Three Phase Solid State Relays
HIGHLIGHTS
x
x
x
x
x
x
x
x
INPUT: DC CONTROL
HIGH DV/DT
OUTPUT: DIRECT COPPER BONDED
BACK-TO-BACK SCR
OPTO ISOLATION 2500 VAC
(4000 V optional)
VOLTAGE RANGE 100 TO 660 VAC
LOAD CURRENT 3x25A / 50A / 75A / 90A
REVERSE POLARITY PROTECTION FOR
DC INPUT CONTROL
Weight = 344 g
Series: 12 SJ/K
(J: Zero voltage turn-on; K: Random turn-on)
ELECTRICAL SPECIFICATIONS
Parameter
Symbol
PSD 12 D
122500
Type
PSD 12 D
125000
PSD 12 D
127500
PSD 12 D
129000
Unit
DC CONTROL
Control voltage range
Control current range
Pick-up voltage
Drop-out voltage
Input resistance
OUTPUT
Mains control voltage
Repetitive peak off state voltage
RMS on-state current (per phase)
Zero turn-on voltage
On-state voltage drop
Off-state leakage current @ rated voltage
Peak one cycle surge current (non-rep)
Holding current
Critical rate of rise of off-state voltage
Thermal resistance (junction to case)
Frequency range
Operating temperature
Turn-on time
Turn-off time
Fusing current
4-32
8-80
4-0
1-0
4-32
8-80
4-0
1-0
4-32
8-80
4-0
1-0
4-32
8-80
4-0
1-0
Vdc
mA
Vdc
Vdc
Current regulator
V
RMS
V
DRM
I
T
V
TM
I
DRM
I
TSM
I
H
dv/dt
R
thjc
f
T
O
T-on
T-off
I
2
t
100-660
800-1600
25
35
1.8
1
400
250
1000
1.38
47-63
-30 to +80
10
10
600
100-660
800-1600
50
35
2.0
1
500
250
1000
0.7
47-63
-30 to +80
10
10
1250
100-660
800-1600
75
35
2.0
1
1150
250
1000
0.6
47-63
-30 to +80
10
10
5000
100-660
800-1600
90
35
2.0
1
1150
250
1000
0.56
47-63
-30 to +80
10
10
5000
Vac
Vpk
A
Vac
Vac
mA
A
mA
V/µs
K/W
Hz
°C
ms
ms
A
2
s
released, E 197669
POWERSEM reserves the right to change limits, test conditions and dimensions -
info@POWERSEM.net
- www.POWERSEM.net
POWERSEM 2007 All rights reserved
Three Phase Solid State Relays
MECHANICAL SPECIFICATIONS
Dimensions in mm
Three Phase Solid State Relay
+0,4
73,0
+1,0
57,0
47,6
+0,1
22
20
20
92
+0,1
104
34,5
20
23
+0,3
24
+0,4
30
(MAX)
90
F
75
60
CURRENT (A)
50
45
F
30
25
15
F
10
20
30
40
50
60
70
80
90
AMBIENT TEMPERATURE ( C )
HEAT SINK USED:
FAN USED:
0,14 K/W
70 CFM
VALIED FOR SERIES: PSD 12 SJK
