CAPACITORS
NPO, X7R & Z5U dielectric
10pF - 1µF
50/63V, 100V & 200V
Enhanced environmental protection coating
50V, 100V rated voltage
Variety of lead configuration
The DR multi-layer ceramic offers small size in a wide range of formats, including
2.54mm & 5mm pitch, loose & taped packaging.
Small value close-tolerance parts are suitable for radio and instrumentation circuits.
Temperature
The range also extends to high-capacity decoupling values.
Temperature Coefficient
SECTION 1
Style
DR 15
DR 20
DR 21
DR 30
CERAMIC MULTI-LAYER RADIAL DR
-55 to 125°C (-25 to +85°C for Y5V)
NPO: Zero ± 30ppm/°C
X7R: ± 15% max Z5U: +22%, -56%
SIZE CODE & CAPACITANCE (pF) AVAIL.
Size Code
DR 15
DR 20/21
DR 30
DR30X
WVDC
COG
X7R
Z5U
63V
10-560
270-18000
10000-47000
100V
10-390
270-10000
680-10000
63V
-
1000 - 100000 10000-470000
100V
10-4700
1000 - 100000
-
63V
-
100000-330000 470000-1000000
100V 4700-10000
-
-
63V
-
470000-1000000
-
DR15
W
H
OUTLINE DRAWING
DR20
W
H
DR21
W
H
L 31.7
L 31.7
L 31.7
DR30
W
F
W
H
H
L
L 31.7
16.5 min
T
Other lead variations
available upon request
SIZE CODE & DIMENSIONS
Size Code
DR 15
DR 20
DR 21
DR 30
Width
W Max
3.81
5.08
5.08
7.62
Height
H Max
3.81
5.08
5.08
7.62
Thickness
T Max
3.18
3.18
3.18
3.81
Lead Spacing
F
2.54 ± 1.0
2.54 ± 1.0
5.08 ± 1.0
5.08 ± 1.0
F
(0.5)
229
Special lead length available
356
Unit of dimension mm
330
46
5 nom
PACKING QUANTITY
Lead
Spacing
2.54
2.54
5.08
5.08
Taped Components
Qty per Heel
Qty per Box
3000
3000
3000
3000
3000
3000
2500/2000
2500
45
TAPING, REEL & BOX DIMENSIONS (mm)
12.7 nom
16.5 min
19±0.5
356
18±0.5
46
5 nom
4±0.2
12.7±0.2
45
ORDERING INFORMATION
16.5 min
12.7 nom
229
356
19±0.5
DR
Range
U
Voltage
U = 50
A = 100
F = 200
E = 25
C = 16
1
Size code
C
Dielectric
C = COG
R = X7R
W = Z5U
10
Value
102 = 1000PF
J
Tol
C = 0.25PF
D = 0.50PF
J = 5.0%
K = 10%
M= 20%
Z = 20% + 80%
B
Pitch
TA
Taping
A = 2.54
TA = Tape
46
B = 5.08
5 nom
Ammo
TR = Tape
Reel
Blank =
12.7 nom
Loose
19±0.5
330
4±0.2
12.7±0.2
18±0.5
45
Fax: 01371 875075
www.dubilier.co.uk
Tel: 01371 875758
18±0.5
