Agilent HSMx-C250
SMT ChipLEDs
Data Sheet
Features
• Directional light emission
• Available in multiple colors
(green, amber, orange, and red)
• Industrial standard footprint
• Compatible with automatic
placement equipment
• Compatible with IR solder reflow
Surface Mount ChipLEDs
ChipLEDs Part Numbers HSMG-C250,
HSMA-C250, HSMC-C250, HSML-C250, HSMM-C250
HSMN-C250, HSMU-C250, HSMV-C250, HSMZ-C250
Description
These solid state surface mount
LEDs are designed with a reflec-
tor cup which provides direc-
tional lighting. The reflector cup
focuses the light more efficiently
to provide about 60% higher in-
tensity and a narrower viewing
angle as compared to the non-
reflector cup equivalent part. This
makes the product excellent for
use with light pipe in backlighting
or status indication application.
The LED material of these parts
includes blue, high brightness
green, and very efficient AlInGaP
material which is capable of pro-
ducing high light output over a
wide range of driving current.
These ChipLEDs are shipped in
tape and reel with 3000 units per
reel.
In order to ensure light output
uniformity within one reel, all
parts are color and intensity
binned, except for red color.
They also come in industrial stan-
dard footprint and have a flat top
to make them compatible with
any automatic placement equip-
ment. The parts are compatible
with IR reflow.
• Available in 8 mm tape on 7"
diameter reel
• Excellent for backlighting and
coupling to light pipes
Applications
• Keypad backlighting
• Pushbutton backlighting
• LCD backlighting
• Symbol indicator
• Front panel indicator
CAUTION: HSMM-C250 and HSMN-C250 are CLass 1 ESD sensitive per MIL-STD-1686. Please
observe appropriate precautions during handling and processing. Refer to Agilent Technologies
Application Note AN-1142 for additional details.
Device Selection Guide
Part
Number
HSMG-C250
HSMA-C250
HSML-C250
HSMC-C250
HSMU-C250
HSMV-C250
HSMZ-C250
HSMM-C250
HSMN-C250
Color
Selection
LPE Green
AS AlInGaP Amber
AS AlInGaP Orange
AS AlInGaP Red
TS AlInGaP Amber
TS AlInGaP Reddish Orange
TS AlInGaP Red
InGaN Green
InGaN Blue
Package Dimension
(mm)
[1] [2]
3.2 (L) x 1.6 (W) x 0.8 (H)
3.2 (L) x 1.6 (W) x 0.8 (H)
3.2 (L) x 1.6 (W) x 0.8 (H)
3.2 (L) x 1.6 (W) x 0.8 (H)
3.2 (L) x 1.6 (W) x 0.8 (H)
3.2 (L) x 1.6 (W) x 0.8 (H)
3.2 (L) x 1.6 (W) x 0.8 (H)
3.2 (L) x 1.6 (W) x 0.8 (H)
3.2 (L) x 1.6 (W) x 0.8 (H)
Package
Description
Untinted, Diffused
Untinted, Diffused
Untinted, Diffused
Untinted, Diffused
Untinted, Diffused
Untinted, Diffused
Untinted, Diffused
Untinted, Diffused
Untinted, Diffused
Notes:
1. Dimensions in mm.
2. Tolerance
±
0.1 mm unless otherwise noted.
Absolute Maximum Ratings at T
A
= 25˚C
Parameter
DC Forward Current
[1]
Power Dissipation
Reverse Voltage (I
R
= 100
µA)
Led Junction Temperature
Operating Temperature Range
Storage Temperature Range
Soldering Temperature
Note:
1. Derate linearly as shown in Figure 4.
LPE and
AS AlInGaP
25
65
5
95
–30 to +85
–40 to +85
TS AlInGaP
25
66
5
95
–30 to +85
–40 to +85
InGaN
20
82
5
95
–30 to +85
–40 to +85
Units
mA
mW
V
˚C
˚C
˚C
See IR soldering profile (Figure 6)
3
Electrical Characteristics at T
A
= 25˚C
Forward Voltage
V
F
(Volts)
@ I
F
= 20 mA
Typ.
Max.
2.2
2.1
2.1
2.1
2.2
2.2
2.2
3.5
3.5
2.6
2.6
2.6
2.6
2.6
2.6
2.6
4.1
4.1
Reverse Breakdown
V
R
(Volts)
@ I
R
= 100
µB
Min.
5
5
5
5
5
5
5
5
5
Capacitance C
(pF), V
F
= 0,
f = 1 MHz
Typ.
[1]
8
9
22
15
30
30
30
53
50
Thermal
Resistance
Rθ
J–PIN
(˚C/W)
Typ.
350
350
350
350
350
350
350
350
350
Part Number
HSMG-C250
HSMA-C250
HSML-C250
HSMC-C250
HSMU-C250
HSMV-C250
HSMZ-C250
HSMM-C250
HSMN-C250
V
F
Tolerance:
±0.1
V.
Optical Characteristics at T
A
= 25˚C
Luminous
Intensity
I
V
(mcd)
@ 20 mA
[1]
Min.
Typ.
10
40
40
40
63
63
63
40
10
30
150
150
150
230
230
230
180
35
Peak
Wavelength
λ
peak
(nm)
Typ.
570
595
609
637
595
621
643
523
468
Color,
Dominant
Wavelength
λ
d[2]
(nm)
Typ.
572
592
605
626
592
615
631
525
470
Viewing
Angle
2
θ
1/2
Degrees
[3]
Typ.
120
120
120
120
120
120
120
120
120
Luminous
Efficacy
η
V
(lm/w)
Typ.
580
514
352
184
490
345
135
475
72
Part Number
HSMG-C250
HSMA-C250
HSML-C250
HSMC-C250
HSMU-C250
HSMV-C250
HSMZ-C250
HSMM-C250
HSMN-C250
Color
Green
AS Amber
AS Orange
AS Red
TS Amber
Reddish Orange
TS Red
InGaN Green
InGaN Blue
Notes:
1. The luminous intensity, I
V
, is measured at the peak of the spatial radiation pattern which may not be aligned with the mechanical axis of the lamp
package.
2. The dominant wavelength,
λ
d
, is derived from the CIE Chromatically Diagram and represent the perceived color of the device.
3.
θ
1/2
is the off-axis angle where the luminous intensity is 1/2 the peak intensity.
4
