MOLDED PARTS
Qualtek Electronics
QLB
LOW VOLTAGE CABLE BREAKOUT, FLAME-RETARDANT
2 CORE & 3 CORE
Features/Applications
QLB is widely used in the electrical power industry because of the insulating,
UV and weather proof properties. The heat shrinkable boots seal and protect
multi core cables. Coated with specially designed hot-melt adhesive.
Operating temperature: -55°C
to +110°C
Minimum shrink temperature: 110°C
Full Recovery Temperature: 130°C
Standard color: Black
RoHS Compliant
2 - Core
3 - Core
Technical Data
Property
Operating Temperature
Tensile Strength
Tensile Strength After Thermal Aging (120°C, 168 hrs.)
Elongation at Break After Thermal Aging (120°C, 168 hrs.)
Elongation at Break
Water Absorption
Volume Resistance
Dielectric Strength
Test Method
IEC 216
ASTM D 2671
ASTM D 2671
ASTM D 2671
ASTM D 2671
ISO 62
IEC 93
IEC 243
Typical Data
-55°C
to +110°C
13 MPa min.
10 MPa min.
250% min.
300% min.
1% max.
10
Ω
.cm
(min.)
13
15KV / mm (min.)
2 CORE BREAKOUTS
Part
Number
QLB205-22/8
QLB210-30/12
QLB215-40/16
QLB220-60/23
QLB220L-60/23L
QLB230-90/60
QLB240-150/90
D (mm)
a (Min.)
22
30
40
60
60
90
150
b (Max.)
8
12
16
23
23
60
90
l (mm)
a (Min.)
9
14
15
25
25
30
20
b (Max.)
3.5
4.5
5.0
7.5
7.5
8.5
6.5
Recovered Length
± 10%
L (mm)
55
93
125
118
155
190
150
F (mm)
18
23
35
29
45
50
70
Recovered Wall
± 10%
Dw (mm)
2.2
2.6
2.1
2.6
2.6
3.0
3.0
lw (mm)
1.8
2.2
2.1
2.6
2.6
3.0
3.0
3 CORE BREAKOUTS
Part
Number
QLB310-38/16
QLB320-60/25
QLB330-80/38
QLB340-110/50
QLB350-125/57
QLB360-140/70
QLB370-170/77
QLB310L-40/16L
QLB320L-60/24L
QLB330L-80/38L
Notes:
(a) as supplied
(b) after recovery
D (mm)
a (Min.)
38
60
80
110
125
140
170
40
60
80
b (Max.)
16
25
38
50
57
70
77
16
24
38
l (mm)
a (Min.)
15
25
35
46
55
62
75
15
25
35
b (Max.)
4.5
8.0
11.0
17.5
20.0
26.0
28.0
4.5
8.0
11.0
Recovered Length
± 10%
L (mm)
110
165
185
250
260
280
280
125
180
215
F (mm)
35
50
55
65
75
75
80
35
45
57
Recovered Wall
± 10%
Dw (mm)
2.1
3.0
3.5
4.0
4.0
4.0
4.0
2.1
3.2
4.0
lw (mm)
2.1
2.5
3.5
4.0
4.0
4.0
4.0
2.1
2.8
4.0
Extender 3 Core Breakouts
ISO-9001 Company
www.qualtekusa.com
QLB-200C
