SMZJ3788B thru SMZJ3809B
www.vishay.com
Vishay General Semiconductor
Surface Mount Power Voltage-Regulating Diodes
FEATURES
• Low profile package
• Ideal for automated placement
• Glass passivated chip junction
• Low Zener impedance
• Low regulation factor
• Meets MSL level 1, per J-STD-020, LF maximum peak of
260 °C
• AEC-Q101 qualified
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
DO-214AA (SMBJ)
MECHANICAL DATA
PRIMARY CHARACTERISTICS
V
Z
P
tot
I
R
(V
Z
12 V)
T
J
max.
V
Z
specification
Int. construction
9.1 V to 68 V
1500 mW
5.0 μA
150 °C
Pulse current
Single
Case:
DO-214AA (SMBJ)
Molding compound meets UL 94 V-0 flammability rating
Base P/N-E3 - RoHS compliant, commercial grade
Base P/NHE3 - RoHS compliant, AEC-Q101 qualified
Terminals:
Matte tin plated leads, solderable per
J-STD-002 and JESD 22-B102
E3 suffix meets JESD 201 class 1A whisker test, HE3 suffix
meets JESD 201 class 2 whisker test
Polarity:
Color band denotes cathode end
TYPICAL APPLICATIONS
For general purpose regulation and protection applications.
MAXIMUM RATINGS
(T
A
= 25 °C unless otherwise noted)
PARAMETER
Operating junction and storage temperature range
SYMBOL
T
J
, T
STG
VALUE
- 55 to + 150
UNIT
°C
Revision: 25-May-12
Document Number: 88402
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
SMZJ3788B thru SMZJ3809B
www.vishay.com
Vishay General Semiconductor
MAXIMUM
REVERSE
CURRENT
I
R
AT V
R
μA
MAX.
1000
1000
650
550
550
600
600
650
650
650
700
700
750
800
850
900
950
1000
1100
1300
1500
1700
MAX.
50
50
10
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
7.0
7.6
8.4
9.1
9.9
11.4
12.2
13.7
15.2
16.7
18.2
20.6
22.8
25.1
27.4
29.7
32.7
35.8
38.8
42.6
47.1
51.7
V
MAXIMUM
ZENER
CURRENT
(1)
I
ZM
mA
MAX.
140
125
115
105
98
85
80
70
62
56
51
46
41
38
35
31
28
26
24
22
20
18
ELECTRICAL CHARACTERISTICS
(T
A
= 25 °C unless otherwise noted)
DEVICE
MARKING
CODE
ZENER VOLTAGE
RANGE
V
Z
AT I
ZT
V
MIN.
SMZJ3788B
SMZJ3789B
SMZJ3790B
SMZJ3791B
SMZJ3792B
SMZJ3793B
SMZJ3794B
SMZJ3795B
SMZJ3796B
SMZJ3797B
SMZJ3798B
SMZJ3799B
SMZJ3800B
SMZJ3801B
SMZJ3802B
SMZJ3803B
SMZJ3804B
SMZJ3805B
SMZJ3806B
SMZJ3807B
SMZJ3808B
SMZJ3809B
VL
WB
WD
WF
WH
WJ
WL
XB
XD
XF
XH
XJ
XL
YB
YD
YF
YH
YJ
YL
ZB
ZD
ZF
8.65
9.50
10.5
11.4
12.4
14.3
15.2
17.1
19.0
20.9
22.8
25.7
28.5
31.4
34.2
37.1
40.9
44.7
48.5
53.2
58.9
64.6
NOM.
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
MAX.
9.56
10.5
11.6
12.6
13.7
15.8
16.8
18.9
21.0
23.1
25.2
28.4
31.5
34.7
37.8
41.0
45.2
49.4
53.6
58.8
65.1
71.4
41.2
37.5
34.1
31.2
28.8
25.0
23.4
20.8
18.7
17.0
15.6
13.9
12.5
11.4
10.4
9.6
8.7
8.0
7.3
6.7
6.0
5.5
0.50
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
TEST CURRENT
I
ZT
mA
MAX.
4.0
5.0
6.0
7.0
7.5
9.0
10.0
12.0
14.0
17.5
19.0
23.0
26.0
33.0
38.0
45.0
53.0
67.0
70.0
86.0
100.0
120.0
I
ZK
MAXIMUM ZENER
IMPEDANCE
Z
ZT
AT I
ZT
Z
ZK
AT I
ZK
PART
NUMBER
(1)
Notes
(1)
Maximum steady state power dissipation is 1500 mW at T = 75 °C (fig. 1)
L
ORDERING INFORMATION
(Example)
PREFERRED P/N
SMZJ3788B-E3/52
SMZJ3788B-E3/5B
SMZJ3788BHE3/52
(1)
SMZJ3788BHE3/5B
(1)
Note
(1)
AEC-Q101 qualified
UNIT WEIGHT (g)
0.096
0.096
0.096
0.096
PREFERRED PACKAGE CODE
52
5B
52
5B
BASE QUANTITY
750
3200
750
3200
DELIVERY MODE
7" diameter plastic tape and reel
13" diameter plastic tape and reel
7" diameter plastic tape and reel
13" diameter plastic tape and reel
Revision: 25-May-12
Document Number: 88402
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
SMZJ3788B thru SMZJ3809B
www.vishay.com
RATINGS AND CHARACTERISTICS CURVES
(T
A
= 25 °C unless otherwise noted)
2.0
200
Vishay General Semiconductor
P
tot
- Power Dissipation (W)
1.5
Z
Z
- Dynamic Impedance (Ω)
60 Hz
Resistive or
Inductive Load
100
I
Z
= 1 mA
1.0
10
I
Z
= 10 mA
I
Z
= 20 mA
I
Z(rms)
= 0.1 I
Z(DC)
2
0.5
PCB Mounted on
0.31" x 0.31" x 0.08"
(8 mm x 8 mm x 2 mm)
Copper Pad Areas
25
50
75
100
125
150
175
0
10
100
T
L
- Lead Temperature (°C)
V
Z
- Zener Voltage (V)
Fig. 1 - Maximum Continuous Power Dissipation
Fig. 3 - Typical Zener Impedance
1000
T
J
= 25 °C
I
Z(RMS)
= 0.1 I
Z(DC)
100
V
Z
= 62 V
100
V
Z
- Temperature Coefficient (mV/°C)
Z
Z
- Dynamic Impedance (Ω)
Tested at Rated I
ZT
10
V
Z
= 22 V
V
Z
= 10 V
0
0.5
1
10
100
500
10
10
100
I
Z
- Zener Test Current (mA)
V
Z
- Zener Voltage (V)
Fig. 2 - Typical Zener Impedance
Fig. 4 - Typical Temperature Coefficients
PACKAGE OUTLINE DIMENSIONS
in inches (millimeters)
DO-214AA (SMB-J-Bend)
Cathode Band
0.085 (2.159)
MAX.
Mounting Pad Layout
0.086 (2.20)
0.077 (1.95)
0.155 (3.94)
0.130 (3.30)
0.086 (2.18)
MIN.
0.180 (4.57)
0.160 (4.06)
0.012 (0.305)
0.006 (0.152)
0.096 (2.44)
0.084 (2.13)
0.060 (1.52)
MIN.
0.220 REF.
0.060 (1.52)
0.030 (0.76)
0.220 (5.59)
0.205 (5.21)
0.008 (0.2)
0 (0)
Revision: 25-May-12
Document Number: 88402
3
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
