B520B Overview

SCHOTTKY BARRIER RECTIFIERS

Preview

Download Datasheet

View All

Compact Technology

B520B thru B5200B

REVERSE VOLTAGE -

200

Volts

FORWARD CURRENT -

5.0

Ampere

SCHOTTKY BARRIER RECTIFIERS

FEATURES

Metal-Semiconductor junction with guard ring

Epitaxial construction

Low forward voltage drop

High current capability

The plastic material carries UL recognition 94V-0

For use in low voltage,high frequency inverters,free

wheeling,and polarity protection applications

SMB

DIM.

MIN.

4.06

3.30

1.91

0.15

5.08

0.05

2.13

0.76

MAX.

4.70

3.94

2.11

0.31

5.59

0.20

2.44

1.52

MECHANICAL DATA

Case : SMB , molded plastic

Polarity : Color band denotes cathode

Weight : 0.095 grams

Mounting position : Any

All Dimensions in millimeter

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25 ambient temperature unless otherwise specified.

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitive load, derate current by 20%

1of2

B520B

thru

B5200B
