R1162x Series
150mA LDO with ECO pin
The R1162x Series are CMOS-based LDO regulators with ECO pin featuring 150mA output. By inputting control signals from the ECO
pin, the mode of the regulator can be switched to low power mode or fast response mode, thus making both active and sleep modes
available for the system. The CE pin can switch the regulator into standby mode. The version with the auto-discharge function is also
available. Ceramic capacitors can be used.
FEATURES
•
Supply Current (I
SS1
) ·······················Typ. 70μA (Fast mode, V
IN
=SET V
OUT
+1V)
•
Supply Current (I
SS2
) ·······················Typ. 5.5μA (Low power mode, same as above)
•
Standby Current (I
standby
) ·················Typ. 0.1μA (Same as above, CE="L")
•
Dropout Voltage (V
DIF
) ····················Typ. 0.25V (Fast mode, I
OUT
=150mA, V
OUT
=2.8V)
•
•
•
Typ. 0.25V (Low power mode, I
OUT
=150mA, V
OUT
=2.8V)
Ripple Rejection (RR)·····················Typ. 70dB (f=1kHz, Fast mode)
Input Voltage Range (V
IN
) ···············2.0V to 6.0V
Output Voltage Range (V
OUT
)··········1.5V to 4.0V (internally fixed)
•
Output Voltage Accuracy ················± 2% (Fast mode)
•
•
•
•
•
•
±
3% (Low power mode)
Temp. coeff. of Output Voltage ·······Typ.
±
100ppm/°C
Line Regulation·······························Typ. 0.02%/V (Fast mode)
Fold-back Protection Circuit············Current limit Typ. 40mA
Auto-Discharge function ·················D Version
Packages ········································SON1612-6, SOT-23-5
Ceramic Capacitor can be used. ····C
IN
=1.0μF or more,
C
OUT
=0.47μF or more
BLOCK DIAGRAMS
R1162xxx1B
(Without Auto-Discharge function)
ECO
V
DD
V
OUT
V
DD
R1162xxx1D
(With Auto-Discharge function)
ECO
V
OUT
Vref
Current Limit
Vref
Current Limit
CE
GND
CE
GND
SELECTION GUIDES
Package
SON1612-6
SOT-23-5
Quantity per Reel
Part No.
4,000 pcs
R1162D.xx.1.
∗
-TR-F
3,000 pcs
R1162N.xx.1.
∗
-TR-F
.xx.
: Specify the output voltage with the range 1.5V (.15.) to 4.0V (.40.)
in 0.1V steps.
: Select from (.B.) without auto-discharge function or
.∗
(.D.) with auto-discharge function.
PACKAGES (Top View)
SON1612-6
6
5
4
5
4
TYPICAL CHARACTERISTIC
SOT-23-5
R1162x281x
Dropout Voltage vs. Output Current
(Fast Response Mode)
ECO=H
85°C
25°C
-40°C
0.30
Dropout Voltage V
DIF
(V)
0.25
0.20
0.15
0.10
0.05
0
0
1
2
3
1
2
3
1
2
3
4
5
6
CE
GND
V
DD
V
OUT
GND
ECO
1
2
3
4
5
V
DD
GND
CE
ECO
V
OUT
25
50
75
100 125
Output Current I
OUT
(mA)
150
APPLICATIONS
•
Power source for hand-held communication equipment, cameras, and VCRs
•
Power source for battery-powered equipment
•
Very stable voltage reference
