BA3121F_09 Overview

Ground Isolation Amplifier

Preview

Download Datasheet

View All

Audio Accessory IC Series

Ground Isolation

Amplifier

BA3121F, BA3123F

No.09092EAT01

●Description

The BA3121F/BA3123F are ground isolation amplifiers developed for use in car audio applications.

This IC efficiently eliminate problems caused by wiring resistance, and remove noise generated by the electrical devices

used in automobiles. The capacitance values of the external capacitors required for the ICs are small to allow compact

and reliable set design.

●Features

1) Large capacitors not required

2) High common-mode rejection ratio (57dB typ. at f = 1kHz).

3) Low noise (VNO = 3.5μVrms Typ.).

4) Low distortion (THD = 0.002% Typ.).

5) Two channels.

●Applications

Car audio systems

●Line

up matrix

Operation temperature

BA3121F

－30½＋85C

BA3123F

－40½＋85C

●Absolute

maximum ratings

(Ta = 25C)

Parameter

Symbol

Limits

450*

－30½＋85

－40½＋85

－55½＋125

Unit

℃

Power supply voltage

Vcc

Power dissipation

BA3121F

Operation

Topr

temperature

BA3123F

Storage temperature

Tstg

＊Reduced

by 4.5mW in Ta of 1C over 25C.

●Recommended

operating conditions

(Ta = 25C)

Parameter

Power supply voltage

Symbol

Vcc

Min.

Typ.

Max.

Unit

www.rohm.com

1/8

2009.08 - Rev.A

BA3121F_09 Related Products

	BA3121F_09	BA3121F	BA3123F
Description	Ground Isolation Amplifier	Ground Isolation Amplifier	Ground Isolation Amplifier
Is it lead-free?	-	Lead free	Lead free
Is it Rohs certified?	-	conform to	conform to
Parts packaging code	-	SOIC	SOIC
package instruction	-	LSOP,	SOP-8
Contacts	-	8	8
Reach Compliance Code	-	compli	compli
ECCN code	-	EAR99	EAR99
Nominal bandwidth	-	20 kHz	20 kHz
Commercial integrated circuit types	-	AUDIO AMPLIFIER	AUDIO AMPLIFIER
harmonic distortion	-	0.002%	0.002%
JESD-30 code	-	R-PDSO-G8	R-PDSO-G8
JESD-609 code	-	e2	e2
length	-	5 mm	5 mm
Number of channels	-	2	2
Number of functions	-	1	1
Number of terminals	-	8	8
Maximum operating temperature	-	85 °C	85 °C
Minimum operating temperature	-	-30 °C	-40 °C
Package body material	-	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	-	LSOP	LSOP
Package shape	-	RECTANGULAR	RECTANGULAR
Package form	-	SMALL OUTLINE, LOW PROFILE	SMALL OUTLINE, LOW PROFILE
Peak Reflow Temperature (Celsius)	-	260	260
Certification status	-	Not Qualified	Not Qualified
Maximum seat height	-	1.6 mm	1.6 mm
Maximum supply voltage (Vsup)	-	18 V	18 V
Minimum supply voltage (Vsup)	-	4 V	4 V
surface mount	-	YES	YES
Temperature level	-	OTHER	INDUSTRIAL
Terminal surface	-	Tin/Copper (Sn/Cu)	Tin/Copper (Sn/Cu)
Terminal form	-	GULL WING	GULL WING
Terminal pitch	-	1.27 mm	1.27 mm
Terminal location	-	DUAL	DUAL
Maximum time at peak reflow temperature	-	10	NOT SPECIFIED
width	-	4.4 mm	4.4 mm
