8EWF04STR

Description
Rectifier Diode, 1 Phase, 1 Element, 8A, 400V V(RRM), Silicon, TO-252AA, DPAK-3
CategoryDiscrete semiconductor    diode
File Size197KB,7 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric Compare View All

8EWF04STR Overview

Rectifier Diode, 1 Phase, 1 Element, 8A, 400V V(RRM), Silicon, TO-252AA, DPAK-3

8EWF04STR Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
MakerVishay
Parts packaging codeTO-252AA
package instructionR-PSSO-G2
Contacts3
Reach Compliance Codecompliant
ECCN codeEAR99
Other featuresFREE WHEELING DIODE, LOW LEAKAGE CURRENT
applicationFAST SOFT RECOVERY
Shell connectionCATHODE
ConfigurationSINGLE
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)1.2 V
JEDEC-95 codeTO-252AA
JESD-30 codeR-PSSO-G2
JESD-609 codee0
Humidity sensitivity level1
Maximum non-repetitive peak forward current200 A
Number of components1
Phase1
Number of terminals2
Maximum operating temperature150 °C
Minimum operating temperature-40 °C
Maximum output current8 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formSMALL OUTLINE
Peak Reflow Temperature (Celsius)225
Certification statusNot Qualified
Maximum repetitive peak reverse voltage400 V
Maximum reverse recovery time0.14 µs
surface mountYES
Terminal surfaceTIN LEAD
Terminal formGULL WING
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
8EWF..SPbF Soft Recovery Series
Vishay High Power Products
Surface Mountable
Fast Soft Recovery Diode, 8 A
FEATURES/DESCRIPTION
Base
common
cathode
+
2
The 8EWF..SPbF fast soft recovery rectifier series
has been optimized for combined short reverse
recovery time, low forward voltage drop and low
leakage current.
The glass passivation ensures stable reliable operation in
the most severe temperature and power cycling conditions.
D-PAK
1
Anode -
3
- Anode
This series is designed and qualified for industrial level.
Compliant to RoHS directive 2002/95/EC.
PRODUCT SUMMARY
V
F
at 8 A
t
rr
V
RRM
< 1.2 V
55 ns
200 to 600 V
APPLICATIONS
• Output rectification and freewheeling diode in inverters,
choppers and converters
• Input rectifications where severe restrictions on conducted
EMI should be met
MAJOR RATINGS AND CHARACTERISTICS
SYMBOL
I
F(AV)
V
RRM
I
FSM
V
F
t
rr
T
J
8 A, T
J
= 25 °C
1 A, 100 A/µs
Range
CHARACTERISTICS
Sinusoidal waveform
VALUES
8
200 to 600
170
1.2
55
- 40 to 150
UNITS
A
V
A
V
ns
°C
VOLTAGE RATINGS
PART NUMBER
8EWF02SPbF
8EWF04SPbF
8EWF06SPbF
V
RRM
, MAXIMUM PEAK
REVERSE VOLTAGE
V
200
400
600
V
RSM
, MAXIMUM NON-REPETITIVE
PEAK REVERSE VOLTAGE
V
300
500
700
3
I
RRM
AT 150 °C
mA
ABSOLUTE MAXIMUM RATINGS
PARAMETER
Maximum average forward current
Maximum peak one cycle
non-repetitive surge current
Maximum I
2
t for fusing
Maximum I
2
√t
for fusing
SYMBOL
I
F(AV)
I
FSM
I
2
t
I
2
√t
TEST CONDITIONS
T
C
= 96 °C, 180° conduction half sine wave
10 ms sine pulse, rated V
RRM
applied
10 ms sine pulse, no voltage reapplied
10 ms sine pulse, rated V
RRM
applied
10 ms sine pulse, no voltage reapplied
t = 0.1 ms to 10 ms, no voltage reapplied
VALUES
8
170
200
140
200
2000
A
2
s
A
2
√s
A
UNITS
Document Number: 94108
Revision: 01-Jul-09
For technical questions, contact:
diodestech@vishay.com
www.vishay.com
1
