PCLD-786
PCLD-7216
8-ch SSR I/O Module Carrier Board
16-ch SSR I/O Module Carrier Board
PCL-10120-1
PCLD-786
PCLM-ODC5
PCLD-7216
Features
Up to eight AC or DC solid state relay modules
Photo-coupler isolated operation
Eight external relay drivers
LED status indicators
Features
Channel status reflected by onboard LED for easy monitoring
Onboard fuse protection
Specifications
Module type
Output Modules
AC Output
Part No.
PCLM-OAC5A
PCLM-ODC5
Part No.
PCLM-IAC5A
PCLM-IDC5B
Field side
Output Voltage
Output Current
Rating
Rating
24 ~ 280 V
AC
3.0 A
AC
12 ~ 280 V
AC
5 ~ 60 V
AC
Input On Voltage
180 ~ 280 V
AC
3 ~ 32 V
AC
3.0 A
C
Input Off Voltage
< 80 V
AC
< 1 V
AC
Logic side
Input Logic and
SSR Status
TTL low (On)
TTL high (Off)
TTL low (On)
TTL high (Off)
Output Logic and
On/Off Status
TTL low (On)
TTL high (Off)
TTL low (On)
TTL high (Off)
Specifications
AC Solid State Relays
1 Cycle Surge
Blocking Voltage
Off Leakage Current
On-state Voltage
Output Rating
Turn On
Turn On/Turn Off Time
Type
1 Second Surge
OFF Leakage Current
ON-state Voltage
Output Rating
Turn On/Turn Off Time
Type
Channels
Coil Driving Voltage
Driver Type
Max. Driving Current
40 A
±600 V min.
8 mA max.
1.6 V max.
24 ~ 280 V
AC
@ 3.0 A
zero volts
< ½ cycle
PCLM-OAC5A
5A
1 mA max.
1.4 V max.
5 ~ 60 V
DC
@ 3.0 A
750 µs max.
PCLM-ODC5
8
+5 V, +12 V from PC or external source
ULN2003, open collector type
125 mA each channel
DC Output
Input Modules
AC Input
DC Input
Input Modules
Field Side:
Input On/Off
Voltage Range
PCLM-IAC5: 90 ~ 140 V/45 V
RMS
PCLM-IAC5A: 180 ~ 280 V/80 V
RMS
PCLM-IDC5B: 3 ~ 32 V/1 V
DC
PCLM-IAC5: 14 kΩ, PCLM-IAC5A: 44 kΩ,
PCLM-IDC5B: 1.5 kΩ
PCLM-IAC5: 20 msec. max., PCLM-IAC5A: 20 msec. max.
PCLM-IDC5B: 100 msec. max.
30 V
DC
100 mA max.
0.4 V max.
12 mA max.
4~6V
DC Solid State Relays
Input Resistance
Turn On/Off Time
Logic Side:
Breakdown Voltage
Output Current
Output Voltage Drop
Supply Current
Supply Voltage
External Relay Drivers
Output Modules
General
Dimensions (L x W)
205 x 114 mm (8.1" x 4.5")
Field Side:
Current Rating
Contact Voltage Drop
Turn On/Off Time
Logic Side:
Input Resistance
Supply Voltage
Supply Current
3 A max. (@ 25° C)
1.6 V max.
PCLM-OAC series: ½ AC cycle max.
PCLM-ODC series: 100 µsec/750 µsec. max.
220
Ω
4~6V
12 mA max.
50-pin edge connector, Opto-22 compatible
367 x 111 x 56 mm (14.4" x 4.4" x 2.2")
Ordering Information
PCLD-786
8-ch SSR I/O Module Board w/ 20-pin Flat Cable
Note:
PCLD-786 does not include SSRs. They must be ordered by selecting single piece
SSR modules according to your requirements.
PCLM-OAC5A
Single Piece AC SSR Module (280 V
AC
, 3 A)
PCLM-ODC5
Single Piece DC SSR Module (60 V
DC
, 3 A)
General
Logic Side Connectors
Dimensions (L x W x H)
Ordering Information
PCLD-7216
16-ch SSR I/O Module Carrier Board
Note:
PCLD-7216 does not include SSRs. They must be ordered by selecting single piece SSR
modules according to your requirements.
Signal Conditioning Modules and Terminal Boards
