Fast Recovery
Epitaxial Diode
(FRED) Module
Preliminary Data Sheet
V
RSM
V
200
400
600
V
RRM
V
200
400
600
Type
PSKD 200E/02
PSKD 200E/04
PSKD 200E/06
PSKD 200E
I
FAV
V
RRM
= 408 A
= 200-600V
Symbol
I
FAV
I
FSM
Test Conditions
T
C
= 70°C
T
VJ
= 45°C
V
R
= 0
T
VJ
= T
VJM
V
R
= 0
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
t = 10 ms (50 Hz), sine
t = 8.3 ms (60 Hz), sine
Maximum Ratings
408
4000
4400
3600
3900
80000
80300
64800
63100
-40 ... + 150
150
-40 ... + 125
A
A
A
A
A
A
2
s
A
2
s
A
2
s
A
2
s
°C
°C
°C
V
∼
V
∼
Nm
Nm
g
∫
i
2
dt
T
VJ
= 45°C
V
R
= 0
T
VJ
= T
VJM
V
R
= 0
Features
•
Package with screw terminals
•
Isolation voltage 3000 V∼
•
Planar glasspassivated chips
•
Short recovery time
•
Low forward voltage drop
•
Short recovery behaviour
•
UL registered, E 148688
Applications
•
Inductive heating and melting
•
Free wheeling diode in converters
and motor control circuits
•
Uninterruptible power supplies
(UPS)
•
Ultrasonic cleaners and welders
T
VJ
T
VJM
T
stg
V
ISOL
M
d
Weight
50/60 HZ, RMS
I
ISOL
≤
1 mA
t = 1 min
t=1s
(M6)
(M6)
2500
3000
5
5
270
Mounting torque
Terminal connection torque
typ.
Advantages
•
High reliability circuit operation
•
Low voltage peaks for reduced
protection circuits
•
Low noise switching
•
Low losses
Package, style and outline
Dimensions in mm (1mm = 0.0394“)
Symbol
I
R
V
F
t
rr
V
TO
r
T
R
thJC
R
thJH
d
S
d
A
a
Test Conditions
V
R
= V
RRM
T
VJ
= 25°C
V
R
= V
RRM
T
VJ
= T
VJM
I
F
= 200 A
T
VJ
= 25°C
T
VJ
= 25°C
For power-loss calculations only
T
VJ
= T
VJM
per diode; DC current
per module
per diode; DC current
per module
Creeping distance on surface
Creeping distance in air
Max. allowable acceleration
Characteristic Value
≤
≤
≤
5.0
30
1.25
typ. 150
0.25
0.43
0.28
0.14
0.38
0.19
10
9.4
50
mA
mA
V
ns
V
mΩ
K/W
K/W
mm
mm
m/s
2
POWERSEM GmbH, Walpersdorfer Str. 53
91126 D- Schwabach
Phone: 09122 - 9764-0 Fax.: 09122 - 9764-20
2003 POWERSEM reserves the right to change limits, test conditions and dimensions
