IC SOCKETS
Open frame style
Very competitively priced
Flame retardant
Low profile
Gold plated turned pin
contacts
Available in 0.3", 0.6" & 0.9" pitch
TURNED - PIN CONTACT
SPECIFICATION
Material
Insulator:
Sleeve:
Contact:
Sleeve Plating:
Contact Plating:
Thermoplastic polyester, UL rated 94V-0
Machined brass
Beryllium copper
Tin
Gold flash
Mechanical
Vibration:
Shock:
Durability:
Normal Force:
Passed MIL-STD-1344, Method 2005.1,
Condition II, 10 G's
Passed MIL-STD-1334, Method 2004.1,
Condition C, 100 G's
Passed MIL-STD-1344, Method 2016
125 Grams (4.4 oz.) average with .018" (0,46) dia.
polished steel pin (Premium Series)
200 Grams (7.1 oz.) average with .018" (0,46) dia.
polished steel pin (Economy Series)
Electrical
Contact Resistance:10
mΩ max.
Contact Rating:
3A
Capacitance:
1pF per MIL-STD-202, Method 305
Insulation Resistance:5,000
MΩ min. @ 500 VDC per
MIL-STD-1344, Method 3003.1
Dielectric Withstanding
Voltage:
1,000 Volts rms per MIL-STD-1344,
Method 3001.1
Inner Contact
Retention:
Sleeve Retention:
Solderability:
Insertion Force:
Environmental
Humidity:
Thermal Shock:
Operation
temperature:
Passed MIL-STD-1344, Method 1002.2, Cond. II
Passed MIL-STD-1344, Method 1003.1 Cond. A
-55°C to +105°C
7.5 Lbs. per line average
3.0Lbs. per line minimum
Passed MIL-STD-202F, Method 208
- 179 grams (6.3 oz.) average with a
.018" (0,46) dia. polished steel pin
Withdrawal Force:
63 Grams (2.2 oz.) average with a
(Premium and Economy)
.018" (0,46) dia. polished steel pin
OUTLINE DRAWING
A
A
A
.100
.100 .100
(2,54)
(2,54)
TYP.
(2,54)
TYP.TYP.
B
B
B
B
P.C.B. Hole Layout
P.C.B. HoleHole Layout
P.C.B. Layout
Tolerance
±.002(0.05)
Tolerance
±.002(0.05)
Tolerance
±.002(0.05)
ø.035
ø.035
(0.89)
ø.035
(0.89)
(0.89)
No. of
Contacts
8
14
16
18
20
24
24
28
32
36
40
42
48
64
A
.400
.700
.800
.900
1.00
1.20
1.20
1.40
1.60
1.80
2.00
2.10
2.40
3.20
B
C
SECTION 14
C
C
C
B
B
.300
.400
Number of windows
Number number of
Number of windows
varies with of windowscontacts
varies with with number of contacts
varies number of contacts
.180(4.57)Max.
.180(4.57)Max.
.180(4.57)Max.
.125(3.18)
.125(3.18)
.125(3.18)
B
.210(5.33)Max
.210(5.33)Max
.210(5.33)Max
.100(2.54)
.100(2.54)
.100(2.54)
ø.020
ø.020
ø.020
(0.51)
(0.51)
(0.51)
.105(2.67)Max
.105(2.67)Max
.105(2.67)Max
.600
.700
.900
1.00
B
B
Application Dimensions:
ORDERING INFORMATION
DBC
Dubilier
Connectors
IC
Series
IC
06=6way
08=8way
14=14way
16=16way
18=18way
20=20way
24=24way
*24=24way
32
No. of Ways
*24=24way
*28=28way
*32=32way
*36=36way
*40=40way
*42=42way
*48=48way
**64=64way
TP
Type of Contact
TP=Turn Pin
6
Pitch
Blank=0.3”
Pitch
*6=0.6” Pitch
**9=0.9”Pitch
PCB Thickness Range: Standard .062 "
and .092" (1,57 and 2,34).
PCB Hole Size Range: .035" ± .002"
(0,89 ± 0,05) PC tail,.005" ± .003" (1,40 ±
0,08) solderless wrap.
IC Pin Dimension Range: .009" x .015"
(0,23 x 0,38) through.001" x .020" (0,28
x 0,51)
.016" to .021" (0,41 to 0,53) round lead
.105" (2,67) min. length.
314
Fax: 01371 875075
www.dubilier.co.uk
Tel: 01371 875758
