Datasheet
General Purpose CMOS Logic IC
Quad 2-Input Exclusive-OR Gate
BU4030B
BU4030BF
Key Specifications
Operating Supply Voltage Range:
+3V to +16V
Input Voltage Range:
0V to V
DD
Operating Temperature Range:
-40°C to +85°C
General Description
BU4030B, BU4030BF consist of four independent
2-input Exclusive-OR gates. An inverter-based buffer is
incorporated at the gate output to improve I/O
transmission characteristics, and it minimizes a variation
in the propagation time caused by an increase in the
load capacitance.
Packages
Features
Low Power Consumption
High Noise Immunity
Wide Operating Supply Voltage Range
High Input Impedance
High Fan Out
2 L-TTL Inputs or 1 LS-TTL Input can be directly
driven
All Outputs are buffered
DIP14
SOP14
W(Typ) x D(Typ) x H(Max)
19.40mm x 6.50mm x 7.95mm
8.70mm x 6.20mm x 1.71mm
Pin Configurations
(Top View)
VDD
A4
B4
O4
O3
B3
A3
DIP14
BU4030B
SOP14
BU4030BF
A1
B1
O1
O2
B2
A2
VSS
Truth Table
INPUT
A
L
L
H
H
B
L
H
L
H
OUTPUT
O
L
H
H
L
○Product
structure: Silicon monolithic integrated circuit
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111・14・001
○This
product has no designed protection against radioactive rays
1/12
TSZ02201-0RDR1GZ00040-1-2
09.Aug.2013 Rev.001
BU4030B
BU4030BF
Datasheet
Pin Descriptions
Pin No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Pin Name
A1
B1
O1
O2
B2
A2
VSS
A3
B3
O3
O4
B4
A4
VDD
I/O
I
I
O
O
I
I
-
I
I
O
O
I
I
-
Function
Input1
Input1
Output1
Output2
Input2
Input2
Ground
Input3
Input3
Output3
Output4
Input4
Input4
Power supply
Absolute Maximum Ratings
Parameter
Supply Voltage
Input Voltage
Input Current
Operating Temperature
Storage Temperature
Maximum Junction Temperature
Power Dissipation
Symbol
V
DD
V
IN
I
IN
Topr
Tstg
Tjmax
DIP14
Pd
SOP14
Rating
-0.3 to +18.0
-0.3 to V
DD
+0.3
±10
-40 to +85
-55 to +150
+150
1.18
(Note 1)
Unit
V
V
mA
°C
°C
°C
W
0.56
(Note 2)
(Note 1) Reduce 9.5mW per 1°C above 25°C
(Note 2) Mounted on 70mm x 70mm x 1.6mm glass epoxy board. Reduce 4.5mW per 1°C above 25°C
Caution:
Operating the IC over the absolute maximum ratings may damage the IC. The damage can either be a short circuit between pins or an open circuit
between pins and the internal circuitry. Therefore, it is important to consider circuit protection measures, such as adding a fuse, in case the IC is operated
over the absolute maximum ratings.
Recommended Operating Conditions
Parameter
Supply Voltage
Input Voltage
Symbol
V
DD
V
IN
Rating
+3.0 to +16.0
0 to V
DD
Unit
V
V
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111・15・001
2/12
TSZ02201-0RDR1GZ00040-1-2
09.Aug.2013 Rev.001
BU4030B
BU4030BF
Datasheet
Electrical Characteristics
(Unless otherwise specified, V
SS
=0V, Ta=25°C)
Limits
Parameter
Symbol
Min
3.5
Input “H” voltage
V
IH
7.0
11.0
-
Input “L” voltage
V
IL
-
-
Input “H” current
Input “L” current
DC Characteristics
I
IH
I
IL
-
-
4.95
Output “H” voltage
V
OH
9.95
14.95
-
Output “L” voltage
V
OL
-
-
-0.16
Output “H” current
I
OH
-0.4
-1.2
0.44
Output “L” current
I
OL
1.1
3.0
-
Quiescent supply current
I
DD
-
-
Typ
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
Limits
Parameter
Symbol
Min
-
Output rising time
Switching Characteristics
t
TLH
-
-
-
Output falling time
t
THL
-
-
-
“L” to ”H”
Propagation delay time
t
PLH
-
-
-
“H” to ”L”
Propagation delay time
Input capacitance
t
PHL
-
-
C
IN
-
Typ
180
90
65
100
50
40
90
50
40
90
50
40
5
Max
-
-
-
-
-
-
-
-
-
-
-
-
-
pF
ns
ns
ns
ns
Unit
V
DD
(V)
5
10
15
5
10
15
5
10
15
5
10
15
-
-
-
C
L
=50pF
9
C
L
=50pF
8
C
L
=50pF
7
C
L
=50pF
6
Max
-
-
-
1.5
3.0
4.0
0.3
-0.3
-
-
-
0.05
0.05
0.05
-
-
-
-
-
-
1
2
4
μA
mA
mA
V
V
μA
μA
V
V
Unit
V
DD
(V)
5
10
15
5
10
15
15
15
5
10
15
5
10
15
5
10
15
5
10
15
5
10
15
Conditions
V
IN
=V
DD
or V
SS
-
V
OH
=4.6V
V
OH
=9.5V
V
OH
=13.5V
V
OL
=0.4V
V
OL
=0.5V
V
OL
=1.5V
5
4
I
OL
=0mA
I
OH
=0mA
V
IH
=15V
V
IL
=0V
-
-
Conditions
Figure
No.
1
2
3
1
2
3
-
-
1
2
3
1
2
3
Figure
No.
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111・15・001
3/12
TSZ02201-0RDR1GZ00040-1-2
09.Aug.2013 Rev.001
BU4030B
BU4030BF
Datasheet
Test
Circuits (one Exclusive-OR circuit only)
1. V
IH
2.V
IL
V
IH
+
V V
OH
V
IL
+
V V
OL
3. V
OH
4.V
OL
V
IH
I
OH
+
V V
OH
V
IL
I
OL
+
V V
OL
5. I
OH
6.I
OL
V
IH
+
A I
OH
V
OH
V
IL
+
A I
OL
V
OL
7. t
TLH
, t
THL
, t
PLH
, t
PHL
20ns
90%
50%
10%
t
PLH
OUTPUT
50%
10%
90%
t
PHL
20ns
INPUT
OUTPUT
INPUT
C
L
=50pF
t
THL
t
TLH
Description of Symbols
t
PLH
：Time
from 50% of the rise edge of input waveform to 50%
of the rise edge of output waveform
t
PHL
：Time
from 50% of the fall edge of input waveform to 50% of
the fall edge of output waveform
t
TLH
：Time
from 10% to 90% of rise edge of outputwaveform
t
THL
：Time
from 10% to 90% of fall edge of outputwaveform
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111・15・001
4/12
TSZ02201-0RDR1GZ00040-1-2
09.Aug.2013 Rev.001
BU4030B
BU4030BF
Datasheet
Typical Performance Curves
6
5
Output Voltage [V]
4
Output Voltage [V]
85℃
25℃
-40℃
12
10
8
85℃
25℃
-40℃
3
2
1
0
0
1
2
3
4
5
Input Voltage [V]
Figure 1. Output Voltage vs Input Voltage
（V
DD
=5V / V
SS
=0V）
6
4
2
0
0
2
4
6
8
10
Input Voltage [V]
Figure 2. Output Voltage vs Input Voltage
（V
DD
=10V / V
SS
=0V）
20
0
V
DD
=5V
85℃
25℃
-40℃
-10
Output "H" Current [mA]
15
Output Voltage [V]
85℃ 25℃
-40℃
-20
V
DD
=10V
85℃
25℃
-40℃
10
-30
5
V
DD
=15V
85℃
25℃
-40℃
-40
0
0
5
10
15
Input Voltage [V]
Figure 3. Output Voltage vs Input Voltage
（V
DD
=15V / V
SS
=0V）
-50
0
5
10
Output Voltage [V]
Figure 4. Output “H” Current vs Output Voltage
15
20
www.rohm.com
© 2013 ROHM Co., Ltd. All rights reserved.
TSZ22111・15・001
5/12
TSZ02201-0RDR1GZ00040-1-2
09.Aug.2013 Rev.001
