ECO-PAC
TM
1
Single Phase
Rectifier Bridge
with fast Recovery Epitaxial Diode (FRED)
Preliminary Data Sheet
V
RSM
V
RRM
Type
V
DSM
V
DRM
(V)
(V)
800 800 PSB 19F/08
1200 1200 PSB 19F/12
PSB 19F
I
dAV
V
RRM
t
rr
+
= 19 A
= 800 - 1200 V
= 40 ns
~
A
~N
K
-
Maximum Ratings
19
90
40
45
35
40
10
10
5
5
A
A
A
A
A
A
A²s
A²s
A²s
A²s
°C
°C
°C
V
∼
Nm
lb.in.
g
V
∼
Symbol
I*
dAV
I
dAVM
I
FSM
Test Conditions
T
C
= 85 °C,
T
VJ
= 45 °C
V
R
= 0
T
VJ
= T
VJM
V
R
= 0
T
VJ
= 45 °C
V
R
= 0
T
VJ
= T
VJM
V
R
= 0
(per module)
Features
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
•
•
•
•
•
•
Package with DCB ceramic base plate
Isolation voltage 3000 V
∼
Planar glass passivated chips
Low forward voltage drop
Leads suitable for PC board
soldering
UL registered, E 148688
∫
i
2
dt
Applications
T
VJ
T
VJM
T
stg
V
ISOL
M
d
-40... + 150
150
-40... + 125
50/60 Hz, RMS t = 1 min
I
ISOL
≤
1 mA
Mounting torque
typ.
t=1s
(M4)
3000
3600
1.5 - 1.8
14 - 16
16
•
•
•
•
Supplies for DC power equipment
Input and output rectifier for high
frequency
Battery DC power supplies
Field supply for DC motors
Advantages
Weight
Symbol
I
R
V
F
V
TO
r
T
R
thJC
R
thJK
I
RM
t
rr
d
s
d
A
a
Test Conditions
V
R
= V
RRM,
T
VJ
= T
VJM
V
R
= V
RRM,
T
VJ
= 25°C
I
F
= 10 A,
T
VJ
= 25 °C
For power-loss calculations only
per diode; DC
per module
per diode; DC
per module
Characteristic Value
≤
≤
≤
0.25
0.06
2.92
1.32
30
2.5
0.63
2.8
0.7
typ. 4
typ. 40
11.2
9.7
50
mA
mA
V
V
m
Ω
K/W
K/W
K/W
K/W
A
ns
mm
mm
m/s²
•
•
•
•
•
Easy to mount with two screws
Space and weight savings
Improved temperature and power
cycling capability
Low noise switching
Small and light weight
Package style and outline
Dimensions in mm (1mm = 0.0394“)
I
F
=12A; -di
F
/dt=100A/µs; V
R
=100V
L=0.05 mH; T
VJ
= 100°C
I
F
=1A; -di
F
/dt=50A/µs; V
R
=30V;
T
VJ
= 25°C
Creeping distance on surface
Creeping distance in air
Max. allowable acceleration
Data according to IEC 60747 refer to a single diode unless otherwise stated
*- for resistive load at bridge output
2005 POWERSEM reserves the right to change limits, test conditions and dimensions
POWERSEM GmbH, Walpersdorfer Str. 53
D - 91126 Schwabach
Phone: 09122 - 9764 - 0 FAX: 09122 - 9764 - 20
