Limit and Enclosed Switches
Plastic Enclosed Switches
BF Series
FEATURES
Wide variety of actuators — roller levers,
wobble levers, and pin plungers
Four conduit openings:
–1/2-14 NPT
–1/2-14 NPSM
–PF1/2
–PG13.5
Large internal cavity for easy wiring
Pressure plate style wire clamps
Rugged plastic enclosure eliminates
need for grounding
Several basic switches available ranging
from 0.1 Amp electronic duty gold
contact to 11 Amp 1/3 HP
Sealed to NEMA 1, 3, 4 and 13
requirements
Wide temperature range, –25 to
+160°F
(–31 to
+71°C)
UL recognized
TYPICAL APPLICATIONS
Overhead cranes and hoists
Surface transportation equipment
Special machinery
Agricultural equipment
Earth moving equipment
Limit/Enclosed
BF Series Plastic Enclosed Basic Switches are available with a wide variety of operators, and
are designed for easy mounting and wiring.
BF switches mount utilizing two (2) #6 screws installed through the two diametrically
opposite mounting holes in the switch housing (2.312 in x 1.375 in spacing). The BF switches
are designed to allow mounting with the cover either towards or away from the mounting
surface. It may be more convenient to select the appropriate operator orientation to allow
mounting with the cover away from the mounting surface, permitting wiring after mounting.
Switches with lever type actuators (actuator code L in the second position after the dash) are
adjustable in two directions. The entire actuator can be rotated around its mounting
bushing, and the angle of the lever can also be changed.
Honeywell
Sensing and Control 1-800-537-6945 USA
1-815-235-6847 International 1-800-737-3360 Canada
A93
Limit and Enclosed Switches
Plastic Enclosed Switches
ORDER GUIDE
BF
ORIENTATION
L L.H. Actuator, std. mtg.
CONDUIT OPENING
1 1/2 – 14 NPT
2 1/2 – 14 NPSM
3 PF1/2
4 PG13.5
BASIC SWITCH
A 5 Amp – V7
B 11 Amp – V7
S 0.1 Amp Gold Clad – V7
ACTUATOR
L1 Roller Lever
L2 Rod Lever
L3 One Way Roller Lever
L4 Manual Lever
P1 Straight Plunger, Std.
W1 Coil Spring Wobble
W2 Plastic Wobble, Std.
W3 Plastic Wobble, Tall
W4 Spring Wire, Std.
W5 Spring Wire, Tall
–
Packet (for use with
1/2-14 NPT)
Cable O.D. In. (mm)
2PA6
2PA16
2PA1
.400 – .435 (10,2 – 11,05)
.435 – .470 (11,05 – 11,90)
.530 – .570 (13,5 – 14,5)
BF Series
SEALING PACKETS
(for use with the 1/2-14 npt conduit opening)
A liquid tight conduit fitting for the 1/2–14 NPT conduit opening is also
available.
Packet
2PA17
Cable O.D. In. (mm)
.170 – .470 (4,3 – 11,9)
MOUNTING DIMENSIONS
(For reference only)
COIL SPRING WOBBLE LEVER
A94
Honeywell
Sensing and Control 1-800-537-6945 USA
1-815-235-6847 International 1-800-737-3360 Canada
