BRIGHT VIEW
ELECTRONICS CO.,LTD
ULTRA BRIGHTNESS LED LAMP
PACKAGE CONFIGURATION
BVU-5E1GN4
5.9
5.9
DESCRIPTION
Dice Material : GaN Green
Light Color : Green Color
Lens Color : Water Transparent
Stand-Off P/N : BVU-5E1GN4 R
7.6
5.0
4.9
RADIATION PATTERN
-30°
0°
30°
1.0
12.8 0.5
1.0Max.
1.3
1.0
25.4Min.
CATHODE
25.4Min.
-60°
60°
CATHODE
0.5
2.54
1.0Min.
2.54
100 75 50 25 0 25 50 75 100
Relative Luminous Intensity ( Iv % )
Tolerance ± 0.25
ABSOLUTE MAXIMUM RATINGS AT Ta = 25
PARAMETER
Power Dissipation
Continuous Forward Current
Peak Forward Current ( 1/10 Duty Cycle , 0.1ms Pulse Width )
Reverse Voltage
Derating Linear From 25
Operating Temperature Range
Storage Temperature Range
Lead Solder Temperature 1.6 mm Below Package 260
for 5 seconds
MAX.
120
30
100
5
0.4
30
to
40
to
UNIT
mW
mA
mA
V
mA/
o
C
80
100
ELECTRICAL / OPTICAL CHARACTERISTICS AT Ta = 25
PARAMETER
SYMBOL
Forward Voltage
V
F
Reverse Current
I
R
Peak Emission Wavelength
Dominant Wavelength
2 1/2 Viewing Angle
TEST COND.
I
F
= 20 mA
V
R
= 5V
I
F
= 20 mA
I
F
= 20 mA
I
F
= 20 mA
MIN.
TYP.
3.3
520
525
15
MAX.
4.0
10
UNIT
V
A
nm
nm
Deg
BIN GRADE LIMITS ( I F = 20 mA ) LUMINOUS INTENSITY / mcd
Bin
Min.
Max.
Q
6000
7800
R
7800
10000
S
10000
13000
T
U
V
13000 16800 21800
16800 21800 28000
Tolerance ± 15%mcd
*Bright View reserves the rights to alter specifications and remove availability of products at any time without notice.
*Dominant Wavelength, d is according to CIE Chromaticity Diagram base on color of lamps.
* 1/2 is the off-axis angle where the luminous intensity is one half the on-axis intensity.
*These products are sensitive to static electricity. Caution must be taken strictly to avoid static electricity.
2006/10/31 – B
BRIGHT VIEW
ELECTRONICS CO.,LTD
ULTRA BRIGHTNESS LED LAMP
BVU-5E1GN4
TYPICAL ELECTRICAL / OPTICAL CHARACTERISTIC CURVES
FIG. 1 Forward Current vs. Forward Voltage
( Ta = 25 °C )
100
90
80
70
60
50
40
30
20
10
0
3.0
2.5
Relative Intensity
2.0
1.5
1.0
0.5
0
2.5
2.9
3.3
3.7
Forward Voltage Vf ( V )
4.1
0
10
20 30 40 50 60
Forward Current If ( mA )
70
Forward Current ( mA )
FIG. 2 Relative Intensity vs. Forward Current
( Ta = 25 ° C )
FIG. 3 Relative Voltage vs. Temperature
1.2
Relative Intensity @ 20mA
Forward Voltage @ 20mA
1.1
1.0
0.9
0.8
-50
3.0
2.5
2.0
1.5
1.0
0.5
FIG. 4 Relative Intensity vs. Temperature
-25
0
25
50
75
100 125
0
-50 -25
0
25
50
75
100 125
Ambient Temperature Ta ( °C )
FIG. 5 Relative Intensity vs. Wavelength ( p )
( Ta = 25 °C )
IF-DC Forward Current ( mA )
1.0
Forward Intensity @ 20mA
40
30
20
10
0
0
Ambient Temperature Ta ( °C )
FIG. 6 Maximum Forward Current
vs. Temperature
0.5
0
450
500
550
Wavelength ( nm )
600
20
40
60
80 100
Ambient Temperature Ta ( °C )
120
2006/10/31 - B
CAUTION FOR CLASS 1 ESD ( MACHINE MODE )
Gallium Nitride (GaN) based light emitting diodes (LEDs) are extremely sensitive to
electrostatic discharge (ESD). Users are strongly recommended to take necessary
meter to test the static and avoid ESD when handling these products.
’
“
”
DOC. NO.:S-QW-K011
2006/03/17 –A
BRIGHT VIEW
ELECTRONICS CO.,LTD
LAMP APPLICATION ( PB FREE SOLDERING )
Apply to LAMP(DIP) series.
Description:
(1) Manual soldering (Solder Iron)
(2) Dip Soldering(Wave soldering-Solder Bath)
DOC. NO.:S-QW-K001
2006 / 02 / 08 -B
BRIGHT VIEW
ELECTRONICS CO.,LTD
LAMP PACKING
Label 2
Label 1
Bright View
PART NO.:
LOT NO.:
GRADE:
Q'ty
X-
-
pcs
Electronics Co.,Ltd.
Bright View
PART NO.:
LOT NO.:
GRADE:
Electronics Co.,Ltd.
BVU-5M5XXXXX
QA
Q'ty
pcs
QA
3mm or 5mm Polybag
X: Bin grade
: Wavelength
: Vf
Anti-electrostatic bag
ELECTROSTATIC SENSITIVE DEVICES
DO NOT OPEN OR HANDLE EXCEPT
AT A STATIC-FREE WORKSTATION
BOX
Dimension(cm): 29*25*15
25
BVU
-5X1XX4XR
BVT
Stand-offs
Luminous Grade-refer
to the selection guide for BIN options
Lens Color-refer
to lens color (1) to (9)
Dice Code-refer
to the selection guide
Lens Configuration
-refer to lens drawing
View Angle-refer
to the selection guide (A) to (Z)
Outline Dimension-refer
to the outline dimension
29
3
15
TYPE
Q'TY
N,W
G,W
C.NO
PCS
KGS
KGS
Label 1 or Label 2 attach on it.
Device
5mm(T-1 3/4)
3mm(T-1)
Blue / Green / White
Q'ty / Polybag (pcs)
1000pcs
1000pcs
500pcs
Polybag / Box A
14 bags
20 bags
18 bags
Fig.
Label 1
Label 1
Label 2
32
53
RE
Y
CARTON
Dimension(cm): 53*32*33
33
ITEM NO.
DEVICE:
Q'TY
N. W.:
G. W.:
PCS.
PCS.
PCS.
4 Boxes / Carton
5mm : 56,000pcs
3mm : 80,000pcs
Blue / Green / White : 36,000pcs
2003 / 9 / 15 - A
