PS7200J-1A-E3: DescriptionTransistor Output SSR, 1-Channel, 1500V Isolation, SOP-4; CategoryLED optoelectronic/LED photoelectric; File Size44KB，5 Pages; ManufacturerNEC Electronics

Download Datasheet Parametric Compare View All

PS7200J-1A-E3 Overview

Transistor Output SSR, 1-Channel, 1500V Isolation, SOP-4

PS7200J-1A-E3 Parametric

Parameter Name	Attribute value
Maker	NEC Electronics
package instruction	SOP-4
Reach Compliance Code	unknown
Configuration	SINGLE
Maximum forward current	0.02 A
Maximum insulation voltage	1500 V
Number of components	1
Maximum on-state current	0.1 A
Maximum on-state resistance	15 Ω
Maximum operating temperature	80 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	TRANSISTOR OUTPUT SSR

Preview

Download Datasheet

View All

4 PIN SOP LOW OUTPUT

CAPACITANCE SOLID STATE RELAY

FEATURES

• 1 CHANNEL TYPE

1A output

• LOW C X R

C X R = 15 pF •

Ω

•

LOW OUTPUT CAPACITANCE

OUT

= 1.7 pF TYP

• LOW OFF-STATE LEAKAGE CURRENT

LOFF

= 0.02 nA TYP

• HIGH SPEED TURN-ON TIME

= 8

µs

TYP

• DESIGNED FOR AC/DC SWITCHING LINE CHANGER

• SMALL PACKAGE

4 pin SOP

• HIGH ISOLATION VOLTAGE

BV = 1500 Vr.m.s.

• LOW OFFSET VOLTAGE

• AVAILABLE IN TAPE AND REEL

PS7200J-1A-E3, E4, F3, F4

PS7200J-1A

DESCRIPTION

The PS7200J-1A is a low output capacitance solid state relay

containing a GaAs LED on the light emitting side (input side)

and MOSFETs on the output side.

It is suitable for high-frequency signal control, due to its low

C x R and low output capacitance. This device is not recom-

mended for new designs. It has been replaced by the PS7200R.

APPLICATIONS

• MEASUREMENT EQUIPMENT

• HIGH SPEED COMMUNICATIONS EQUIPMENT

ELECTRICAL CHARACTERISTICS

= 25

°C)

PART NUMBER

SYMBOLS

PARAMETERS

Forward Voltage, I

= 10 mA

Reverse Current, V

= 5 V

Off-State Leakage Current, V

= 40 V

Output Capacitance, V = 0 V, f = 1 MHz

LED On-State Current, I

= 100 mA

On-State Resistance, I

= 10 mA, I

= 10 mA

= 10 mA, I

= 100 mA

Turn-on Time, I

= 10 mA, V

= 5 V, PW

≥

10 ms

Turn-off Time, I

= 10 mA, V

= 5 V, PW

≥

10 ms

Isolation Resistance, V

I-O

= 1.0 kV

Isolation Capacitance, V = 0 V, f = 1 MHz

UNITS

µA

Ω

0.5

8.5

0.008

0.3

1.7

1.0

100

MIN

PS7200J-1A

TYP

1.2

MAX

1.4

5.0

3.0

MOS

Diode

FET

LOFF

OUT

Coupled

OFF

I-O

Note:

1. Turn-On, Turn-Off Time

Input

50%

= 5 V

Output

10%

OFF

PS7200J-1A

90%

California Eastern Laboratories
