EGP10A-EGP10K
EGP10A - EGP10K
Features
•
•
•
•
Superfast recovery time for high
efficiency.
Low forward voltage, high current
capability.
Low leakage current.
High surge current capability.
DO-41
COLOR BAND DENOTES CATHODE
Fast Rectifiers (Glass Passivated)
Absolute Maximum Ratings*
Symbol
V
RRM
I
F(AV)
I
FSM
T
stg
T
J
T
A
= 25°C unless otherwise noted
Parameter
10A 10B
Maximum Repetitive Reverse Voltage
Average Rectified Forward Current,
.375 " lead length @ T
L
= 55°C
Non-repetitive Peak Forward Surge Current
8.3 ms Single Half-Sine-Wave
Storage Temperature Range
Operating Junction Temperature
50
100
10C
150
Value
10D
200
1.0
30
-65 to +150
-65 to +150
10F 10G 10J 10K
300
400
600
800
Units
V
A
A
°C
°C
*
These ratings are limiting values above which the serviceability of any semiconductor device may be impaired.
Thermal Characteristics
Symbol
P
D
R
θJA
Parameter
Power Dissipation
Thermal Resistance, Junction to Ambient
Value
2.5
50
Units
W
°C/W
Electrical Characteristics
Symbol
V
F
t
rr
I
R
C
T
T
A
= 25°C unless otherwise noted
Parameter
10A 10B
Forward Voltage @ 1.0 A
Reverse Recovery Time
I
F
= 0.5 A, I
R
= 1.0 A, I
rr
= 0.25 A
Reverse Current @ rated V
R
T
A
= 25°C
T
A
= 125°C
Total Capacitance
V
R
= 4.0 V, f = 1.0 MHz
10C
50
0.95
Device
10D
10F 10G 10J 10K
1.25
1.7
75
5.0
100
22
15
Units
V
ns
µA
µA
pF
2001
Fairchild Semiconductor Corporation
EPG10A - EPG10K, Rev. C
EGP10A-EGP10K
Typical Characteristics
Average Rectified Forward Current, I
F
[A]
Peak Forward Surge Current, I
FSM
[A]
1
30
25
20
15
10
5
0
0.75
0.5
SINGLE PHASE
HALF WAVE
60HZ
RESISTIVE OR
INDUCTIVE LOAD
.375" (9.0mm) LEAD
LENGTHS
0.25
0
25
50
75
100
125
Lead Temperature [ºC]
150
175
1
2
5
10
20
Number of Cycles at 60Hz
50
100
Figure 1. Forward Current Derating Curve
50
T
A
= 150
º
C
Figure 2. Non-Repetitive Surge Current
1000
Forward Current, I
F
[A]
10
EGP10A-EGP10D
T
A
= 25
º
C
100
Reverse Current, I
R
[mA]
T
A
= 125
º
C
10
1
1
T
A
= 100
º
C
0.1
EGP10F-EGP10K
0.1
T
A
= 25
º
C
Pulse Width = 300µs
µ
2% Duty Cycle
0.01
0.2
0.4
0.6 0.8
1
1.2 1.4
Forward Voltage, V
F
[V]
1.6
1.8
0.01
0
20
40
60
80
100
120 140
Percent of Rated Peak Reverse Voltage [%]
Figure 3. Forward Voltage Characteristics
60
Total Capacitance, C
T
[pF]
50
40
30
Figure 4. Reverse Current vs Reverse Voltage
EGP10A-EGP10D
20
EGP10F-EGP10K
10
0
0.1
1
10
100
Reverse Voltage, V
R
[V]
1000
50Ω
NONINDUCTIVE
Figure 5. Total Capacitance
50Ω
NONINDUCTIVE
+0.5A
(-)
trr
DUT
50V
(approx)
50Ω
NONINDUCTIVE
Pulse
Generator
(Note 2)
(+)
OSCILLOSCOPE
(Note 1)
0
-0.25A
NOTES:
1. Rise time = 7.0 ns max; Input impedance = 1.0 megaohm 22 pf.
2. Rise time = 10 ns max; Source impedance = 50 ohms.
-1.0A
1.0cm
SET TIME BASE FOR
5/ 10 ns/ cm
Reverse Recovery Time Characterstic and Test Circuit Diagram
2001
Fairchild Semiconductor Corporation
EPG10A - EPG10K, Rev. C
