Printed-circuit board connector - CC 2,5/ 2-GSF-5,08 GN
P26THR - 1711003
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
PCB headers, nominal current: 12 A, rated voltage (III/2): 320 V, number of positions: 2, pitch: 5.08 mm, color:
green, contact surface: Tin, mounting: THR soldering, User information and design recommendations for
through hole reflow technology can be found under “Downloads”
The figure shows a 6-position
version
Your advantages
Designed for integration into the SMT soldering process
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
Screwable flange for superior mechanical stability
Key Commercial Data
Packing unit
GTIN
GTIN
Custom tariff number
4055626200453
85366930
1
Technical data
Dimensions
Length [ l ]
Width
Pitch
Dimension a
Width [ w ]
Height [ h ]
Height
Length of the solder pin
Pin dimensions
12 mm
20.27 mm
5.08 mm
5.08 mm
20.27 mm
11.17 mm
8.57 mm
2.6 mm
1 x 1 mm
01/14/2019 Page 1 / 3
https://www.phoenixcontact.com/in/products/1711003
Printed-circuit board connector - CC 2,5/ 2-GSF-5,08 GN
P26THR - 1711003
Technical data
Dimensions
Length
12 mm
General
Range of articles
Insulating material group
Rated surge voltage (III/3)
Rated surge voltage (III/2)
Rated surge voltage (II/2)
Rated voltage (III/3)
Rated voltage (III/2)
Rated voltage (II/2)
Connection in acc. with standard
Nominal current I
N
Maximum load current
Insulating material
Flammability rating according to UL 94
Color
Number of positions
CC 2,5/..-GSF
IIIa
4 kV
4 kV
4 kV
250 V
320 V
400 V
EN-VDE
12 A
12 A
LCP
V0
green
2
Standards and Regulations
Connection in acc. with standard
Flammability rating according to UL 94
EN-VDE
V0
Environmental Product Compliance
REACh SVHC
China RoHS
Lead 7439-92-1
Environmentally Friendly Use Period = 50
For details about hazardous substances go to tab “Downloads”,
Category “Manufacturer's declaration”
Classifications
eCl@ss
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
eCl@ss 8.0
eCl@ss 9.0
27260700
27260700
27440402
27440402
27440402
ETIM
ETIM 5.0
ETIM 6.0
EC002637
EC002637
01/14/2019 Page 2 / 3
https://www.phoenixcontact.com/in/products/1711003
Printed-circuit board connector - CC 2,5/ 2-GSF-5,08 GN
P26THR - 1711003
Classifications
UNSPSC
UNSPSC 13.2
39121409
Approvals
Approvals
Approvals
EAC / cULus Recognized
Ex Approvals
Approval details
EAC
B
300 V
10 A
B.01742
cULus Recognized
Nominal voltage UN
Nominal current IN
http://database.ul.com/cgi-bin/XYV/template/LISEXT/1FRAME/index.htm E60425-19931011
C
300 V
10 A
