SURFACE MOUNT SILICON RECTIFIER
VOLTAGE RANGE 50 to 1000 Volts CURRENT 1.0 Ampere
HL101W
THRU
HL107W
FEATURES
* Ideal for surface mounted applications
* Low leakage current
* Metallurgically bonded construction
* Mounting position: Any
* Weight: 0.078 gram
SMX
MECHANICAL DATA
* Epoxy : Device has UL flammability classification 94V-0
.110 (2.79)
.086 (2.18)
.209 (5.31)
.185 (4.70)
.071 (1.80)
.051 (1.30)
.010 (0.25)
.008 (0.20)
.011 (0.28)
.007 (0.18)
.180 (4.57)
.160 (4.06)
.091 (2.31)
.067 (1.70)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
O
C ambient temperature unless otherwise specfied.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
.059 (1.50)
.035 (0.89)
Dimensions in inches and (millimeters)
MAXIMUM RATINGS (@ T
A
=25
O
C unless otherwise noted)
RATINGS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
at Lead Temperatu re
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Typical Thermal Resistance (Note 1)
Typical Thermal Resistance (Note 1)
Typical Junction Capacitance (Note 2)
Operating Temperature Range
Storage Temperature Range
SYMBOL
V
RRM
V
RMS
V
DC
I
O
I
FSM
R
q
JA
R
q
JL
C
J
T
J
T
STG
35
100
60
15
150
-55 to + 150
HL101W
HL102W
HL103W
HL104W
HL105W
HL106W
HL107W
UNITS
Vol ts
Vol ts
Vol ts
Amps
50
35
50
100
70
100
200
140
200
400
280
400
1.0
600
420
600
800
560
800
1000
700
1000
30
Amps
0
0
C/W
C/W
pF
0
0
C
C
ELECTRICA L CHARACTERISTIC S (@T
A
=25
O
C unless otherwise noted)
CHARACTERISTICS
Maximum Instantaneous Forward Voltage at 1.0A DC
Maximum Full Load Reverse Current,
Full cycle Average at T
A
=75
O
C
Maximum Average Reverse Current
at Rated DC Blocking Voltage
@T
A
= 25
o
C
@T
A
= 125
o
C
I
R
SYMBOL
V
F
HL101W
HL102W
HL103W
HL104W
HL105W
HL106W
HL107W
UNITS
Vol ts
uA
nA
uA
2008-7
1.05
30
500
100
NOTES : 1. Thermal Resistance :Mounted on PCB.
2. Measured at 1 MHz and applied reverse voltage of 4.0 volts.
3. "Fully ROHS compliant","100% Sn plating (Pb-free)".
RATING AND CHARACTERISTICS CURVES ( HL101W THRU HL107W )
INSTANTANEOUS FORWARD CURRENT, ( uA)
AVERAGE FORWARD CURRENT, (A)
2.0
1000
100
T
A
= 100
O
C
10
1.0
0.1
0.01
0
T
A
= 75
O
C
T
A
= 25
O
C
1.5
1.0
0.5
Single Phase Half Wave 60Hz
Resistive or Inductive Load
0.375" (9.5mm) Lead Length
0
0
25
50
75
100
125
O
150
175
20
40
60
80
100
120
140
LEAD TEMPERATURE, ( C)
PERCENT OF RATED PEAK REVERSE VOLTAGE, (%)
INSTANTANEOUS REVERSE CURRENT, (A)
10
C
J
, JUNCTION CAPACITANCE, (pF)
20
FIG.1 TYPICAL FORWARD CURRENT
DERATING CURVE
40
20
10
8
6
4
2
1
FIG.2 TYPICAL REVERSE
CHARACTERISTICS
T
J
= 25
O
C
1.0
0.1
T
J
= 25
O
C
Pulse width=300 S
1% Duty Cycle
0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
0.1
0.4
1.0
4
10
40 80
INSTANTANEOUS FORWARD VOLTAGE, (V)
REVERSE VOLTAGE, (V)
FIG.3 TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS
PEAK FORWARD SURGE CURRENT, (A)
FIG.4 TYPICAL JUNCTION CAPACITANCE
50
40
30
20
10
0
1
8.3mS Single Half Sine-Wave
JEDEC Method
HL101W~HL104W
HL105W~HL106W
2
4
6
8 10
20
40
80 100
NUMBER OF CYCLES AT 60Hz
FIG.5 MAXIMUM NON-REPETITIVE FORWARD
SURGE CURRENT
