SMD Wire-wound Chip Inductors
ctparts.com
CT1210LSC Series
From 0.47 µH to 680 µH
Part
Number
CT1210LSC_-R47_
CT1210LSC_-1R0_
CT1210LSC_-1R5_
CT1210LSC_-1R8_
CT1210LSC_-2R2_
CT1210LSC_-2R7_
CT1210LSC_-3R3_
CT1210LSC_-4R7_
CT1210LSC_-5R6_
CT1210LSC_-6R8_
CT1210LSC_-8R2_
CT1210LSC_-100_
CT1210LSC_-150_
CT1210LSC_-180_
CT1210LSC_-220_
CT1210LSC_-270_
CT1210LSC_-330_
CT1210LSC_-470_
CT1210LSC_-680_
CT1210LSC_-101_
CT1210LSC_-151_
CT1210LSC_-181_
CT1210LSC_-221_
CT1210LSC_-331_
CT1210LSC_-471_
CT1210LSC_-681_
Not shown at actual size.
SPECIFICATIONS
Please specify tolerance code when ordering.
CT1210LSC-1R0_
J = ±5%, K = ±10%
CT1210LCSF
Please specify “F” for RoHS compliant
L Test
Freq.
(MHz)
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
Q
Fact.
Min.
40
20
20
20
20
20
20
20
20
20
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
15
Q Test
Freq.
(MHz)
25.2
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
7.96
2.52
2.52
2.52
2.52
2.52
2.52
2.52
2.52
0.796
0.796
0.796
0.796
0.796
0.796
0.796
SRF
Min.
(MHz)
450
100
80
70
68
62
54
43
36
33
28
28
19
17
16
13
12
10
9
6
5
4
4
3.5
2.8
2
DCR
±30%
Ω
(Ω)
0.07
0.08
0.11
0.13
0.13
0.15
0.16
0.20
0.26
0.27
0.33
0.36
0.56
0.67
0.77
1.00
1.10
1.64
2.8
3.7
6.1
8.0
8.4
12
22
28
Rated
DC
(mA)
1800
1500
1125
970
970
900
837
675
620
600
570
520
480
330
310
280
270
210
189
145
120
105
100
80
75
65
Inductance
(µH)
0.47
1.0
1.5
1.8
2.2
2.7
3.3
4.7
5.6
6.8
8.2
10
15
18
22
27
33
47
68
100
150
180
220
330
470
680
Compliant
Available
RoHS
CHARACTERISTICS
Description:
SMD ferrite core wire-wound high current chip
inductor
Applications:
LC resonant circuits such as oscillator and signal
generators, impedance matching, circuit isolation, RF filters, disk
drives and computer peripherals, audio and video equipment, TV,
radio and telecommunication equipment
Operating Temperature:
-25°C to +85°C
Inductance Tolerance:
±5% & ±10%
Testing:
Inductance and Q are tested on an HP4285A at
specified frequency
Packaging:
Tape & Reel
Miscellaneous:
RoHS Compliant available.
Marking:
Parts are marked with color dots in nanoHenries.
Example: 10uH = 10000nH
marking would be Brown, Black,
Orange(103).
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
3.70
0.146
B
Max.
2.90
0.114
C
Max.
2.6
0.102
D
0.51
0.019
E
0.51
0.019
F
1.52
0.060
C
B
Overall
E
A
F
E
D
Terminal Wraparound
0.38mm(0.015“) Both Ends
PAD LAYOUT
