GBU1001 - GBU1007
Pb
RoHS
COMPLIANCE
Single Phase 10.0 AMPS. Glass Passivated
Bridge Rectifiers
GBU
Features
UL Recoganized File # E-326243
Glass passivated junction
Ideal for printed circuit board
High case dielectric strength of 1500Vrms
Plastic material has Underwriters laboratory
flammability Classification 94V-0
Typical IR less than 0.1uA
High surge current capability
High temperature soldering guaranteed:
260℃ / 10 seconds at 5 lbs., ( 2.3 kg ) tension
Green compound with suffix “G” on packing code &
prefix “G” on datecode.
Dimension in inches and (millimeter)
Mechanical Data
Case : Molded plastic body
Terminal : Pure
tin plated , Lead free. Leads solderable per
MIL-STD-202 Method 208
Weight : 0.141 ounce ,4 grams
Mounting Torque : 5 in lbs max.
Maximum Ratings and Electrical Characteristics
Rating at 25℃ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%
Type Number
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
@ T
C
= 100
o
C
Peak Forward Surge Current, 8.3 ms Single Half Sine-
wave Superimposed on Rated Load (JEDEC method )
Rating of fusing ( t < 8.3mS )
Maximum Instantaneous Forward Voltage @ 5.0A
@ 10.0A
Maximum DC Reverse Current
@ TA=25℃
at Rated DC Blocking Voltage @ TA=125℃
Typical Junction Capacitance per leg (Note 1)
Typical Thermal Resistance (Note 2)
Operating Temperature Range
Storage Temperature Range
Note 1 : Measured at 1MHz and applied Reverse bias of 4.0V DC.
2. Unit case mounted on 4" x 6" x 0.25" Al plate heat sink.
Symbol
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
t
V
F
I
R
Cj
R
θJA
R
θJC
T
J
T
STG
GBU
1001
50
35
50
GBU
1002
100
70
100
GBU
1003
200
140
200
GBU
1004
400
2100
400
10.0
220
200
1.0
1.1
5.0
500
GBU
1005
600
420
600
GBU
1006
1000
560
1000
GBU
1007
1000
700
1000
Units
V
V
V
A
A
A
2
S
V
uA
211
21
2.0
-55 to +150
-55 to +150
94
pF
oC/W
O
O
C
C
1 of 2
Version : C09
Rating and Sharacteristic Curves (GBU1001 Thru GBU1007)
FIG 1 Maximum Derating Curve for Output
Current
Peak Forward Surge Current
10
FIG 2 Maximum Forward Surge Current per Leg
225
200
175
150
8.3mS Single
Half Sin-wave
(Jedec Method)
Average Forward Current
8
6
(A)
Mounted on 4"
(A)
125
100
75
50
25
0
4
2
0
0
20
x 6" x 0.25" Al-
plate heat sink
40
Case Temperature ( C)
60
80
100
o
120
140
160
1
Number of cycles at 60 Hz
10
100
FIG 3 Typical Reverse Characteristics per Leg
1000
FIG 4 Typical Forward Characteristics per Leg.
100
Instantaneous Reverse Current (uA)
100
Ta=125
o
C
Instantaneous Forward Current (A)
10
10
1
Ta=25
o
C
1
0.1
0
20
40
60
80
100
120
140
0.1
0.6
0.7
0.8
0.9
1
1.1
1.2
1.3
Percent of Rated Peak Reverse Volatge (V)
Instantaneous Forward Voltage (V)
FIG 5 Typical Junction Capacitance
1000
Junction Capacitance (pF)
GBU1001-
GBU1004
100
GBU1005-
GBU1007
10
0.1
1
10
100
Reverse Voltage (V)
2 of 2
Version : C09
