KD10 SERIES CONNECTORS
2.0mm (.079") Contact Spacing, Board-to-Multi Coaxial Connectors
• • • • • • • • • • • • • •
The KD10 Series is a small size multi coaxial connector suitable
for middle frequency range. Two versions are available: 50 ohms
and 75 ohms. The 50 ohms is ideally used for digital information
equipment, telecommunication, and calculation equipment, while
75 ohms is used in video movie, radio and multimedia equipment.
GENERAL SPECIFICATIONS
Number of Contacts
Characteristic Impedance
Frequency
VSWR
Insertion Loss
Current Rating
Dielectric Withstanding
Voltage
Insulation Resistance
Contact Resistance
Insertion Force
Withdrawal Force
Operating Temperature
Insertion/Withdrawal
1, 3, 5 and 8
50 ohms/75 ohms
DC 300 MHz
1.3 max. DC 300 MHz
0.3 dB/DC 300 MHz
250mAmps
250 VAC r.m.s. (for one minute)
100 megohms min. (with 10mm cable)
Initial (Center: 80 megohms max.
Outer 30 megohms max.)
One pin: 5N max.
Three pins: 10N max.
Five pins: 15N max. Eight pins: 20N max.
One pin: 2N max.
Three pins: 5N max.
Five pins: 7N max. Eight pins: 11N max.
-55°C to +85°C
50 times
FEATURES
• Low profile 6.1mm (.240") for minimized
mounting space
• Characteristic impedance of 50 ohms and
75 ohms
• Kinked hold-down allows connector to be fixed on
board during soldering
Connector Profile (Ref.)
11.5
(.453)
MATERIALS AND FINISHES
Description
Materials/Finishes
Glass-filled (6-6 Nylon)
Copper alloy, Gold over Nickel Plating
Copper alloy, Gold over Nickel Plating
Copper alloy, Tin Plating
6.1
(.240)
Insulator
Center Contact
Outer Contact
Hold-down
ORDERING INFORMATION
Cable Plug
KD10 – RRP
* – F – 0
KD10 – CA
** – 2PL – * *V
Receptacle
Series
Termination Right Angle
No. of Contacts
1, 3, 5, 8
Connector Type
Termination Style
Solder
Series
Cable Assembly
Cable Length
60-800mm – every 20 mm
Longer than 800mm – every 40mm
2 – Both ends harnessed
None – One end harnessed
No. of Contacts
1, 3, 5, 8
Characteristic Impedance
D – 50 ohms
C – 75 ohms
* Cable assemblies only available
Dimensions in mm (inches).
Dimensions and specifications subject to change without notice.
KD10 SERIES CONNECTORS
2.0mm (.079") Contact Spacing, Board-to-Multi Coaxial Connectors
RECEPTACLE–RIGHT ANGLE
1.3 (.051)
±
0.4 (.016)
PLUG (WITH CABLE)
9.6 (.378)
B
±
0.4 (.016)
2.5 (.098)
±
0.4 (.016)
±
0.4 (.016)
±
0.4 (.016)
5 (.197)
C
±
0.4 (.016)
2.3 (.091)
±
0.4 (.016)
PCB Hole Pattern
3.68 (.145)
3 (.118)
±
0.1 (.004)
±
0.1 (.004)
2 (079)
±
0.05 (.002)
4.78 (.188)
±
0.8 (.031)
2 (.079)
±
0.8 (.031)
3.54 (.140)
±
0.1 (.004)
10.35 (.408)
±
0.1 (.004)
A
7.3 (.287)
±
0.4 (.016)
D
±
0.4 (.016)
PCB Hole Pattern (Ref.)
ø0.8 (.031)
±
0.05 (.002)
E
±
0.1 (.004)
2 (.079)
±
0.05 (.002)
2 (079)
±
0.05 (.002)
7.3 (.287)
±
0.1 (.004)
Note 1: Plug side contacts are different for 50Ω & 75Ω.
Receptacle side is the same.
Note 2: Applicable Cable
50Ω: 0.8D–QEV
75Ω: 8CV-E41447
ø0.8 (.031)
±
0.05 (.002)
A
±
0.1 (.004)
2-ø2.2 (.087)
±
0.1 (.004)
No. of
Contacts
1
3
5
8
Receptacle
KD10-RRP-F-0
KD10-RRP3-F-0
KD10-RRP5-F-0
KD10-RRP8-F-0
Part Number
Plug with Cable
50Ω
75Ω
KD10-CA**-*PL-8DV
KD10-CA**-*PL-8CV
KD10-CA**-*PL3-8DV
KD10-CA**-*PL5-8DV
KD10-CA**-*PL8-8DV
KD10-CA**-*PL-8CV
KD10-CA**-*PL3-8CV
KD10-CA**-*PL3-8CV
A
B
±
0.4
(± .016)
C
±
0.4
(± .016)
D
E
5.15 ( .203)
13.15 ( .518)
21.15 ( .833)
33.15 (1.310)
6.7 ( .264)
14.7 ( .579)
22.7 ( .894)
34.7 (1.367)
2.8 ( .110)
10.8 ( .425)
18.8 ( .740)
30.8 (1.213)
3.54 ( .139)
11.54 ( .454)
19.54 ( .769)
31.54 (1.242)
2 ( .079)
10 ( .393)
18 ( .709)
30 (1.181)
** (1): Cable assemblies include connector length of 10mm (.039").
If you require 60-800mm (2.36-31.5") cable, you should select cable length every 20mm (.79").
For 840mm (33.1") and above, cable length is every 40mm (1.57").
* (2): Blank–harness on one side, 2–harness will be on both sides.
Dimensions in mm (inches).
