ECO-PAC
TM
2
Single Phase
Rectifier Bridge
with fast Recovery Epitaxial Diode (FRED)
Preliminary Data Sheet
V
RSM
V
RRM
Type
V
DSM
V
DRM
(V)
(V)
400 400 PSB 100F/04
600 600 PSB 100F/06
PSB 100F
I
dAV
V
RRM
t
rr
PS
= 100 A
= 400 - 600 V
= 35 ns
+
~
L9
~
K10
EG
-
Symbol
I*
dAV
I
FSM
Test Conditions
T
C
= 85 °C,
T
VJ
= 45 °C
V
R
= 0
T
VJ
= T
VJM
V
R
= 0
T
VJ
= 45 °C
V
R
= 0
T
VJ
= T
VJM
V
R
= 0
(per module)
Maximum Ratings
100
600
660
540
590
1800
1810
1450
1440
A
A
A
A
A
A²s
A²s
A²s
A²s
°C
°C
°C
V
∼
V
∼
Features
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
∫
i dt
2
•
•
•
•
•
•
Package with DCB ceramic base plate
Isolation voltage 3000 V
∼
Planar glass passivated chips
Low forward voltage drop
Leads suitable for PC board
soldering
UL registered, E 148688
Applications
T
VJ
T
VJM
T
stg
V
ISOL
M
d
-40... + 150
150
-40... + 125
50/60 Hz, RMS t = 1 min
I
ISOL
≤
1 mA
Mounting torque
typ.
t=1s
(M4)
3000
3600
1.5 - 2.0
14 - 18
22
•
•
•
•
Supplies for DC power equipment
Input and output rectifier for high
frequency
Battery DC power supplies
Field supply for DC motors
Weight
Nm
lb.in.
g
Advantages
Symbol
I
R
V
F
V
TO
r
T
R
thJC
R
thJK
I
RM
t
rr
d
s
d
A
a
Test Conditions
V
R
= V
RRM,
T
VJ
= T
VJM
V
R
= V
RRM,
T
VJ
= 25°C
I
F
= 60 A, T
VJ
= 25 °C
For power-loss calculations only
per diode; DC
per module
per diode; DC
per module
Characteristic Value
≤
≤
≤
2.5
0.65
1.35
1.09
4.3
0.85
0.21
1.0
0.25
typ. 4.0
typ. 35
11.2
9.45
50
mA
mA
V
V
m
Ω
K/W
K/W
K/W
K/W
A
ns
mm
mm
m/s²
•
•
•
•
•
Easy to mount with two screws
Space and weight savings
Improved temperature and power
cycling capability
Low noise switching
Small and light weight
Package style and outline
Dimensions in mm (1mm = 0.0394“)
I
F
=130A; -di
F
/dt=100A/µs; V
R
=100V
L=0.05 mH; T
VJ
= 100°C
I
F
=1A; -di
F
/dt=200A/µs; V
R
=30V;
T
VJ
= 25°C
Creeping distance on surface
Creeping distance in air
Max. allowable acceleration
Data according to IEC 60747 refer to a single diode unless otherwise stated
*- for resistive load at bridge output
