SLIM-PAC
TM
Single Phase
Rectifier Bridge
Preliminary Data Sheet
V
RSM
V
DSM
(V)
700
900
1300
1500
1700
V
RRM
V
DRM
(V)
600
800
1200
1400
1600
Type
PSB 53
I
dAV
V
RRM
+
= 54 A
= 600-1600 V
PSB 53/06
PSB 53/08
PSB 53/12
PSB 53/14
PSB 53/16
~
A
~N
K
-
Features
Symbol
I*
dAV
I
FSM
Test Conditions
T
C
= 100 °C, (per module)
T
VJ
= 45 °C
V
R
= 0
T
VJ
= T
VJM
V
R
= 0
T
VJ
= 45 °C
V
R
= 0
T
VJ
= T
VJM
V
R
= 0
Maximum Ratings
54
300
320
260
280
450
425
340
325
A
A
A
A
A
A²s
A²s
A²s
A²s
°C
°C
°C
V
∼
Nm
lb.in.
g
V
∼
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
•
•
•
•
•
•
Package with DCB ceramic base plate
Isolation voltage 3000 V
∼
Planar glass passivated chips
Low forward voltage drop
Leads suitable for PC board
soldering
UL registered, E 148688
∫
i
2
dt
Applications
T
VJ
T
VJM
T
stg
V
ISOL
M
d
-40... + 150
150
-40... + 125
50/60 Hz, RMS t = 1 min
I
ISOL
≤
1 mA
Mounting torque
typ.
t=1s
(M4)
2500
3000
1.5 - 1.8
14 - 16
10
•
•
•
•
Supplies for DC power equipment
Input rectifier for PWM inverter
Battery DC power supplies
Field supply for DC motors
Advantages
Weight
•
•
•
•
•
Easy to mount with two screws
Space and weight savings
Improved temperature and power
cycling capability
High power density
Small and light weight
Symbol
I
R
V
F
V
TO
r
T
R
thJC
R
thJK
d
s
d
A
a
Test Conditions
V
R
= V
RRM,
T
VJ
= T
VJM
V
R
= V
RRM,
T
VJ
= 25°C
I
F
= 55 A,
T
VJ
= 25 °C
For power-loss calculations only
per diode; DC
per module
per diode; DC
per module
Creeping distance on surface
Creeping distance in air
Max. allowable acceleration
Characteristic Value
≤
≤
≤
3.0
0.5
1.46
0.8
13
1.1
0.28
1.6
0.4
11.2
9.7
50
mA
mA
V
V
m
Ω
K/W
K/W
K/W
K/W
mm
mm
m/s²
Package style and outline
Dimensions in mm (1mm = 0.0394“)
R2,15
R0,75
0,5
11,0
+-0,2
Data according to IEC 60747 refer to a single diode unless otherwise stated
*- for resistive load at bridge output
1
39
0,2
47
+-0,2
5
POWERSEM GmbH, Walpersdorfer Str. 53
D - 91126 Schwabach
Phone: 09122 - 9764 - 0 FAX: 09122 - 9764 - 20
2006 POWERSEM reserves the right to change limits, test conditions and dimensions
18
-0,3
0,3
21,6
+-0,3
0,2
30,3
+-0,2
+ 0,3
