASTIC PACKAGE-4
Contacts4
Reach Compliance Codeunknown
ECCN codeEAR99
Other featuresLOW NOISE
Shell connectionSOURCE
ConfigurationCOMPLEX
Minimum drain-source breakdown voltage7 V
Maximum drain current (Abs) (ID)0.04 A
Maximum drain current (ID)0.04 A
FET technologyMETAL-OXIDE SEMICONDUCTOR
Maximum feedback capacitance (Crss)0.05 pF
highest frequency bandULTRA HIGH FREQUENCY BAND
JESD-30 codeR-PDSO-G4
JESD-609 codee3
Number of components2
Number of terminals4
Operating modeDUAL GATE, ENHANCEMENT MODE
Maximum operating temperature150 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)260
Polarity/channel typeN-CHANNEL
Certification statusNot Qualified
surface mountYES
Terminal surfaceTIN
Terminal formGULL WING
Terminal locationDUAL
Maximum time at peak reflow temperature40
transistor applicationsAMPLIFIER
Transistor component materialsSILICON
BF909; BF909R
N-channel dual gate MOS-FETs
Rev. 02 — 19 November 2007
Product data sheet
IMPORTANT NOTICE
Dear customer,
As from October 1st, 2006 Philips Semiconductors has a new trade name
- NXP Semiconductors, which will be used in future data sheets together with new contact
details.
In data sheets where the previous Philips references remain, please use the new links as
shown below.
http://www.philips.semiconductors.com use http://www.nxp.com
http://www.semiconductors.philips.com use http://www.nxp.com (Internet)
sales.addresses@www.semiconductors.philips.com use salesaddresses@nxp.com
(email)
The copyright notice at the bottom of each page (or elsewhere in the document,
depending on the version)
- © Koninklijke Philips Electronics N.V. (year). All rights reserved -
is replaced with:
- © NXP B.V. (year). All rights reserved. -
If you have any questions related to the data sheet, please contact our nearest sales
office via e-mail or phone (details via salesaddresses@nxp.com). Thank you for your
cooperation and understanding,
NXP Semiconductors
