BFX29-QR-B: Description600mA, 60V, PNP, Si, SMALL SIGNAL TRANSISTOR, TO-39, TO-39, 3 PIN; CategoryDiscrete semiconductor The transistor; File Size111KB，3 Pages; ManufacturerSEMELAB

Download Datasheet Parametric Compare View All

BFX29-QR-B Overview

600mA, 60V, PNP, Si, SMALL SIGNAL TRANSISTOR, TO-39, TO-39, 3 PIN

BFX29-QR-B Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	SEMELAB
Parts packaging code	TO-39
package instruction	CYLINDRICAL, O-MBCY-W3
Contacts	3
Reach Compliance Code	compliant
ECCN code	EAR99
Maximum collector current (IC)	0.6 A
Collector-emitter maximum voltage	60 V
Configuration	SINGLE
Minimum DC current gain (hFE)	40
JEDEC-95 code	TO-39
JESD-30 code	O-MBCY-W3
Number of components	1
Number of terminals	3
Maximum operating temperature	200 °C
Package body material	METAL
Package shape	ROUND
Package form	CYLINDRICAL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Polarity/channel type	PNP
Certification status	Not Qualified
surface mount	NO
Terminal form	WIRE
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
Transistor component materials	SILICON
Nominal transition frequency (fT)	360 MHz

Preview

Download Datasheet

View All

SILICON PNP TRANSISTOR

BFX29

•

Hermetic TO-39 Metal package.

Ideally suited for Switching

and General Purpose Applications

Screening Options Available

ABSOLUTE MAXIMUM RATINGS

(TC = 25°C unless otherwise stated)

VCBO

VCEO

VEBO

IC

ICM

PD

TJ

Tstg

Collector – Base Voltage

Collector – Emitter Voltage

Emitter – Base Voltage

Continuous Collector Current

Peak Collector Current

Total Power Dissipation at

TA = 25°C

Derate Above 25°C

Junction Temperature Range

Storage Temperature Range

60V

5V

600mA

600mW

34mW/°C

-65 to +200°C

THERMAL PROPERTIES

Symbols

R

θJA

Parameters

Thermal Resistance, Junction To Ambient

Max.

292

Units

°C/W

Semelab Limited reserves the right to change test conditions, parameter limits and package dimensions without notice.

Information furnished by Semelab is believed to be both accurate and reliable at the time of going to press. However

Semelab assumes no responsibility for any errors or omissions discovered in its use. Semelab encourages customers to

verify that datasheets are current before placing orders.

Semelab Limited

Coventry Road, Lutterworth, Leicestershire, LE17 4JB

Telephone +44 (0) 1455 556565

Fax +44 (0) 1455 552612

Email:

sales@semelab-tt.com

Document Number 3083

Issue 3

Page 1 of 3

Website:

http://www.semelab-tt.com
