A28/SMA28
10 TO 1500 MHz
CASCADABLE AMPLIFIER
·HIGH OUTPUT LEVEL: +15 dBm (TYP.)
·HIGH THIRD ORDER I.P.: +29 dBm (TYP.)
·WIDE POWER SUPPLY RANGE:
+5 TO +15 VOLTS
Specifications (Rev. Date: 11/00)*
Characteristics
Frequency
Small Signal Gain (min.)
Gain Flatness (max.)
Reverse Isolation
Noise Figure (max.)
Power Output @ 1 dB comp. (min.)
IP3
IP2
Second Order Harmonic IP
VSWR Input / Output (max.)
DC Current @ 15 Volts (max.)
Typical
0° to 50°C
°
°
Typical Performance @ 25°C
Guaranteed
-54° to +85°C
°
°
0.0-1.6 GHz
11.0 dB
±0.2 dB
17 dB
6.0 dB
15.0 dBm
+29 dBm
+44 dBm
+49 dBm
1.5:1 / 1.5:1
45 mA
0.0-1.5 GHz
10.0 dB
±0.6 dB
7.0 dB
14.0 dBm
0.0-1.5 GHz
9.5 dB
±1.0 dB
7.5 dB
13.5 dBm
2.0:1 / 2.0:1
50 mA
2.1:1 / 2.1:1
53 mA
* Measured in a 50-ohm system at +15 Vdc Nominal. Subject to change without notice.
Absolute Maximum Ratings
Storage Temperature
Max. Case Temperature
Max. DC Voltage
Max. Continuous RF Input Power
Max. Short Term RF Input Power (1 minute max.)
Max. Peak Power (3
µsec
max.)
“S” Series Burn-in Temperature (Case)
-62° to +125°C
125°C
+17 Volts
+13 dBm
50 mW
0.5 W
125°C
Thermal Data: V
cc
= 15 Vdc
Thermal Resistance
θ
jc
Transistor Power Dissipation P
d
Junction Temperature Rise Above Case T
jc
145°C/W
0.429 W
62°C
Outline Drawings
Package
Figure
Model
TO-8
BG
A28
Surface Mount
AA
SMA28
SMA Connectorized
CE
CA28
Specifications subject to change without notice.
•
North America: 1-800-366-2266
Visit www.macom.com for complete contact and product information.
