REVISION AM
DO NOT
SCALE FROM
THIS PRINT
C
C1-A-DC
QSS-XXX-XX-XXX-D-RA-XX-XXX
"A"
"B" REF
.250 6.35 REF (TYP)
.250 6.35 MAX REF (TYP)
.006 0.15 REF
.560 14.22
REF
No OF POSITIONS
-025, -050, -075, *-100
(PER ROW)
(SEE NOTE 4)
*(SEE NOTE 12)
LEAD STYLE
-01: .062 BOARD
-02: .093 BOARD
PLATING SPECIFICATION
SEE TABLE 8, SHEET 6
ROW SPECIFICATION
-D: DOUBLE
(USE QSS-25-01-D-XX-RA)
.280 7.11 REF
C
L
OPTION
-LS1: LOCKING SCREW
(SEE FIG. 2, SHT 4)
(FOR MATING WITH
QTS-...-RA-..LS1)
-MTI: THREADED INSERT
(SEE FIG. 5, SHT 6)
-SP: SOLDER PIN
(NOT AVAILABLE
W/LS1 OPTION)
(USE SP-19-T)
(SEE FIG. 3, SHT 5)
-K: KAPTON PAD
(SEE FIG. 4, SHT 5)
(USE K-500-300)
-WT: WELD TAB
(SEE NOTE 4)
(USE WT-16-XX-T)
.1240 3.15 INSCRIBED
REF (TYP)
24 EQ SPACES
C
L
@ .0250[.635] =
.600 15.24
C
C2-F-MV
CONNECTOR TO
PCB MOUNTING
POINT (2 PLCS)
(SEE NOTE 10)
-RA: RIGHT ANGLE
.096 2.44 REF
.069 1.75 REF
.7838 19.91 REF
C
L
QSS-25-01-D-XX-RA
01
.186 4.71 REF
.245 6.22
REF
"E" REF
(SEE TABLE 2)
C
C15-A-MV
.328 8.33 REF
.012 0.30 REF
7 EQ SPACES @ .080[2.03] =
.560 14.22
C
C3-F-MV
.114±.003 2.89±0.08
(TYP) (SEE NOTE 4)
"C" REF
"D" REF
.025 0.64 SQ
REF (TYP)
(SEE NOTE 4)
02
.125 3.18 REF
NOTES:
1.
CX-X-XX
REPRESENTS A CRITICAL DIMENSION.
2. BURR ALLOWANCE: .0010 MAX.
3. MINIMUM PUSHOUT FORCE: 6 OZ.
4. WELD TABS (WT-16-XX-T) NOT AVAILABLE ON -025 POSITION.
WT OPTION MUST BE SELECTED FOR -050, -075 & -100 POSITIONS.
5. IF NEEDED, -L PLATING CAN BE SUBSTITUTED FOR -F PLATING.
6. IM-1G18-XX-1-XX RETENTION TO BE 1.0 LBS. MINIMUM PRIOR
TO SECOND ROW FILL.
7. DESIGNED FOR USE WITH A .062 OR .093 THICK PCB
8. ASSEMBLIES TO BE PACKAGED IN TRAYS.
9. NOTE DELETED
10. TORQUE TO BE 10.0 IN-OZ USING 4-40 UNC SCREW.
11. USE -Z- DATUM ZONE ONLY FOR MEASUREMENTS.
12. AVAILABLE FOR EXISTING CUSTOMERS ONLY.
(SOME CENTER DETAILS REMOVED FOR CLARITY)
QSS-075-01-XXX-D-RA-WT SHOWN
FIG 1
* = SEE NOTE 12
FREQUENCY
THIS SHEET
A
B
C
D
C1, C15
CPC
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
INSULATOR: LCP, COLOR: BLACK
TERMINAL, GROUND PLANE &
WELD TAB: PHOS BRONZE
F:\DWG\MISC\MKTG\QSS-XXX-XX-XXX-D-RA-XX-XXX-MKT.SLDDRW
.635mm DOUBLE ROW RIGHT ANGLE SOCKET STRIP
DWG. NO.
BY:
KEVIN B
QSS-XXX-XX-XXX-D-RA-XX-XXX
01/22/02
SHEET
1
OF
6
REVISION AM
-C-
.113 2.87
REF
* = SEE NOTE 12
C-178-02-XXX
(SEE TABLE 8, SHEET 6)
IM-1G18-XX-1-XXX
(SEE TABLE 4 & TABLE 8, SHEET 6)
C-177-01-XXX
(SEE TABLE 8, SHEET 6)
-C-
SEE TOP ROW-TAIL DETAIL
C8-B-MV
"F"
.1680±.0030 4.267±0.076
C4-B-MV
C-177-01-XXX
(SEE TABLE 8, SHEET 6)
.0040 0.102
C5-F-MV
C13-F-OG
.004±.002 0.10±0.05
(BOTTOM ROW)
(MEAS BOTH ENDS)
(SEE NOTE 11)
C6-B-MV
"F"
(SEE NOTE 4 & 11)
SEE TABLE 3
TOP ROW & BOTTOM ROW
(LOCATE ASSY ON DATUM -C-
FOR MEASUREMENT)
BOTTOM ROW - TAIL DETAIL
(LOCATE ASSEMBLY ON
DATUM -C- FOR MEASUREMENT)
SEE BOTTOM ROW-TAIL DETAIL
WT-16-XX-T
(SEE NOTE 4 )
(SEE TABLE 4)
C7-B-MV
C17-B,I-MV
C9-B-MV
"G"
(SEE NOTE 11)
.207 5.25 REF
(SEE NOTE 4)
.025 0.64 REF
.285 7.24 REF
.354 8.99 REF
.442 11.21 REF
.148 3.75
(SEE NOTE 4)
C21-B-MV
C12-B-MV
.040 1.02 REF
.010 0.25 REF
-C-
.004±.002 0.10±0.05
(TOP ROW)
(MEAS BOTH ENDS)
(SEE NOTE 11)
C11-B-MV
C-178-02-XXX
(SEE TABLE 8, SHEET 6)
30° TYP REF
.018 0.457
REF
TOP ROW - TAIL DETAIL
(LOCATE ASSEMBLY ON
DATUM -C- FOR MEASUREMENT)
FREQUENCY
THIS SHEET
A
C4, C6, C7,
C8,
B C11, C9,
C12,
C17, C21
CPC
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 6:1
DETAIL "F"
SCALE 10 : 1
.635mm DOUBLE ROW RIGHT ANGLE SOCKET STRIP
C
D
BY:
KEVIN B
F:\DWG\MISC\MKTG\QSS-XXX-XX-XXX-D-RA-XX-XXX-MKT.SLDDRW
QSS-XXX-XX-XXX-D-RA-XX-XXX
01/22/02
SHEET
2
OF
6
REVISION AM
Z1
-C-
INSPECTION VIEW 1
(FILL BOTTOM ROW)
Z2
.046 1.17
REF
.046 1.17 REF
Zx
-C-
C-177-01-XXX
(SEE TABLE 8, SHEET 6)
QSS-25-01-D-XX-RA
.285 7.24 (TYP)
C7-B-MV
C-177-01-XXX
(SEE TABLE 8, SHEET 6)
'G'
'H'
ISO VIEW OF
-Z- DATUM ZONE
SEE TABLE 3, SHT 2
WITHIN ROW
C10-REF
.285 7.24 REF
C7-REF
.004 0.10 REF
(BOTTOM ROW)
(SEE NOTE 11)
C8-REF
.004±.002 0.10±0.05
(BOTTOM ROW)
(SEE NOTE 11)
C8-B-MV
Z1
Z2
SEE TABLE 3, SHT 2
WITHIN ROW
C10-B,I-MV
(FILL BOTTOM ROW)
(SEE INSPECTION VIEW 1 FOR ORIENTATION AND CPC'S)
IN-PROCESS 1
-C-
DETAIL 'G'
SCALE 6 : 1
DETAIL 'H'
SCALE 6 : 1
.004±.002 0.10±0.05
(BOTTOM ROW)
(SEE NOTE 11)
C8-B-MV
IM-1G18-XX-1-XXX
(SEE TABLE 4, SHEET 2
& TABLE 8, SHEET 6)
INSPECTION VIEW 2
(FILL IM-1G18)
"G" REF
(SEE NOTE 11)
(SEE TABLE 4, SHEET 2)
C12-REF
Z1
-C-
Z2
.046 1.17 REF
C17-REF
.354 8.99 REF
.424 10.77 REF
.354 8.99
C17-B-MV
IM-1G18-XX-1-XXX
(SEE TABLE 4, SHEET 2
& TABLE 8, SHEET 6)
Z1
Z2
(FILL IM-1G18)
(SEE INSPECTION VIEW 2 FOR ORIENTATION AND CPC'S)
FREQUENCY
THIS SHEET
A
C7, C8,
B C10, C12,
C17
C
D
IN-PROCESS 2
CPC
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
"G"
(SEE TABLE 4, SHEET 2)
(SEE NOTE 11)
C12-B-MV
"G"
(SEE TABLE 4, SHEET 2)
(SEE NOTE 11)
C
C12-B-MV
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
.635mm DOUBLE ROW RIGHT ANGLE SOCKET STRIP
BY:
KEVIN B
QSS-XXX-XX-XXX-D-RA-XX-XXX
01/22/02
SHEET
3
OF
6
F:\DWG\MISC\MKTG\QSS-XXX-XX-XXX-D-RA-XX-XXX-MKT.SLDDRW
REVISION AM
INSPECTION VIEW 3
(FILL TOP ROW)
'J'
"E" REF (SEE TABLE 2, SHEET 1)
Z1
-C-
.442 11.21
C9-B-MV
Z2
.046 1.17 REF
"H" REF
C22-B-CP
'K'
C-178-02-XXX
(SEE TABLE 8, SHEET 6)
'L'
FIG 2
QSS-075-01-XXX-D-RA-WT-LS1 SHOWN
(SAME AS FIG. 1, EXCEPT AS SHOWN)
(SOME CENTER DETAILS REMOVED FOR CLARITY)
* = SEE NOTE 12
.1680 4.267
REF (TYP)
C4-REF
C-178-02-XXX
(SEE TABLE 8, SHEET 6)
C
C4-B-MV
.1700 4.318
SEE TABLE 3, SHT 2
WITHIN ROW
C24-REF
C11-B-MV
.004±.002 0.10±0.05
(TOP ROW)
(SEE NOTE 11)
DETAIL 'J'
SCALE 6 : 1
Z1
Z2
C24-B,I-MV
.442 11.21 REF
C18-REF
.004 0.10 REF
(TOP ROW)
(SEE NOTE 11)
C11-REF
SEE TABLE 3, SHT 2
WITHIN ROW
.004±.002 0.10±0.05
TOP ROW
(SEE NOTE 11)
C11-B-MV
(FILL TOP ROW)
(SEE INSPECTION VIEW 3 FOR ORIENTATION AND CPC'S)
FREQUENCY
THIS SHEET
A
C4, C9,
B C10, C11,
C22, C24
C
D
IN-PROCESS 3
CPC
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DETAIL 'K'
SCALE 6 : 1
DETAIL 'L'
SCALE 6 : 1
DO NOT SCALE DRAWING
SHEET SCALE: 1.5:1
.635mm DOUBLE ROW RIGHT ANGLE SOCKET STRIP
BY:
KEVIN B
QSS-XXX-XX-XXX-D-RA-XX-XXX
01/22/02
SHEET
4
OF
6
F:\DWG\MISC\MKTG\QSS-XXX-XX-XXX-D-RA-XX-XXX-MKT.SLDDRW
REVISION AM
QSS-075-01-XXX-D-RA-WT-SP SHOWN
(SAME AS FIG. 1, EXCEPT AS SHOWN)
(NOT AVAILABLE WITH LS1 OPTION)
(SOME CENTER DETAILS REMOVED FOR CLARITY)
FIG 3
QSS-25-01-D-XX-RA-SP
.055 1.40
C19-B-MV
.035 0.89 REF
SP-19-T
C
C23-B-MV
"B"
(SEE TABLE 1, SHEET 1)
.081 2.06 REF
-K OPTION
QSS-075-01-XXX-D-RA-WT-K SHOWN
(SAME AS FIG. 1, EXCEPT AS SHOWN)
(SOME CENTER DETAILS REMOVED FOR CLARITY)
FIG 4
.250 6.35 REF
.065±.010 1.65±0.25
.333 8.46 REF
"J"±.020 [0.51]
C16-B-MV
.790 20.07 REF
FREQUENCY
THIS SHEET
A
B C16, C19,
C23
C
CPC
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail info@SAMTEC.com
code 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 1:0.666667
.635mm DOUBLE ROW RIGHT ANGLE SOCKET STRIP
* = SEE NOTE 12
D
QSS-XXX-XX-XXX-D-RA-XX-XXX
01/22/02
SHEET
5
OF
6
BY:
KEVIN B
F:\DWG\MISC\MKTG\QSS-XXX-XX-XXX-D-RA-XX-XXX-MKT.SLDDRW
