REVISION B
DO NOT
SCALE FROM
THIS PRINT
FIG. 1
MMTD-06-20-X-X-XX.XX-S SHOWN
C1-A-DC
MMTXX-XX-XX-X-X-XX.XX-X-XXX
B
ROW OPTION
-D: DOUBLE
-S: SINGLE (SEE SHT 3, FIG. 4)
PTFE CABLE OPTION
-T: PTFE
(LEAVE BLANK FOR
STANDARD PVC INSULATION)
No OF POSITIONS
-02 THRU -25 (PER ROW)
WIRE GAUGE (AWG)
-20, -22, -24, -26, -28, -30
PTFE: -24,-28,-30
COLOR CODE
-C (SEE TABLE 2)
(LEAVE BLANK FOR
STANDARD BLACK CABLE)
(NOT AVAILABLE WITH PTFE OPTION)
PLATING SPECIFICATION
-F: FLASH SELECTIVE (USE T-1M74-XX-F)
-L: LIGHT SELECTIVE (USE T-1M74-XX-L)
-S: SELECTIVE (USE T-1M74-XX-S)
OPTION
[MUST BE USED ON -D END OPTION ONLY
& APPLIES TO END 2 HOUSING]
-TUS: TRANSFER LATCH UP, STRAIGHT
(SEE FIG.2, SHEET 2)
-TDS: TRANSFER LATCH DOWN, STRAIGHT
(SEE FIG.3, SHEET 2)
01 02
(NO OF POS X.100 [2.54])
+.070 [1.78] REF
C2-A-DC
.300 7.62 REF
'C'
"A"
IPM1-06-D
END OPTION
-S: SINGLE END
-D: DOUBLE END(MUST CHOOSE TUS OR TDS OPTIONS.)
ASSEMBLED LENGTH
SPECIFY IN INCHES [USE DWCX-XX-XX]
(SINGLE END: 03.00[76.2] INCH MINIMUM,
DOUBLE END: 03.25[82.6] INCH MINIMUM)
C3-A-DC
.690 17.53 REF
"A"
.020 0.51
REF
C4-B-GR
XX.XX
C
(SEE NOTE 10)
.035 0.89 REF
'B'
.035 0.89 REF
DETAIL 'C'
SCALE 8 : 1
DWCX-XX-XX
.004 0.10 REF
(SEE NOTE 5)
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. NOTE DELETED
3. NOTE DELETED
4. MINIMUM PULLOUT FORCE: 0.5 lbs [2.22 N].
C
5. CONTACT MUST BE INSERTED UNTIL RETENTION FEATURE LOCKS
INTO PLACE.
C
6. ALL FINISHED GOODS ARE TO BE ELECTRICAL TESTED INCLUDING
HI-POT TEST @ 1000 VOLTS DC.
7. TINNED COPPER WIRE CONTAINS LEAD.
8. PARTS ARE TO BE LAYER PACKAGED.
9. MMTX: SEE DWL-12-XX-X-XX.XX-XX-XX FOR CRIMP DIMENSIONS.
C6-B-MM
MMTXT: SEE DWLT-12-XX-X-XX.XX-XX-XX.
10. FOR LENGTHS LESS THAN 12 IN[304.8], TOLERANCE SHALL BE ±.125[3.18].
FOR OTHER LENGTHS, TOLERANCES SHALL BE ± 2%.
DETAIL 'B'
SCALE 8 : 1
SECTION "A"-"A"
SCALE 4 : 1
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
ANGLES
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
MATERIAL:
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Ma il: info @SAMTEC.c o m
c o d e: 55322
DESCRIPTION:
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
HOUSING: NYLON 6/6, COLOR: WHITE
CONTACT: PHOS BRONZE
CABLE: INSULATION: SEE CALLOUT
WIRE: TINNED COPPER
c:\enterprisevault\DWG\MISC\MKTG\MMTXX-XX-XX-X-X-XX.XX-X-XXX-MKT.SLDDRW
.100[2.54] TERMINAL DISCRETE CABLE ASSEMBLY
DWG. NO.
MMTXX-XX-XX-X-X-XX.XX-X-XXX
BY:
D. SCHMELZ 12/04/2008
SHEET
1
OF
3
REVISION B
C
C5-B-GR
XX.XX
(SEE NOTE 10)
LTC-14-01-N
IPD1-06-X-K-R
C9-A-DC
.618 15.70
REF
END 1
END 2
END 1
+.010
END 2
"A"
- .005
+.003
+0.076
.107
- .002
2.71
- 0.051
C7-B-CP
C8-B-CP
FIG.2
-TUS
(TRANSFER,LATCH UP, STRAIGHT)
(SAME AS FIG.1 UNLESS OTHERWISE STATED)
FIG.3
-TDS
(TRANSFER,LATCH DOWN, STRAIGHT)
(SAME AS FIG.2, UNLESS OTHERWISE STATED)
TABLE 1
SERIES
MMTXX
MMTXX
MMTXX
MMTXX
MMTXX
MMTXX
MMTXT
MMTXT
MMTXT
WIRE GAUGE
20 AWG
22 AWG
24 AWG
26 AWG
28 AWG
30 AWG
24AWG
28AWG
30AWG
CABLE
DWC-20-XX-300
DWC-22-XX-300
DWC-24-XX-300
DWC-26-XX-300
DWC-28-XX-300
DWC-30-XX-300
DWCT-24-XX
DWCT-28-XX
DWCT-30-XX
TERMINAL
T-1M74-02-X
T-1M74-02-X
T-1M74-02-X
T-1M74-01-X
T-1M74-01-X
T-1M74-01-X
T-1M74-02-X
T-1M74-03-X
T-1M74-03-X
CONTACT
C-179-03-X
C-179-03-X
C-179-03-X
C-179-02-X
C-179-02-X
C-179-02-X
C-179-03-X
C-179-04-X
C-179-04-X
ROW
MMTDX
MMTSX
TABLE 3
IPD1-XX-X-K-R
IPD1-XX-D-K-R
IPD1-XX-S-K-R
"A"
.260[6.60]
.160[4.06]
TABLE 2
MMTXX COLOR CODED WIRE SEQUENCE
COLOR
BROWN
1
11
21
31
41
RED
2
12
22
32
42
ORANGE YELLOW GREEN
3
13
23
33
43
4
14
24
34
44
5
15
25
35
45
BLUE
6
16
26
36
46
VIOLET
7
17
27
37
47
GRAY
8
18
28
38
48
WHITE
9
19
29
39
49
BLACK
10
20
30
40
50
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Ma il: info @SAMTEC.c o m
c o d e: 55322
DESCRIPTION:
PIN#
DO NOT SCALE DRAWING
.100[2.54] TERMINAL DISCRETE CABLE ASSEMBLY
DWG. NO.
SHEET SCALE: 2:1
MMTXX-XX-XX-X-X-XX.XX-X-XXX
BY:
D. SCHMELZ 12/04/2008
SHEET
2
OF
3
c:\enterprisevault\DWG\MISC\MKTG\MMTXX-XX-XX-X-X-XX.XX-X-XXX-MKT.SLDDRW
REVISION B
FIG. 4
MMTS-06-20-X-XX.XX-S SHOWN
(DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG. 1)
01 02
.200 5.08 REF
IPM1-06-S
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Ma il: info @SAMTEC.c o m
c o d e: 55322
DESCRIPTION:
DO NOT SCALE DRAWING
.100[2.54] TERMINAL DISCRETE CABLE ASSEMBLY
DWG. NO.
SHEET SCALE: 2:1
MMTXX-XX-XX-X-X-XX.XX-X-XXX
BY:
D. SCHMELZ 12/04/2008
SHEET
3
OF
3
c:\enterprisevault\DWG\MISC\MKTG\MMTXX-XX-XX-X-X-XX.XX-X-XXX-MKT.SLDDRW
