CLR130W,CLR131W,CLR132W
NPN Silicon Photodarlingtons
CLR130W, CLR131W, and CLRW132 are
exact replacements for obsolete part numbers
CLR2049, CLR2050 and CLR2060.
0.210 (5.33)
0.190 (4.83)
0.500 (12.7) min
0.190 (4.83)
0.176 (4.47)
®
Clairex
0.215 (5.46)
0.205 (5.21)
Technologies, Inc
.
April, 2002
COLLECTOR
0.160 (4.06)
0.150 (3.81)
BASE
EMITTER
0.100 (2.54) dia
0.010 (0.25)
max
0.025 (0.64)
max
0.019 (0.48)
0.016 (0.41)
0.147 (3.73)
0.137 (3.48)
ALL DIMENSIONS ARE IN INCHES (MILLIMETERS)
Case 18
features
absolute maximum ratings
(T
A
= 25°C unless otherwise stated)
storage temperature........................................................................-65°C to +150°C
•
high sensitivity
operating temperature ....................................................................-65°C to +125°C
•
±35° acceptance angle
lead soldering temperature
(1)
..........................................................................260°C
•
TO-18 hermetically sealed package
collector-emitter voltage .................................................................................... 15V
•
transistor base is bonded
continuous collector current ........................................................................... 50mA
•
RoHS compliant
continuous power dissipation
(2)
....................................................................250mW
description
The CLR130W-CLR132W series are
notes:
1. 0.06” (1.5mm) from the header for 5 seconds maximum
NPN silicon photodarlingtons
2. Derate linearly 2.0mW/°C from 25°C free air temperature to T
A
= +125°C.
mounted in TO-18 flat window
packages. The wide acceptance
angle provided by the flat window
enables even reception over a
relatively large area.
Photodarlingtons allow high
sensitivity at low irradiance levels
These devices are mechanically
and spectrally matched to the
CLE130-CLE133 series IREDs. For
additional information, call Clairex.
electrical characteristics
(T
A
= 25°C unless otherwise noted)
symbol
parameter
Light current
(1)
I
L
I
CEO
V
(BR)CEO
t
r
t
f
θ
HP
Collector dark current
Collector-emitter breakdown
Output rise time
Output fall time
Total angle at half sensitivity points
CLR130W
CLR131W
CLR132W
min
0.2
0.6
1.4
-
15
-
-
-
typ
-
-
-
-
-
100
150
70
max
-
-
-
100
-
-
-
-
units
mA
mA
mA
nA
V
µs
µs
deg.
test conditions
V
CE
=5V, E
e
=0.06mW/cm
2
V
CE
=10V, E
e
=0
I
C
=100µA
V
CE
=5V, R
L
=100Ω.
V
CE
=5V, R
L
=100Ω.
note:
1. Radiation source for all light current testing is a 940nm IRED.
Revised 3/13/06
Clairex reserves the right to make changes at any time to improve design and to provide the best possible product.
Clairex Technologies, Inc.
Phone: 972-265-4900
1301 East Plano Parkway
Fax: 972-265-4949
Plano, Texas 75074-8524
www.clairex.com
