Supply Voltage
Input Voltage
Output Voltage
Continuous Power Dissipation
@
25˚C Free-Air (Note 5)
7.0V
15V
70V
2075 mW
Storage Temperature Range
Lead Temperature
(Soldering, 4 seconds)
−65˚C to +150˚C
260
Operating Conditions
Min
Supply Voltage
Ambient Temperature
3.00
−40
Max
5.25
125
Units
V
˚C
Electrical Characteristics
(Notes 2, 3, 6)
Symbol
V
IH
V
IL
I
IH
I
IL
V
IK
V
OL
I
CEX
V
F
I
R
I
CC
I
TH
Parameter
Input High Voltage
Input Low Voltage
Input High Current
Input Low Current
Input Clamp Voltage
Output Low Voltage
Output Leakage Current
Diode Forward Voltage
Diode Leakage Current
Supply Current
Protection Circuit
Threshold Current
V
IN
= 5.25V, V
CC
= 5.25V
V
IN
= 0.4V
I
I
= −12 mA
I
L
= 300 mA
I
L
= 600 mA (Note 4)
V
CE
= 70V, V
IN
= 0.8V
I
F
= 800 mA
V
R
= 70V
All Inputs High
All Inputs Low
62
20
1
1.4
1.2
−0.8
0.2
0.55
1.0
Conditions
Min
2.0
0.8
20
Typ
Max
Units
V
V
µA
µA
V
V
V
µA
V
µA
mA
mA
A
±
10
−1.5
0.7
1.5
100
1.6
100
80
Switching Characteristics
(Notes 2, 6)
Symbol
t
PHL
t
PLH
t
FZ
t
RL
Parameter
Turn On Delay
Turn Off Delay
Protection Enable Delay
(after Detection of Fault)
Input Low Time for
Protection Circuit Reset
Conditions
R
L
= 60Ω, V
L
= 30V
R
L
= 60Ω, V
L
= 30V
6
1.0
Min
Typ
0.3
2
12
Max
1.0
10.0
Units
µs
µs
µs
µs
Note 1:
“Absolute Maximum Ratings” are those values beyond which the safety of the device cannot be guaranteed. They are not meant to imply that the devices
should be operated at these limits. The table of “Electrical Characteristics” specifies conditions of actual device operation.
Note 2:
Unless otherwise specified, min/max limits apply across the 0˚C to +70˚C temperature range and the 4.75V to 5.25V power supply range. All typical values
are for T
A
= 25˚C and V
CC
= 5.0V.
Note 3:
All currents into device pins are shown as positive; all currents out of device pins are shown as negative; all voltages are referenced to ground, unless
otherwise specified. All values shown as max or min are so classified on absolute value basis.
Note 4:
All sectors of this quad circuit may conduct rated current simultaneously, however, power dissipation averaged over a short interval of time must fall within
specified continuous dissipation ratings.
Note 5:
For operation over 25˚C free-air temperature, derate linearly to 1328 mW
@
70˚C
@
the rate of 16.6 mW/˚C.
Note 6:
Datasheet min/max specification limits are guaranteed by design, test, or statistical analysis.
