ULTRA BRIGHTNESS LED LAMP
PACKAGE CONFIGURATION
BVU-3R16BA4
DESCRIPTION
Dice Material : GaN Blue
Light Color : Blue Color
Lens Color : Water Transparent
Stand-Off P/N : BVU-3R16BA4 R
3.2
3.2
3.0
3.5
1.0
1.0Max.
3.2
RADIATION PATTERN
-30°
0°
30°
9.8±0.5
1.3
25.4Min.
1.0
25.4Min.
-60°
60°
CATHODE
0.5
2.54
CATHODE
100 75 50 25
0 25 50 75 100
Relative Luminous Intensity ( Iv % )
1.0Min.
2.54
Tolerance ± 0.25
㎜
ABSOLUTE MAXIMUM RATINGS AT Ta = 25
℃
PARAMETER
Power Dissipation (P
D
)
Continuous Forward Current (I
F
)
Peak Forward Current ( 1/10 Duty Cycle , 0.1ms Pulse Width ) (I
FP
)
Reverse Voltage (V
R
)
MAX.
120
30
160
5
0.4
UNIT
mW
mA
mA
V
mA/
o
C
Derating Linear From 25
℃
Operating Temperature Range (Topr)
－30 ℃
to
＋
80
℃
Storage Temperature Range (Tstg)
－40
℃
to
＋
100
℃
Lead Solder Temperature 1.6 mm Below Package 260
℃
for 5 seconds (Tsld)
ELECTRICAL / OPTICAL CHARACTERISTICS AT Ta = 25
℃
SYMBOL
V
F
I
R
λp
λd
2θ1/2
I
V
PARAMETER
Forward Voltage
Reverse Current
Peak Emission Wavelength
Dominant Wavelength
Viewing Angle
Luminous Intensity
TEST COND.
I
F
= 20 mA
V
R
= 5V
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
MIN.
TYP.
3.2
465
470
40
1680
MAX.
4.0
10
UNIT
V
μA
nm
nm
Deg
mcd
1300
BIN GRADE LIMITS (IF=20 mA)
LUMINOUS INTENSITY / mcd
Bin
Min.
Max.
K
1300
1680
L
1680
2180
M
2180
2800
N
2800
3600
Tolerance ± 15%mcd
BIN GRADE LIMITS (IF=20 mA)
DOMINANT WAVELENGTH / nm
Bin
Min.
Max.
BM
460
465
BN
465
470
BO
470
475
*Bright View reserves the rights to alter specifications and remove availability of products at any time without notice.
*Dominant Wavelength,
λd
is according to CIE Chromaticity Diagram base on color of lamps.
*
θ
1/2 is the off-axis angle where the luminous intensity is one half the on-axis intensity.
*These products are sensitive to static electricity. Caution must be taken strictly to avoid static electricity.
2009/2/19 – B
BRIGHT VIEW
ELECTRONICS CO.,LTD
ULTRA BRIGHTNESS LED LAMP
BVU-3R16BA4
TYPICAL ELECTRICAL / OPTICAL CHARACTERISTIC CURVES
FIG. 1 Forward Current vs. Forward Voltage
( Ta = 25 °C )
FIG. 2 Relative Intensity vs. Forward Current
( Ta = 25 °C )
40
35
30
25
20
15
10
5
0
3.0
2.5
Relative Intensity
2.0
1.5
1.0
0.5
0
Forward Current ( mA )
2.2
2.7
3.2
3.7
Forward Voltage Vf ( V )
4.2
0
10
20
30
Forward Current If ( mA )
40
FIG. 3 Forward Voltage vs. Temperature
1.2
Relative Intensity @ 20mA
Forward Voltage @ 20mA
1.1
1.0
0.9
0.8
-50
3.0
2.5
2.0
1.5
1.0
0.5
FIG. 4 Relative Intensity vs. Temperature
-25
0
25
50
75
100 125
0
-50 -25
0
25
50
75
100 125
Ambient Temperature Ta ( °C )
FIG. 5 Relative Intensity vs. Wavelength (
λp
)
( Ta = 25 °C )
IF-DC Forward Current ( mA )
Ambient Temperature Ta ( °C )
FIG. 6 Maximum Forward Current
40
30
20
10
0
0
vs. Temperature
1.0
Forward Intensity @ 20mA
0.5
0
400
450
500
Wavelength ( nm )
550
20
40
60
80 100
Ambient Temperature Ta ( °C )
120
2009/2/19 – B
BRIGHT VIEW
ELECTRONICS CO.,LTD
ULTRA BRIGHTNESS LED LAMP
BVU-3R16BA4
CAUTION FOR CLASS 1 ESD ( MACHINE MODE )
Gallium Nitride (GaN) based light emitting diodes (LEDs) are extremely sensitive to electrostatic
discharge (ESD). Users are strongly recommended to take necessary meter to test the static
and avoid ESD when handing these products.
Bright View's BA, GN, WI series products are GaN based materials and are classified as
"Class 1",( ESD endurance 50V or lower ), any manufacturing site or workstation where
GaN devices are handled should be rated and controlled at 50V or below.
Proper grounding of products or machines ( via 1MΩ ), using static dissipative mats, static
dissipative containers, static dissipative working uniferms and shoes are considered to be
effective against ESD.
An ionizer is recommended in the facility or environment where ESD may be generated
easily, and soldering iron with a grounded tip is also recommended.
To install a protection device in the LED circuit to ensure the surge current and voltage not
exceeding the max rating during on/off swithing.
When inspecting the final products in which LEDs are assembled, it is recommended to
check whether the assembled LEDs are damaged by ESD or not. It is simple to find
damaged LEDs by light-on or a VF test at lower current (below 1mA is recommended).
ESD damaged LEDs will show some unusual characteristics such as the remarkable
increasing of leak current, the forward voltage become lower, or the LEDs do not light on
at the low current.
2009/2/19 – B
BRIGHT VIEW
ELECTRONICS CO.,LTD
ULTRA BRIGHTNESS LED LAMP
BVU-3R16BA4
Apply to LAMP(DIP) series.
Description:
( 1 ) Manual soldering (Solder Iron)
(1.1) Temperature at tip of the iron: 300°C Max.
(1.2) It's banned to load any stress on the resin during soldering.
(1.3) Soldering time: 3 sec. Max.(one time only)
(1.4) Leave 3mm of minimum distance from the base of epoxy.
( 2 ) Dip Soldering(Wave soldering-Solder Bath)
(2.1) Leave 3mm of minimum distance from the base of the epoxy.
Soldering beyond the base of the tie bar(stand off) is recommended.
(2.2) When soldering, do not put stress on the LEDs during heating.
(2.3) Cutting the leadframes at high temperatures may cause LED failure.
(2.4) Never take next process until the component is cooled down to room temperature
after reflow.
(2.5) After soldering, do not warp the circuit board.
(2.6) The recommended dip soldering profile is the following:
Degree C.
300.0
275.0
250.0
225.0
200.0
175.0
150.0
125.0
100.0
75.0
50.0
25.0
0.0
MAX 260 C
， 5
sec.
>20 C
Temperature
(
C
)
4 C / sec.
150 C
0.0
50.0
100.0
150.0
200.0
250.0
300.0
Time ( sec. )
2009/2/19 – B
BRIGHT VIEW
ELECTRONICS CO.,LTD
ULTRA BRIGHTNESS LED LAMP
BVU-3R16BA4
Label 1
Label 2
Bright View
PART NO.:
LOT NO.:
GRADE:
Q'ty
X-
-
pcs
Electronics Co.,Ltd.
Bright View
PART NO.:
LOT NO.:
GRADE:
Electronics Co.,Ltd.
BVU-XXXXXXXX
QA
3mm or 5mm Polybag
Pb - Free / RoHS Compliant
X: Bin grade
: Wavelength
: Vf
Anti-electrostatic bag
Q'ty
pcs
QA
Pb - Free / RoHS Compliant
ELECTROSTATIC SENSITIVE DEVICES
DO NOT OPEN OR HANDLE EXCEPT
AT A STATIC-FREE WORKSTATION
BOX
Dimension(cm): 29*25*15
25
BVU - X X X X X X X R
Stand-offs
Luminous Grade-refer
to the selection guide for BIN options
Lens Color-refer
to lens color (1) to (9)
Dice Code-refer
to the selection guide
Lens Configuration-refer
to lens drawing
View Angle-refer
to the selection guide (A) to (Z)
Outline Dimension-refer
to the outline dimension
29
3
15
TYPE
Q'TY
N,W
G,W
C.NO
PCS
KGS
KGS
Label 1 or Label 2 attach on it.
Device
5mm(T-1 3/4)
3mm(T-1)
Blue / Green / White
Q'ty / Polybag (pcs)
1000pcs
1000pcs
500pcs
Polybag / Box A
14 bags
20 bags
18 bags
Fig.
Label 1
Label 1
Label 2
32
53
RE
Y
CARTON
Dimension(cm): 53*32*33
33
ITEM NO.
DEVICE:
Q'TY
N. W.:
G. W.:
PCS.
KGS.
KGS.
4 Boxes / Carton
5mm : 56,000pcs
3mm : 80,000pcs
Blue / Green / White : 36,000pcs
2009/2/19 – B
