HYMD132G725BL4-H

Description
Registered DDR SDRAM DIMM
Categorystorage    storage
File Size308KB，17 Pages
ManufacturerSK Hynix
Websitehttp://www.hynix.com/eng/
Download Datasheet Parametric Compare View All

HYMD132G725BL4-H Overview

Registered DDR SDRAM DIMM

HYMD132G725BL4-H Parametric

Parameter NameAttribute value
MakerSK Hynix
Parts packaging codeDIMM
package instructionDIMM, DIMM184
Contacts184
Reach Compliance Codecompli
ECCN codeEAR99
access modeFOUR BANK PAGE BURST
Maximum access time0.75 ns
Other featuresAUTO/SELF REFRESH
Maximum clock frequency (fCLK)133 MHz
I/O typeCOMMON
JESD-30 codeR-XDMA-N184
length133.35 mm
memory density2415919104 bi
Memory IC TypeDDR DRAM MODULE
memory width72
Number of functions1
Number of ports1
Number of terminals184
word count33554432 words
character code32000000
Operating modeSYNCHRONOUS
Maximum operating temperature70 °C
Minimum operating temperature
organize32MX72
Output characteristics3-STATE
Package body materialUNSPECIFIED
encapsulated codeDIMM
Encapsulate equivalent codeDIMM184
Package shapeRECTANGULAR
Package formMICROELECTRONIC ASSEMBLY
power supply2.5 V
Certification statusNot Qualified
refresh cycle4096
Maximum seat height3.99 mm
self refreshYES
Maximum standby current0.92 A
Maximum slew rate5.33 mA
Maximum supply voltage (Vsup)2.7 V
Minimum supply voltage (Vsup)2.3 V
Nominal supply voltage (Vsup)2.5 V
surface mountNO
technologyCMOS
Temperature levelCOMMERCIAL
Terminal formNO LEAD
Terminal pitch1.27 mm
Terminal locationDUAL
width43.18 mm

Preview

Download Datasheet
32Mx72 bits
Registered DDR SDRAM DIMM
HYMD132G725B(L)4-M/K/H/L
DESCRIPTION
Hynix HYMD132G725B(L)4-M/K/H/L series is registered 184-pin double data rate Synchronous DRAM Dual In-Line
Memory Modules (DIMMs) which are organized as 32Mx72 high-speed memory arrays. Hynix HYMD132G725B(L)4-M/
K/H/L series consists of eighteen 32Mx4 DDR SDRAM in 400mil TSOP II packages on a 184pin glass-epoxy substrate.
Hynix HYMD132G725B(L)4-M/K/H/L series provide a high performance 8-byte interface in 5.25" width form factor of
industry standard. It is suitable for easy interchange and addition.
Hynix HYMD132G725B(L)4-M/K/H/L series is designed for high speed of up to 133MHz and offers fully synchronous
operations referenced to both rising and falling edges of differential clock inputs. While all addresses and control
inputs are latched on the rising edges of the clock, Data, Data strobes and Write data masks inputs are sampled on
both rising and falling edges of it. The data paths are internally pipelined and 2-bit prefetched to achieve very high
bandwidth. All input and output voltage levels are compatible with SSTL_2. High speed frequencies, programmable
latencies and burst lengths allow variety of device operation in high performance memory system.
Hynix HYMD132G725B(L)4-M/K/H/L series incorporates SPD(serial presence detect). Serial presence detect function is
implemented via a serial 2,048-bit EEPROM. The first 128 bytes of serial PD data are programmed by Hynix to identify
DIMM type, capacity and other the information of DIMM and the last 128 bytes are available to the customer.
FEATURES
•
•
•
•
•
•
•
256MB (32M x 72) Registered DDR DIMM based on
32Mx4 DDR SDRAM
JEDEC Standard 184-pin dual in-line memory module
(DIMM)
Error Check Correction (ECC) Capability
Registered inputs with one-clock delay
Phase-lock loop (PLL) clock driver to reduce loading
2.5V +/- 0.2V VDD and VDDQ Power supply
All inputs and outputs are compatible with SSTL_2
interface
•
•
•
•
•
•
•
Fully differential clock operations (CK & /CK) with
100MHz/125MHz/133MHz
Programmable CAS Latency 2 / 2.5 supported
Programmable Burst Length 2 / 4 / 8 with both
sequential and interleave mode
tRAS Lock-out function supported
Internal four bank operations with single pulsed RAS
Auto refresh and self refresh supported
4096 refresh cycles / 64ms
ORDERING INFORMATION
Part No.
HYMD132G725B(L)4-M
HYMD132G725B(L)4-K
HYMD132G725B(L)4-H
HYMD132G725B(L)4-L
V
DD
=2.5V
V
DDQ
=2.5V
Power Supply
Clock Frequency
133MHz (*DDR266:2-2-2)
133MHz (*DDR266A)
133MHz (*DDR266B)
125MHz (*DDR200)
Interface
Form Factor
SSTL_2
184pin Registered DIMM
5.25 x 1.7 x 0.15 inch
* JEDEC Defined Specifications compliant
This document is a general product description and is subject to change without notice. Hynix Semiconductor does not assume any
responsibility for use of circuits described. No patent licenses are implied.
Rev. 0.3/May. 02
1
