MGDS-04-C-F/S-L datasheet, PDF

Datasheet> All Categories > Power/power management> The power supply circuit> MGDS-04-C-F/S-L

MGDS-04-C-F/S-L: DescriptionDC-DC Regulated Power Supply Module, 1 Output, 4W, Hybrid, METAL PACKAGE-9/24; CategoryPower/power management The power supply circuit; File Size512KB，14 Pages; ManufacturerGAIA Converter Inc; Websitehttps://gaia-converter.com

Download Datasheet Parametric View All

MGDS-04-C-F/S-L Overview

DC-DC Regulated Power Supply Module, 1 Output, 4W, Hybrid, METAL PACKAGE-9/24

MGDS-04-C-F/S-L Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	GAIA Converter Inc
Parts packaging code	MODULE
package instruction	METAL PACKAGE-9/24
Contacts	9/24
Reach Compliance Code	compliant
ECCN code	EAR99
Analog Integrated Circuits - Other Types	DC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage	5.5 V
Minimum input voltage	4.5 V
Nominal input voltage	5 V
JESD-30 code	R-MDMA-P9
JESD-609 code	e3
length	32 mm
Maximum load regulation	2.5%
Number of functions	1
Output times	1
Number of terminals	9
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output current	0.26 A
Maximum output voltage	15.3 V
Minimum output voltage	14.7 V
Nominal output voltage	15 V
Package body material	METAL
encapsulated code	DIP
Encapsulate equivalent code	DIP9/24,.6
Package shape	RECTANGULAR
Package form	MICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum seat height	7.7 mm
surface mount	NO
technology	HYBRID
Temperature level	INDUSTRIAL
Terminal surface	MATTE TIN OVER NICKEL
Terminal form	PIN/PEG
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Maximum total power output	4 W
Fine-tuning/adjustable output	NO
width	19.3 mm

Preview

Download Datasheet

View All

Hi-Rel DC/DC CONVERTER

MGDM-04 : 4W POWER

Hi-Rel

Grade

Single, Bi & Triple Outputs

Metallic Case - 1 500 VDC Isolation

• 28 Vdc input compliant with MIL-STD-704 D/E

• Low profile : 0,3‘’ (7.5mm)

• Nominal power of 4W without derating

• Wide temperature range : -40°C/+105°C case

• Soft start

• Galvanic isolation 1.500 VDC

• Integrated LC EMI filter

• Permanent short circuit protection

• Standard pin out DIL24 9 pins

• Inhibit function

• No optocoupler for high reliability

• RoHS or Leaded process option

The MGDM-04 series is a full family of high per-

formance and low profile DC/DC power modules

designed for aerospace, military and high-end

industrial applications. These modules use a high

frequency fixed switching technic at 480KHz

providing excellent reliability, low noise

characteristics, high power density and a low pro-

file package. Standard models are available with

nominal input voltages as 5, 12 or 28 volts in

range of 4,5-5,5 , 9-36 or 16-40 volts. The series

include single, bi and triple output voltage choices

of 3.3, 5, 12, 15, +/-5, +/-12 or +/-15 volts. No

external heatsink is required for the MGDM-04

series to supply 4W output power over the case

temperature range of -40°C up to 105°C.

All the modules are designed with LC network

filters to minimize reflected input current ripple

and output voltage ripple.

The modules include a soft-start, a permanent

short circuit protection and an output overvoltage

protection to ensure efficient module protections.

The soft-start allows current limitation and

eliminates inrush current during start-up. The

short circuit protection completely protects the

module against short-circuits of any duration by

a shut-down and restores to normal when the

overload is removed.

The design has been carried out with surface

mount components and is manufactured in a fully

automated process to guarantee high quality. Each

module is tested and burned in with a GAIA

Converter automated test equipment before and

after encapsulation. The modules are potted with

a bi-component thermal conductive compound and

packaged in a metallic case to ensure the module’s

integrity under high environmental conditions.

1-General

2-Product Selection

Single output model

Bi output model

Triple output model

: MGDS - 04 -

: MGDB - 04 -

: MGDT - 04 -

input

output

option

suffix

Input Voltage Range

Permanent

C : 4,5-5,5 VDC

H : 9-36 VDC

J : 16-40 VDC

* Consult factory

Output

B : 3.3 VDC

C : 5 VDC or +/-5VDC

E : 12 VDC or +/-12VDC

F : 15 VDC or +/-15VDC

CF : 5 VDC and +/-15 VDC

Transient

n/a

40 VDC/100 ms *

50 VDC/100 ms *

Options :

/T : option for -55°C start up operating temperature

/S : option for screening and serialization

Suffix :

nothing : RoHS process

-L : leaded process

(available in N. America)

REDEFINING THE SOURCE OF POWER

Gaia Converter FC97-008.01/11 Revision P

For locations, phone, fax, E-Mail see back cover
