DR127-221

Description
General Purpose Inductor, 220uH, 20%, Iron-Core, 4947,
CategoryPassive components    inductor
File Size373KB,6 Pages
ManufacturerCoiltronics
Download Datasheet Parametric View All

DR127-221 Overview

General Purpose Inductor, 220uH, 20%, Iron-Core, 4947,

DR127-221 Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerCoiltronics
package instruction4947
Reach Compliance Codeunknown
uppercase and lowercase codes4947
structureMagnetic Shielding
core materialIron
DC Resistance0.376 Ω
Nominal inductance(L)220 µH
Inductor typeGENERAL PURPOSE INDUCTOR
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Package height8 mm
Package length12.5 mm
Package formSMT
Package width12.05 mm
method of packingTR
Maximum rated current2.43 A
seriesDR127
shieldYES
Tolerance20%
®
DR Series
High Power Density,
High Efficiency, Shielded Inductors
Description
• Four sizes of shielded drum core inductors
• Inductance range from 0.33uH to 1000uH
• Current range up to 56 Amps peak
• Frequency range up to 3MHz
• Magnetic shielding
• Secure mounting
Applications
• Computer, DVD players, and portable power devices
• LCD panels
• DC-DC converters
• Buck, boost, forward, and resonant converters
• Noise filtering and filter chokes
Environmental Data
• Storage temperature range: -40C to +125C
• Operating ambient temperature range: -40C to +85C
(range is application specific). The internal “hot-spot”
temperature defines the maximum allowable currents,
which are limited to 130C, including ambient.
• Infrared reflow temperature: +240C for 30 seconds max.
Part Number
DR73-R33
DR73-1R0
DR73-1R5
DR73-2R2
DR73-3R3
DR73-4R7
DR73-6R8
DR73-8R2
DR73-100
DR73-150
DR73-220
DR73-330
DR73-470
DR73-680
DR73-820
DR73-101
DR73-151
DR73-221
DR73-331
DR73-471
DR73-681
DR73-821
DR73-102
DR74-R33
DR74-1R0
DR74-1R5
DR74-2R2
DR74-3R3
DR74-4R7
DR74-6R8
DR74-8R2
DR74-100
DR74-150
DR74-220
Rated
Inductance
(µH)
0.33
1.00
1.50
2.20
3.30
4.70
6.80
8.20
10.0
15.0
22.0
33.0
47.0
68.0
82.0
100
150
220
330
470
680
820
1000
0.33
1.00
1.50
2.20
3.30
4.70
6.80
8.20
10.0
15.0
22.0
OCL
(1)
+/-20%
(µH)
0.306
0.992
1.482
2.070
3.540
4.422
6.480
8.930
10.30
15.01
22.65
34.41
48.62
68.91
80.37
101.4
150.9
223.3
325.5
465.8
676.5
821.7
995.0
0.294
0.952
1.422
1.986
3.396
5.182
7.344
8.566
9.882
16.09
21.73
Irms
(2)
Amperes
6.21
5.28
4.67
4.15
3.31
3.09
2.55
2.19
2.08
1.83
1.62
1.31
1.08
0.89
0.86
0.73
0.58
0.52
0.42
0.35
0.29
0.27
0.26
6.26
5.39
4.94
4.76
3.94
3.34
2.60
2.53
2.41
2.11
1.75
Packaging
• Supplied in tape and reel packaging, 1350 (DR73),
1100 (DR74), 600 (DR125), and 350 (DR127) per reel
Isat
(3)
Amperes
Peak
14.4
7.97
6.52
5.52
4.22
3.78
3.12
2.66
2.47
2.05
1.67
1.35
1.14
0.96
0.89
0.79
0.65
0.53
0.44
0.37
0.31
0.28
0.25
18.4
10.2
8.35
7.06
5.40
4.37
3.67
3.40
3.17
2.48
2.13
DCR
(4)
(Ω)
Typ.
0.0073
0.0102
0.0130
0.0165
0.0259
0.0297
0.0435
0.0592
0.0656
0.0844
0.107
0.166
0.241
0.358
0.384
0.527
0.851
1.05
1.59
2.36
3.47
3.93
4.34
0.0074
0.0099
0.0118
0.0126
0.0183
0.0254
0.0418
0.0441
0.0489
0.0637
0.0925
Volt-uSec
(5)
Typ.
1.98
3.56
4.36
5.15
6.73
7.52
9.11
10.7
11.5
13.9
17.0
21.0
24.9
29.7
32.1
36.0
44.0
53.5
64.5
77.2
93.1
103
113
1.71
3.08
3.76
4.45
5.81
7.18
8.55
9.23
9.92
12.7
14.7
(1) Open Circuit Inductance Test Parameters: 100KHz, 0.25Vrms, 0.0Adc.
(2) RMS current for an approximate
∆T
of 40°C without core loss. It is
recommended that the temperature of the part not exceed 125°C.
(3) Peak current for approximate 30% roll off at 20°C.
(4) DCR limits @ 20°C.
(5) Applied Volt-Time product (V-µS) across the inductor. This value represent the
applied V-µS at 100KHz necessary to generate a core loss equal to 10% of the
total losses for 40°C temperature rise.
