Hand Formable / Reformable Cable
•
Helically Formed Aluminum Composite Jacket
•
Replaces Semi-Rigid Cable
•
Phase and Temperature Stable
Midwest Microwave offers these hand formable and reformable semi-
flexible cable assemblies in three popular connector types; SMA, N, and
TNC. The assemblies can be hand formed to almost any reasonable
shape required and re-formed if necessary, eliminating the need for
complex drawings and costly dimensional inspections. The special
construction of this aluminum composite Flexiform cable provides supe-
rior phase amplitude stability, high impact strength, and excellent stability
over temperature. Flexiform has an outer conductor of helically formed
aluminum-tin composite, a solid PTFE dielectric, and a silver plated
copper clad steel center conductor.
Cable Assemblies
Flexiform Aluminum Composite Cable Assembly Specifications
MIDWEST CABLE No.
CSY-SMSM-A4-006-IS
CSY-SMSM-A4-012-IS
CSY-SMSM-A4-018-IS
CSY-SMSM-A4-024-IS
CSY-SMSM-A4-036-IS
MID WEST C AB LE N o.
C SY-N MN M-A4-006-IS
C SY-N MN M-A4-012-IS
C SY-N MN M-A4-018-IS
C SY-N MN M-A4-024-IS
C SY-N MN M-A4-036-IS
Connectors
SMA Male to SMA Male
SMA Male to SMA Male
SMA Male to SMA Male
SMA Male to SMA Male
SMA Male to SMA Male
C onnectors
N Male to M Male
N Male to N Male
N Male to N Male
N Male to N Male
N Male to N Male
Length (in.)
6
12
2.0
0.03
0.05
0.06
0.07
0.08
0.09
0.10
0.11
0.12
Insertion Loss
Frequency
(GHz )
SMA
dB
Type N TNC
dB
dB
0.05
0.08
0.10
0.11
0.13
0.14
0.20
0.22
0.25
0.04
0.07
0.09
0.10
0.12
0.13
0.18
0.20
0.23
Cable - dB/ft
M42
M52
0.17
0.25
0.33
0.40
0.46
0.50
0.56
0.60
0.64
0.12
0.18
0.22
0.26
0.30
0.33
0.36
0.39
0.41
18
4.0
24
6.0
36
8.0
Length (in.)
10.0
6
12
18
24
36
12.0
14.0
16.0
18.0
Notes:
1. TNC male connectors can be designated by substituting "TMTM" for the
“NMNM” in the Model No.
2. An optional Polyurethane shrink jacket to protect the outer conductor can
be designated by substituting a "J" for the “S” in the Model No.
HELICALLY FORMED TIN
PLATED SOFT ALUMINUM
OUTER CONDUCTOR
EXTRUDED PTFE
DIELECTRIC
3. Insertion loss specifications up to 26.0 GHz for SMA type
cable assemblies are available upon request.
4. Other standard connector interfaces may be supplied as
long as they can be fitted to 0.141 dia. semi-rigid cable.
MID WEST C AB LE TYPE
JAC K ET MATER IAL
OU TSID E D IA - in(mm)
D IELEC TR IC D IA - in(mm)
C EN TER C ON D U C TOR D IA - in(mm)
A4
Al / Sn
0.141 (3.6)
0.1175 (3.0)
0.0362 (0.92)
0.25 (6.35)
0.61
OPTIONAL
POLYURETHANE
SHRINK JACKET
SILVER PLATED
COPPER CLAD
SOLID STEEL
CENTER
CONDUCTOR
MIN B EN D R AD IU S - in(mm)
WEIGH T (oz per ft)
Materials and Finishes
Center Conductor
- Silver-coated copper clad steel per ASTM-B-298 40 micro-inches min thick per MIL-C-17.
Dielectric Core -
Extruded Polytetrafluoroethylene (PTFE), per MIL-C-17.
Outer Jacket -
Aluminum - Tin Composite
