STANDARD POWER INDUCTORS - THRU HOLE
DB2
DB2LF
*
PART
NUMBER
TRADITIONAL
Pb
COMPLIANT
RoHS
Wirewound, Power Line Choke, Radial
L µH
@ 1 kHz
DCR
OHMS
MAX
SATURATION
CURRENT
A DC
FERRITE CORE
58.0
50.0
50.0
44.0
39.0
36.0
30.0
27.0
25.0
22.0
21.0
20.5
18.6
17.0
15.1
13.6
12.7
11.3
10.4
9.4
8.6
7.8
7.6
7.0
6.5
6.3
5.2
4.9
4.5
4.1
3.7
3.4
3.1
2.7
2.4
2.2
2.0
CURRENT
RATING
A DC
15.1
15.1
15.1
15.1
13.1
13.1
11.7
11.4
9.0
7.2
7.2
5.8
5.6
5.5
5.5
5.5
4.8
4.8
4.0
4.0
4.0
4.0
3.0
2.8
2.4
2.1
2.0
1.9
1.8
1.6
1.6
1.3
1.2
1.1
0.96
0.83
0.80
E
DIM
DIMENSIONS
LEAD
DIAMETER
0.0720 (1.83)
0.0720 (1.83)
0.0720 (1.83)
0.0720 (1.83)
0.0720 (1.83)
0.0720 (1.83)
0.0641 (1.63)
0.0571 (1.45)
0.0508 (1.29)
0.0508 (1.29)
0.0453 (1.15)
0.0403 (1.02)
0.0403 (1.02)
0.0403 (1.02)
0.0403 (1.02)
0.0403 (1.02)
0.0403 (1.02)
0.0359 (0.91)
0.0320 (0.81)
0.0320 (0.81)
0.0320 (0.81)
0.0320 (0.81)
0.0285 (0.72)
0.0285 (0.72)
0.0285 (0.72)
0.0285 (0.72)
0.0285 (0.72)
0.0253 (0.64)
0.0253 (0.64)
0.0226 (0.57)
0.0226 (0.57)
0.0201 (0.51)
0.0201 (0.51)
0.0201 (0.51)
0.0179 (0.45)
0.0159 (0.40)
0.0159 (0.40)
DB2-331†
3.3
0.003
DB2-391†
3.9
0.003
DB2-471†
4.7
0.003
DB2-561†
5.6
0.003
DB2-681†
6.8
0.004
DB2-821†
8.2
0.004
DB2-102
10
0.005
DB2-122
12
0.007
DB2-152
15
0.009
DB2-182
18
0.013
DB2-222
22
0.014
DB2-272
27
0.020
DB2-332
33
0.022
DB2-392
39
0.026
DB2-472
47
0.026
DB2-562
56
0.031
DB2-682
68
0.036
DB2-822
82
0.044
DB2-103
100
0.060
DB2-123
120
0.067
DB2-153
150
0.075
DB2-183
180
0.090
DB2-193
190
0.110
DB2-223
220
0.114
DB2-253
250
0.135
DB2-273
270
0.155
DB2-333
330
0.175
DB2-393
390
0.195
DB2-473
470
0.209
DB2-563
560
0.300
DB2-683
680
0.399
DB2-823
820
0.445
DB2-104
1000
0.484
DB2-124
1200
0.550
DB2-154
1500
0.746
DB2-184
1800
0.985
DB2-224
2200
1.149
All part numbers provide 10% tolerance on inductance
† Provide 20% tolerance on inductance
Custom designs are available to meet your specific requirements; please contact factory
0.650 (16.51)
0.650 (16.51)
0.650 (16.51)
0.650 (16.51)
0.675 (17.15)
0.675 (17.15)
0.630 (16.00)
0.630 (16.00)
0.630 (16.00)
0.630 (16.00)
0.600 (15.24)
0.600 (15.24)
0.600 (15.24)
0.600 (15.24)
0.600 (15.24)
0.600 (15.24)
0.600 (15.24)
0.600 (15.24)
0.580 (14.73)
0.580 (14.73)
0.580 (14.73)
0.580 (14.73)
0.580 (14.73)
0.580 (14.73)
0.580 (14.73)
0.580 (14.73)
0.600 (15.24)
0.600 (15.24)
0.600 (15.24)
0.570 (14.49)
0.570 (14.49)
0.570 (14.49)
0.570 (14.49)
0.570 (14.49)
0.570 (14.49)
0.570 (14.49)
0.570 (14.49)
*Add “LF” suffix for RoHS requirement. Example: DB2-331LF
E
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
NOTES:
LEAD DIA
E
0.800
(20.32)
MAX
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 35°C temperature
rise at an ambient temperature of 90°C
• Saturation Current is the approximate value that
will cause a 10% drop in inductance as
indicated in the table
• Leads tinned to within 0.062 in. of body
• Epoxy-insulated core
in. (mm)
0.135
(3.43)
LEAD DIA
0.800
(20.32)
MAX
0.500
±
0.062
(12.7
±
1.57)
0.825
(20.96) MAX
PACKAGING SPECS:
Bulk only
0.135
(3.43)
*LEADS TINNED TO WITHIN .062 OF BODY
