CLOCK
Page 1 of 3
CS9 SERIES: CLOCK OSCILLATOR, PECL, +3.3 VDC
DESCRIPTION: A crystal controlled, high frequency, highly stable oscillator, adhering to Positive Emitter
Coupled Logic (PECL) Standards. The output can be Tri-stated to facilitate testing or combined multiple clocks.
The device is contained in a sub-miniature, very low profile, leadless ceramic SMD package with 6 gold contact
pads. This miniature oscillator is ideal for today's automated assembly environments.
APPLICATIONS AND FEATURES:
"
"
"
"
"
"
$
Infiniband; 10GbE; Network Processors; SOHO Routing; Switches; WAN Interfaces
Common Frequencies: 106.25 MHz; 125 MHz; 150 MHz; 155.52 MHz; 156.25 MHz; 161.1328 MHz
+3.3 VDC PECL
Frequency Range from 50 to 700 MHz
Miniature Ceramic SMD Package Available on Tape and Reel
Lead Free and ROHS Compliant
ELECTRICAL PARAMETERS:
PARAMETER
SYMBOL
fo
Vcc
Is
Connected between each output and Vcc – 2.0 VDC
Voh
Vol
DC
tr / tf
J
∆f/fc
En
Dis
Vcc(abs)
TEST CONDITIONS
*1
VALUE
50.00 ~ 700.000**
+3.3
±5%
80.0 MAX
PECL
50
2.275 MIN
1.68 MAX
40/60 to 60/40 or 45/55 to 55/45
1.0 TYP
*2
1 TYP**
±25, ±50,
or
±100
MAX
0.7•Vcc MIN
0.3•Vcc MAX
-0.5…+7.0
*3
UNIT
MHz
VDC
mA
Ω
VDC
VDC
%
ns
ps
ppm
VDC
VDC
VDC
Nominal Frequency
Supply Voltage
Supply Current
Output Logic Type
Load
Output Voltage Levels
Duty Cycle
Rise / Fall Time
Integrated Jitter
Overall Frequency Stability
Pin 1
Output Enabled
Output Disabled
Measured at 50% of Vcc
Measured at 20/80% and 80/20% Vcc Levels
RMS, Fj = 12 kHz…20 MHz
Op. Temp., Aging, Load, Supply and Cal. Variations
High Voltage or No Connect
Ground
Non-Destructive
Absolute voltage range
*1 Test Conditions Unless Stated Otherwise: Nominal Vcc, Nominal Load, +25
±3°C
*2 Frequency Dependent
*3 Not All Stabilities Available With All Temperature Ranges—Please Consult Factory For Availability
$
ENVIRONMENTAL PARAMETERS:
PARAMETER
SYMBOL
Ta
T(stg)
TESTCONDITIONS
*1
VALUE
SEE PART NUMBER TABLE
-55…+90
UNIT
°C
°C
Operating temperature range
Storage temperature range
$
PART NUMBERING SYSTEM:
SERIES
SYMMETRY
A: 40/60 to 60/40%
T: 45/55 to 55/45%
TEMPERATURE
RANGE (°C)
R:
S:
U:
V:
0…+50
0…+70
-20…+70
-40…+85**
FREQUENCY
STABILITY
(Overall)
I:
±25
ppm**
H:
±50
ppm
J:
±100
ppm
FREQUENCY
(MHz)
50.000…700.000
CS9: Clock
with PECL
Comp. Output
EXAMPLE: CS9ASH-155.520
Clock Oscillator, 7x5mm Package, +3.3 VDC Supply Voltage, PECL Output, Standard Symmetry, 0…+70°C Operating
Temperature Range,
±50
ppm Total Frequency Stability, 155.520 MHz
**Above 300MHz extended temp range and ±25ppm stability may not be available, jitter may vary upon spec requirements.
Please consult the factory for any custom requirements.
RALTRON ELECTRONICS CORP.
!
10651 N.W . 19
th
St
!
Miami, Florida 33172
!
U.S.A.
phone: (305) 593-6033
!
fax: (305) 594-3973
!
e-mail: sales@raltron.com
!
WEB: http://www.raltron.com
