GG72220
TM
®
ABSORPTIVE SPDT SWITCH MODULES with TTL Driver
RoHS Compliant
DESCRIPTION
Microsemi – Lowell’s switch modules provide an economical way of
achieving a switch function from UHF through Ku band. These switch
modules provide broadband, high performance characteristics in a
small package. Our catalog parts are basic examples of our
capability. We will be glad to explore your specific requirements with
the goal of providing custom parts for your needs.
KEY FEATURES
Multi Octave Frequency
www.MICROSEMI.com
Ranges
Hermetically Sealed
Microstrip/Stripline Compatible
Consistent VSWR
This series of modules meets RoHS requirements per EU Directive
2002/95/EC. The standard terminal finish is gold unless otherwise
specified. Consult the factory if you have special requirements.
Internal TTL Driver
RoHS Compliant
IMPORTANT:
For the most current data, consult
MICROSEMI’s
website:
www.MICROSEMI.com
These devices are ESD sensitive and must be handled use using ESD precautions.
ABSOLUTE MAXIMUM RATINGS AT 25º C
(UNLESS OTHERWISE SPECIFIED)
Rating
Storage Temperature
Operating Temperature
RF CW Power Handling
Symbol
T
STG
T
OP
P
CW
Value
-55 to +125
-55 to +95
0.5
Unit
ºC
ºC
W
APPLICATIONS/BENEFITS
Drop in Module
Broadband (0.5 – 18 GHz)
GG72220
GG72220
Copyright
2006
Rev.: 2009-02-02
Microsemi
Microwave Products
75 Technology Drive, Lowell, MA. 01851, 978-442-5600, Fax: 978-937-3748
Page 1
GG72220
TM
®
ABSORPTIVE SPDT SWITCH MODULES with TTL Driver
RoHS Compliant
GUARANTEED ELECTRICAL PARAMETERS @ 25C (unless otherwise specified)
Model Number
GG72220-01
GG72220-02
GG72220-03
GG72220-04
GG72220-05
Frequency
Range
0.5 - 4.0
2.0 - 8.0
4.0 - 12.4
8.0 - 18.0
2.0 - 18.0
Insertion Loss
1
(dB)
(Max)
1.7
2.1
2.4
2.9
2.9
Isolation(dB)
(Min)
60
55
50
40
40
VSWR
(Max)
1.7:1
1.7:1
1.8:1
1.9:1
2.0:1
SWITCHING
2
SPEED (uS)
T
RISE
(Max)
T
FALL
(Max)
www.MICROSEMI.com
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
Notes:
1. RF Power Handling; .5W CW.
2. Switching Speed: 1.0µS (max).
3. Required D.C. Bias: +5v @ +75mA (max) and -8 to -15v @ -50mA (max)
4. Switching Speed is measured from the 50% point of the TTL pulse to the 90%-10% of the detected RF pulse with a 100 kHz maximum
switching rate.
5. Temperature Rating: Operating, -55 to +95°C; Storage, -55 to =125°C.
6. Only the switched arms, J1 & J2 are matched in the isolated state. The common arm is matched only when one path is in the loss state.
ENVIRONMENTAL
These units are designed to withstand the following
environmental conditions without damage.
ENVRONMENTAL CONDITIONS
TEST
Internal Visual
Stabilization Bake
Thermal Cycle
Constant
Seal – Fine Leak
Seal – Gross Leak
External Visual
MIL-PRF METHOD CONDITION
883
883
883
883
883
883
883
2017
1008
1010
2001
1014
1014
2009
--
B
B
1 (Y1 Axis)
A1
C1
--
OUTLINE 210015
NOTES
1. All pins are 0.012 ±0.001" dia, 0.100" (min) long.
May be supplied with tabs, 0.025 ±0.01 x 0.006
±0.002, upon request.
2. Tolerance on 3 place decimal, ±0.003" unless
otherwise specified.
3. Case and leads gold plated per MIL-G-45204,
Type 3, Grade A 50 µinch (min).
ELEC / MECH
ELEC / MECH
Copyright
2006
Rev.: 2009-02-02
Microsemi
Microwave Products
75 Technology Drive, Lowell, MA. 01851, 978-442-5600, Fax: 978-937-3748
Page 2
