SN74ALS466AN3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> SN74ALS466AN3

SN74ALS466AN3: DescriptionALS SERIES, 8-BIT DRIVER, INVERTED OUTPUT, PDIP20; Categorylogic logic; File Size809KB，7 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric Compare View All

SN74ALS466AN3 Overview

ALS SERIES, 8-BIT DRIVER, INVERTED OUTPUT, PDIP20

SN74ALS466AN3 Parametric

Parameter Name	Attribute value
Maker	Rochester Electronics
package instruction	DIP,
Reach Compliance Code	unknown
Other features	WITH DUAL OUTPUT ENABLE
series	ALS
JESD-30 code	R-PDIP-T20
length	24.325 mm
Logic integrated circuit type	BUS DRIVER
Number of digits	8
Number of functions	1
Number of ports	2
Number of terminals	20
Maximum operating temperature	70 °C
Minimum operating temperature
Output characteristics	3-STATE
Output polarity	INVERTED
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
propagation delay (tpd)	9 ns
Certification status	COMMERCIAL
Maximum seat height	5.08 mm
Maximum supply voltage (Vsup)	5.5 V
Minimum supply voltage (Vsup)	4.5 V
Nominal supply voltage (Vsup)	5 V
surface mount	NO
technology	TTL
Temperature level	COMMERCIAL
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	7.62 mm
