INDUCTORS
First class electrical properties
High packing density
Flame retardant encapsulation
Applications include telecoms, automotive, industrial and
process control technology
SURFACE MOUNT INDUCTORS DCH
OUTLINE DRAWING
W
2
TAPING SPECIFICATION
IN ACCORDANCE WITH IEC 286-3
+0.15
12.75
-0
h
s
b
l
W
1
ø 62
±1.5
TAPING SPECIFICATION DIMENSIONS (MM)
Dimensions
mm
A
W1
W2
Pieces per reel
0603
178 ±2.0
9 ±0.3
-
4000
0805
178±2.0
9.2±0.8
14.4 max.
3000
Sizes/Types
1210
178±2.0
9.2±0.8
14.4 max.
2000
1812
330±2.0
13.2±0.8
18.4 max.
2500
SPECIFICATION
Case Size
Dimension
h
I
b
0603
0805
0.8±0.1
1.45max
1.6±0.1
2.20max
0.8±0.1
1.4max
Ceramic
Ceramic or Ferrite
±0.3nH(A)±5%(J)
Lead Free Tinned
Silver Palladium
IR, vapour phase, wave soldering
1210
1812
2.1±0.2
3.2±0.2
3.4±0.2
4.5±0.2
2.7±0.2
3.2±0.2
Ceramic or Ferrite
Ferrite
55/125/56
±5%(J)±10%(K)
Lead Free Tinned
Lead Free Tinned
Core Material
IEC climate category
Tolerances available
Terminals
Soldering
ORDERING INFORMATION
DCH
Range
1210
Case Size*
0603
0805
1210
1812*
150
Inductance
Code
K
Tolerance
J = 5%
*K = 10%
*Other case sizes available
122
Fax: 01371 875075
www.dubilier.co.uk
Tel: 01371 875758
Direction of unreeling
SECTION 3
A
INDUCTORS
SURFACE MOUNT INDUCTORS DCH
RANGE & SPECIFICATION 0603
Order Code
DCH06031N0*
DCH06031N5*
DCH06031N8*
DCH06032N2*
DCH06033N3*
DCH06034N7*
DCH06036N8*
DCH0603100*
DCH0603150*
DCH0603220*
DCH0603330*
DCH0603470*
DCH0603680*
DCH0603101*
DCH0603121*
DCH0603151*
DCH0603181*
DCH0603221*
nH
1.0
1.5
1.8
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
120
150
180
220
Quality Factor
(min)
7
8
12
14
14
14
14
14
14
14
14
14
14
14
5
5
4
4
Q. Typical
(@800MHz)
60
50
50
50
40
40
40
40
40
40
35
35
35
30
30
30
25
25
Measuring
Frequency (MHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
25.2
25.2
25.2
25.2
Rated Current
(Max)
1800
1500
1500
1500
1200
800
700
600
420
380
350
270
230
200
160
130
120
110
DC Resistance
max (Ω)
0.02
0.03
0.03
0.03
0.05
0.10
0.15
0.20
0.40
0.50
0.60
0.95
1.30
1.80
3.0
5.0
6.0
7.0
Resonance Frequency
(min) MHz
16000
13000
12000
10000
9000
7000
6000
5000
4500
4000
3000
2500
2000
1800
1800
1600
1400
1300
SECTION 3
RANGE & SPECIFICATION 0805
Order Code
DCH08055N6*
DCH08056N8*
DCH0805100*
DCH0805120*
DCH0805150*
DCH0805220*
DCH0805330*
DCH0805470*
DCH0805560*
DCH0805680*
DCH0805101*
DCH0805121*
DCH0805151*
DCH0805181*
DCH0805221*
DCH0805271*
DCH0805331*
DCH0805471*
DCH0805561*
DCH0805681*
DCH0805821*
DCH0805102*
DCH0805122*
DCH0805152*
DCH0805182*
DCH0805222*
DCH0805272*
DCH0805332*
DCH0805392*
DCH0805472*
nH
5.6
6.8
10
12
15
22
33
47
56
68
100
120
150
180
220
270
330
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
Quality Factor
(min)
25
30
40
40
40
45
45
45
45
45
40
40
35
35
35
35
35
35
35
20
20
20
20
20
20
20
20
20
20
20
Q. Typical
(@800MHz)
60
70
80
85
85
85
80
85
60
60
50
45
40
30
Measuring
Frequency (MHz)
250
250
250
250
250
250
250
200
200
200
150
150
100
100
100
100
100
100
100
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
Rated Current
(Max)
900
800
700
700
670
600
520
500
480
410
350
270
270
20
240
180
180
115
100
250
240
250
220
200
190
130
120
100
95
90
DC Resistance
max (Ω)
0.04
0.05
0.06
0.06
0.07
0.07
0.12
0.13
0.14
0.19
0.26
0.44
0.44
0.47
0.55
1.0
1.0
2.4
3.2
0.50
0.55
0.50
0.65
0.75
0.85
1.7
2.0
3.3
3.6
3.8
Resonance Frequency
(min) MHz
6000
5500
4500
4000
3500
2600
2150
1900
1700
1550
1310
1210
1120
1030
950
870
800
660
600
450
400
350
300
250
250
250
200
200
150
150
* Specify tolerance
123
Fax: 01371 875075
www.dubilier.co.uk
Tel: 01371 875758
INDUCTORS
SURFACE MOUNT INDUCTORS DCH
RANGE & SPECIFICATION 1210
Order Code
DCH1210100*
DCH1210150*
DCH1210220*
DCH1210330*
DCH1210470*
DCH1210560*
DCH1210680*
DCH1210101*
DCH1210151*
DCH1210221*
DCH1210331*
DCH1210471*
DCH1210561*
DCH1210681*
DCH1210102*
DCH1210122*
DCH1210152*
DCH1210182*
DCH1210222*
DCH1210272*
DCH1210332*
DCH1210392*
DCH1210472*
DCH1210562*
DCH1210682*
DCH1210103*
DCH1210123*
DCH1210153*
DCH1210183*
DCH1210223*
DCH1210333*
DCH1210473*
DCH1210563*
DCH1210683*
DCH1210104*
DCH1210124*
DCH1210154*
DCH1210184*
DCH1210224*
DCH1210272*
DCH1210334*
µH
0.010
0.015
0.022
0.033
0.047
0.056
0.068
0.10
0.15
0.22
0.33
0.47
0.56
0.68
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
10
12
15
19
22
33
47
56
68
100
120
150
180
220
270
330
Quality Factor
(min)
15
19
23
25
26
26
27
28
30
30
30
30
30
30
30
30
30
30
30
30
30
30
30
27
27
27
27
27
27
27
27
27
27
27
20
20
20
20
20
20
20
Measuring
Frequency (MHz)
100
100
100
100
100
100
100
100
25.2
25.2
25.2
25.2
25.2
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
Rated Current
(Max)
450
450
450
450
450
450
450
450
450
450
450
450
450
450
400
390
370
350
320
290
260
250
220
200
180
150
140
130
120
110
70
60
60
60
60
60
50
50
45
40
40
DC Resistance
max (Ω)
0.10
0.13
0.16
0.18
0.20
0.21
0.23
0.31
0.18
0.20
0.23
0.30
0.31
0.34
0.60
0.70
0.70
0.80
0.80
0.90
1.20
1.30
1.50
1.60
1.80
2.10
2.50
2.80
3.0
3.5
5.6
7.0
8.0
9.0
11.0
12.0
17.0
18.0
22.0
28.0
34.0
Resonance Frequency
(min) MHz
4000
3000
2000
1700
1300
1100
1000
900
700
500
500
400
300
300
300
250
200
140
100
70
60
60
50
45
40
30
25
20
20
20
17
15
12
9
8
8
7
7
6
5
4
SECTION 3
RANGE & SPECIFICATION 1812
Order Code
DCH1812104*
DCH1812224*
DCH1812334*
DCH1812474*
DCH18121058
µH
100
220
330
470
1000
Quality Factor
(min)
20
20
20
20
20
Measuring
Frequency (MHz)
0.796
0.796
0.796
0.796
0.252
Rated Current
(Max)
200
130
120
100
70
DC Resistance
max (Ω)
3.50
7.50
11.0
15.0
30.0
Resonance Frequency
(min) MHz
6.5
4.5
4.1
3.5
2.3
124
Fax: 01371 875075
www.dubilier.co.uk
Tel: 01371 875758
